YM20 250V 5A 9Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal

Name: YM20 250V 5A 9Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 357.0 INR
Availability: InStock

357.0 INR/Piece

Get a Price/Quote

Product Details:

Features Waterproof, Dustproof, Durable, Easy install, Corrosion Resistant
Input Solder Terminal
Output Solder Terminal
Power Supply AC
Power Source Electrical Grid / Panel Connection
Usage Waterproof Power Connector
Operating Temperature -40C to +85C
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YM20 250V 5A 9Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal Price And Quantity

Price 357.0 INR/Piece
Minimum Order Quantity 100 Piece

Mechanical Life >500 Mating Cycles
Contact Resistance 5m
Mounting Type Panel Mount
Insulation Resistance 2000M (at 500V DC)
Environmental Protection UV Resistant, Weatherproof
Shell Material High Strength Plastic
Pin Material Brass with Tin Plating
Seal Type Rubber Gasket
Cable Diameter Range 7mm - 12mm
Connector Gender Female
Flame Retardant Grade UL94 V-0
Withstanding Voltage 1500V AC/minute
Mating Cycle >500 Times

YM20 250V 5A 9Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal Product Specifications

Rated Voltage 250V AC
Frequency 50/60Hz
Dimension (L*W*H) Approx 67mm (Total Length), 25mm (Diameter)
Power Supply AC
Power Source Electrical Grid / Panel Connection
Usage Waterproof Power Connector
Operating Temperature -40C to +85C
Current Rating 5A
Thickness Standard
Interface 9 Pin Female Socket
Components Plastic Shell, 9-pin Insert, Solder Contacts
IP Rating IP67
Input Solder Terminal
Features Waterproof, Dustproof, Durable, Easy install, Corrosion Resistant
Function Power Connection
Capacity 5A
Application Industrial Equipment, Outdoor Power Distribution, Automation
Supply Voltage 250V AC
Product Type 9 Pin Female Socket
Color Black
Size YM20
Weight Approx 32g
Output Solder Terminal

Mechanical Life >500 Mating Cycles
Contact Resistance 5m
Mounting Type Panel Mount
Insulation Resistance 2000M (at 500V DC)
Environmental Protection UV Resistant, Weatherproof
Shell Material High Strength Plastic
Pin Material Brass with Tin Plating
Seal Type Rubber Gasket
Cable Diameter Range 7mm - 12mm
Connector Gender Female
Flame Retardant Grade UL94 V-0
Withstanding Voltage 1500V AC/minute
Mating Cycle >500 Times

YM20 250V 5A 9Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Withstanding voltage:1500V
Operating Voltage:250V
Contact dimension:Phi 1*9
Insertion and extraction force:2.7N Max
Mating cycle:1700 Times
Screw torque:42-53(N.m)
Temperature and humidity:-4080C; 40C, 85%RH

Superior Waterproof and Dustproof Performance

Certified to IP67 standards, this connector is engineered for harsh environments. Whether used in outdoor industrial equipment or exposed installations, its reliable waterproof and dustproof sealing-thanks to a quality rubber gasket-protects internal contacts from moisture and particulates, ensuring steady operation and longevity.

High Durability and Operational Safety

With a mechanical life exceeding 500 mating cycles and flame retardant materials rated to UL94 V-0, the YM20 connector is built for repeated, safe usage. It withstands voltages up to 1500V AC/minute and operates effectively in temperatures from -40C to +85C, making it suitable for a wide range of industrial and outdoor settings.

Efficient Panel Mount Installation

Designed for easy panel mounting, this 9-pin female socket simplifies installation in power distribution systems. Cable management is versatile with a 7mm-12mm diameter range, while the robust plastic build and solder terminal interfaces ensure secure, straightforward wiring for both power input and output.

FAQ's of YM20 250V 5A 9Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal:

Q: How do I install the YM20 9Pin Female Power Connector in my industrial panel?

A: To install, simply insert the connector into your panel's pre-cut hole, secure it using the mounting hardware, and solder your wires to the terminal pins. The rubber gasket ensures a watertight seal, making it suitable for outdoor or challenging environments.

Q: What are the key benefits of using this connector for outdoor applications?

A: The YM20 offers IP67 waterproofing, UV resistance, and a flame-retardant shell, which provide excellent protection against weather, sunlight, and fire hazards. Its durable construction ensures long-term reliability even in exposed or harsh settings.

Q: When should I use a 9-pin configuration for power connections?

A: A 9-pin connector is ideal when you need multiple power or signal connections in a single, sealed interface, commonly required in automation, control panels, or equipment with several circuit requirements.

Q: Where can this connector be used most effectively?

A: It is best suited for industrial equipment, outdoor power distribution, automation systems, and any installation requiring reliable, weatherproof power connections-particularly where safety and longevity are critical.

Q: What is the rated current and voltage capacity for this connector?

A: The YM20 9Pin Female Socket is rated for 250V AC and 5A. It is compatible with standard AC power supplies and supports currents typical in industrial equipment and power distribution setups.

Q: Is the connector resistant to corrosion and mechanical wear?

A: Yes, the high-strength plastic shell, tin-plated brass pins, and rubber gasket make it corrosion-resistant and capable of withstanding over 500 mating cycles, ensuring mechanical durability in demanding environments.

Q: How does the solder terminal process work for this connector?

A: To connect wires, strip the insulation, insert the bare wire into each solder cup on the back of the connector, and solder it securely. This provides a stable and low-resistance electrical connection for both input and output terminals.
