LP28 35A 3Pin Male Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Screw Terminal

Name: LP28 35A 3Pin Male Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Screw Terminal
Brand: CONNECTOR DEVICES
Price: 1089.0 INR
Availability: InStock

1089.0 INR/Piece

Get a Price/Quote

Product Details:

Components Metal shell, screw terminals, sealing gaskets
Usage Panel mount connection for power distribution
Interface 3 Pin Male Socket, Screw Terminal
Input 3P male screw terminal
Features IP67 waterproof, robust metal shell, anti-vibration, corrosion-resistant
Power Supply Electrical
Power Source External AC/DC supply
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP28 35A 3Pin Male Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Screw Terminal Price And Quantity

Price 1089.0 INR/Piece
Minimum Order Quantity 100 Piece

Connector Gender Male
Durability Mechanical life 500 mating cycles
Sealing Method Silicone O-ring and gasket
Withstand Voltage 1500V AC/1min
Terminal Type Screw terminal
Environmental Protection UV resistant, dustproof
Mounting Type Panel mount using rear locking nut
Contact Resistance 5m
Flame Retardancy UL94-V0 insulator
Wire Size Compatibility 2.5mm2 to 6mm2 (14-10 AWG)
Insulation Resistance 2000M @ 500V DC
Material Zinc alloy shell, copper alloy contacts, PA plastic insulator

LP28 35A 3Pin Male Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Screw Terminal Product Specifications

Capacity 35A at 500V per pin
Dimension (L*W*H) Approx. 63mm x 38mm x 38mm
Components Metal shell, screw terminals, sealing gaskets
Product Type Panel Mount Power Connector Socket
Thickness Shell thickness approx. 2mm
Usage Panel mount connection for power distribution
Interface 3 Pin Male Socket, Screw Terminal
Application Industrial machines, power supplies, automation, heavy equipment
Input 3P male screw terminal
Features IP67 waterproof, robust metal shell, anti-vibration, corrosion-resistant
Current Rating 35A
Rated Voltage 500V AC / DC
Power Supply Electrical
Function Power connection for industrial equipment
Power Source External AC/DC supply
IP Rating IP67
Color Silver + Black
Operating Temperature -40C to +80C
Size Shell size 28mm, contact diameter 3.5mm
Output To external heavy-duty cables or mating connector
Weight Approx. 160g
Supply Voltage 500V max
Frequency 50/60Hz

Connector Gender Male
Durability Mechanical life 500 mating cycles
Sealing Method Silicone O-ring and gasket
Withstand Voltage 1500V AC/1min
Terminal Type Screw terminal
Environmental Protection UV resistant, dustproof
Mounting Type Panel mount using rear locking nut
Contact Resistance 5m
Flame Retardancy UL94-V0 insulator
Wire Size Compatibility 2.5mm2 to 6mm2 (14-10 AWG)
Insulation Resistance 2000M @ 500V DC
Material Zinc alloy shell, copper alloy contacts, PA plastic insulator

LP28 35A 3Pin Male Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Screw Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:500V
Wire Specification:2.5mm5mm/14-12AWG
Line Diameter Range:18mm20mm
Mating Cycle:>500 times
Working Temperature:-4080C
Connection Mode:Quick Plug Connection

Reliable Power Connector for Harsh Environments

Engineered to perform in challenging industrial settings, the LP28 35A 3Pin Male Socket provides a secure and waterproof (IP67) power connection. Its tough metal shell and silicone O-ring sealing protect against dust, water, and vibration, ensuring dependable operation even in outdoor or high-moisture environments. This panel mount connector is UV resistant, corrosion-proof, and meets flame retardancy standards for enhanced safety.

Easy Installation and Versatile Wiring

Featuring screw terminals that accommodate 2.5mm2 to 6mm2 (14-10 AWG) cables and a rear locking nut for panel mounting, this connector is user-friendly for electricians and technicians. The clear marking and robust construction streamline the installation process, making the LP28 ideal for new projects or retrofits in machinery and power distribution panels.

Built for Longevity and Safety

With mechanical life rated at 500 mating cycles, insulation resistance of 2000M, and a withstand voltage of 1500V AC for one minute, the LP28 prioritizes operational safety and durability. Its UL94-V0 flame-retardant insulator adds an extra layer of protection for critical electrical systems in high-demand environments.

FAQ's of LP28 35A 3Pin Male Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Screw Terminal:

Q: How do I install the LP28 3Pin Male Socket on a panel?

A: Installation involves cutting a suitable hole in the panel, inserting the connector from the front, and securing it using the included rear locking nut. Attach your power cables to the internal screw terminals and ensure the silicone O-ring and gaskets are properly seated to maintain the IP67 seal.

Q: What environments is this connector suitable for?

A: This connector is ideal for industrial applications where dust, moisture, UV exposure, and mechanical vibration are concerns. The IP67 rating and robust metal shell make it suitable for both indoor and outdoor use on machinery, power supplies, automation systems, and heavy equipment.

Q: When should I use this connector over other types?

A: Choose the LP28 when you need a high-current (up to 35A) and high-voltage (up to 500V AC/DC) connection with secure panel mounting and reliable environmental sealing. Its screw terminals allow for flexible wire sizes, making it a preferred choice for heavy-duty or outdoor electrical projects.

Q: What is the wire size compatibility for the screw terminals?

A: The LP28 3Pin Male Socket supports copper cables between 2.5mm2 and 6mm2 (14-10 AWG), accommodating a range of heavy-duty wires typically used in industrial power distribution.

Q: Where can this power connector be applied?

A: This connector is widely used in industrial machines, automation equipment, power panels, heavy vehicles, and electrical distribution systems, especially where protection from water, dust, and UV is critical.

Q: What are the key benefits of using the LP28 35A 3Pin connector?

A: Benefits include excellent durability, high electrical performance, easy screw-terminal wiring, quick panel installation, IP67 protection from water and dust, UV resistance, and flame-retardant construction. These features contribute to safety and reliability in harsh environments.
