LP24 400V 10A 10Pin Female Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal

Name: LP24 400V 10A 10Pin Female Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 656.0 INR
Availability: InStock

656.0 INR/Piece

Get a Price/Quote

Product Details:

Input Up to 400V AC, 10A max current
Power Source Electrical Mains
Output Through 10-pins solder terminal connection
Components Connector shell, 10-pin female insert, sealing gasket, screw lock
IP Rating IP67
Usage Provides reliable power transmission and connectivity in harsh environments
Power Supply Electrical Cable Connection
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP24 400V 10A 10Pin Female Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal Price And Quantity

Price 656.0 INR/Piece
Minimum Order Quantity 100 Piece

Contact Resistance 5m
Shell Material Zinc alloy with nickel plating
Flame Retardant Level UL94 V-0
Connector Gender Female
Environmental Compliance RoHS Compliant
Sealing Method Silicone O-ring gasket
Contact Material Gold-plated brass contacts for enhanced conductivity
Mating Connector LP24 10-pin male plug (compatible)
Insulation Resistance >2000M (at 500V DC)
Mounting Type Panel mount with screw fastening
Number of Pins 10-pin
Mechanical Endurance >500 mating cycles
Cable Entry Size M20 x 1.5 (cable gland compatible)
Locking System Threaded metal locking ring

LP24 400V 10A 10Pin Female Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal Product Specifications

Color Silver / Black
Thickness Shell thickness approx. 3mm
Thermal Conductivity Standard for metal-bodied connectors
Size LP24 Standard
Interface 10-pin solder terminal
Components Connector shell, 10-pin female insert, sealing gasket, screw lock
Product Type Female Power Socket Connector
Power Supply Electrical Cable Connection
Supply Voltage 400V AC
Power Source Electrical Mains
Dimension (L*W*H) Approx. 31mm x 65mm (excluding cable assembly)
Rated Voltage 400V AC
Operating Temperature -40C to +85C
Output Through 10-pins solder terminal connection
Features Dustproof, waterproof, anti-corrosion, vibration resistant, secure locking mechanism
Frequency 50/60Hz
Input Up to 400V AC, 10A max current
Application Heavy Duty Equipment, Automation, Machinery, Outdoor Power Distribution
Function Waterproof power connection for industrial and outdoor applications
Capacity 10A maximum current per contact
Weight Approx. 125g
IP Rating IP67
Usage Provides reliable power transmission and connectivity in harsh environments
Current Rating 10A per contact

Contact Resistance 5m
Shell Material Zinc alloy with nickel plating
Flame Retardant Level UL94 V-0
Connector Gender Female
Environmental Compliance RoHS Compliant
Sealing Method Silicone O-ring gasket
Contact Material Gold-plated brass contacts for enhanced conductivity
Mating Connector LP24 10-pin male plug (compatible)
Insulation Resistance >2000M (at 500V DC)
Mounting Type Panel mount with screw fastening
Number of Pins 10-pin
Mechanical Endurance >500 mating cycles
Cable Entry Size M20 x 1.5 (cable gland compatible)
Locking System Threaded metal locking ring

LP24 400V 10A 10Pin Female Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:400V
Insertion and extraction force:22N Max
Withstanding voltage:2000V
Wire Gauge:1.01.5mm/18 -16AWG
Temperature and humidity:-40+80C; 40C, 85%RH
Mating cycle:1700 times
Screw torque:42-53 (N·m)

Rugged Waterproof Power Connection

Engineered for reliability, the LP24 Female Socket features a robust metal shell and advanced sealing to provide IP67-rated resistance to water and dust. This makes it the ideal solution for critical power connections in automation, outdoor, and industrial environments.

Enhanced Conductivity and Durability

Gold-plated brass contacts ensure excellent electrical performance and reduced resistance, while the sturdy zinc alloy shell with nickel plating protects against corrosion, vibration, and physical impact over extensive use-exceeding 500 mating cycles.

Easy and Secure Panel Mount Installation

The connector's panel mount design with screw fastening allows for straightforward installation. A threaded metal locking ring and compatible cable gland (M20 x 1.5) ensure a secure and vibration-resistant fit, maintaining stable connections even in harsh operation conditions.

FAQ's of LP24 400V 10A 10Pin Female Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal:

Q: How is the LP24 10-pin female socket installed on a panel?

A: Installation involves mounting the connector onto a panel using screw fastenings and a threaded metal locking ring. The panel is prepared with an appropriately sized cutout, and the included silicone O-ring ensures a watertight seal when the socket is secured in place.

Q: What environments is the LP24 10-pin female socket suitable for?

A: This connector is designed for heavy duty equipment, automation systems, machinery, and outdoor power distribution. It is ideal for harsh environments thanks to its IP67 waterproof and dustproof rating, as well as resistance to corrosion and vibration.

Q: When should I use the LP24 connector instead of standard power connectors?

A: Use the LP24 for applications demanding higher durability, enhanced protection against water and dust, and reliable performance in environments subject to mechanical stress, vibration, or frequent mating and unmating.

Q: What benefits does gold-plated contact material provide?

A: Gold-plated brass contacts offer superior conductivity, reducing contact resistance and ensuring efficient power transmission. The plating also resists oxidation and corrosion, significantly extending the connector's operational life.

Q: How does the waterproof sealing work in the LP24 socket?

A: A silicone O-ring gasket provides the primary waterproof seal between the connector and the mounting panel. Combined with precise manufacturing tolerances and the threaded locking mechanism, it achieves an IP67 rating, ensuring protection even during water immersion.

Q: Where can the LP24 10-pin female socket be sourced in India?

A: This connector is available through various distributors, exporters, importers, manufacturers, traders, and wholesalers across India specializing in industrial electrical components.

Q: What is the maximum electrical capacity per contact pin in the LP24 socket?

A: Each contact pin can handle up to 10A at 400V AC, allowing the connector to efficiently manage high power applications with reliable thermal and electrical performance.
