LP20 10A 5Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal

Name: LP20 10A 5Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 515.0 INR
Availability: InStock

515.0 INR/Piece

Get a Price/Quote

Product Details:

Usage Outdoor and Industrial Equipment Connection
Power Source Wired Power Connection
Power Supply Electrical
Output Panel-Mount Electrical Output
Operating Temperature -40C to +80C
IP Rating IP67
Interface Solder Terminal
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP20 10A 5Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 515.0 INR/Piece

LP20 10A 5Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal Product Specifications

Dimension (L*W*H) Approx. 41mm (Length) x 28mm (Diameter) x 24mm (Height, Panel Depth)
Thickness Standard Panel Mount Thickness
Supply Voltage Up to 250V AC
Color Metallic Gray
Usage Outdoor and Industrial Equipment Connection
Function Power Connection, Waterproof Electrical Interface
Power Source Wired Power Connection
Power Supply Electrical
Capacity 10A Max Current Capacity
Output Panel-Mount Electrical Output
Current Rating 10A Max
Frequency 50/60 Hz
IP Rating IP67
Size M20 Panel Cutout (20mm)
Interface Solder Terminal
Rated Voltage 250V AC
Application LED Lighting, Electric Machinery, Engineering Automation
Operating Temperature -40C to +80C
Input 5-Pin Female Socket
Weight Approx. 55g
Features Waterproof, Dustproof, Robust Metal Housing, Screw Lock
Components Connector Body, Solder Terminals, Panel Mount Fastener
Product Type Female Power Connector

Number of Pins 5 Pins
Contact Resistance 5m
Compliance RoHS Compliant
Mounting Type Front Panel Mount
Mechanical Durability > 500 Mating Cycles
Contact Material Copper Alloy with Gold Plating
Packing Individual Polybag
Flame Retardant Grade UL94-V0
Connection Type Solder Terminal
Model Number LP20-10A-5Pin-Female-Panel-Socket
Panel Mount Hole Diameter 20mm
Shell Material Zinc Alloy with Nickel Plating
Insulation Resistance > 2000M at 500V DC
Locking Mechanism Bayonet/Screw Lock
Sealing Method Silicone Rubber Gasket

LP20 10A 5Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:400V
Withstanding voltage:2500V
Mating cycle:1700 Times
Temperature and humidity:-40+80C; 40C, 85%RH
Contact dimension:Phi 2.7x3
Screw torque:42-53 (N.m)

Rugged Design for Demanding Environments

Built with a solid zinc alloy shell and gold-plated contacts, the LP20-10A-5Pin-Female-Panel-Socket provides exceptional durability and corrosion resistance. Its waterproof IP67 rating and silicone rubber gasket offer excellent protection against dust and moisture, making it perfect for outdoor usage and industrial equipment.

Reliable Electrical Performance

Engineered for performance, this connector supports up to 10A current and 250V AC supply voltage. With low contact resistance and high insulation resistance, it delivers consistent electrical reliability and safety. The connector's flame retardant design and compliance with RoHS standards further enhance its quality.

Easy Installation and Versatile Application

The front panel mount and solder terminals facilitate straightforward integration into systems. Suitable for LED lighting, electric machinery, and automation projects, it provides a secure connection with simple bayonet/screw locking mechanics. Its flexible usage makes it ideal for manufacturers, distributors, and installers.

FAQ's of LP20 10A 5Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal:

Q: How is the LP20 10A 5Pin Female Socket installed on panels?

A: This panel-mount socket is installed from the front side of the panel using a 20mm hole cutout. The assembly secures quickly with the supplied fastener and a bayonet or screw lock mechanism, ensuring robust mounting and reliable sealing for waterproof performance.

Q: What benefits does the IP67 waterproof rating provide?

A: The IP67 rating guarantees that the connector remains fully protected against dust ingress and can withstand immersion in water up to 1 meter for 30 minutes. This is particularly beneficial for outdoor installations and machinery exposed to harsh or wet environments.

Q: When should I use this connector instead of standard ones?

A: Use this connector when your application requires high current capacity up to 10A, secure and waterproof electrical connections, and mechanical durability for repeated connections, such as in LED lighting, electric machinery, and automation systems.

Q: Where is the LP20-10A-5Pin-Female-Panel-Socket typically used?

A: This connector is widely used in outdoor equipment, engineering automation setups, industrial electrical cabinets, LED lighting systems, and various electric machinery requiring safe, waterproof, and robust power connections.

Q: What is the process for wiring this connector?

A: Wiring is done using solder terminals provided inside the metal housing. Simply insert each wire into the matching pin location, solder securely, and then attach the connector to your panel while ensuring the silicone rubber gasket is in place for waterproof sealing.

Q: What are the main benefits of using a metal shell with nickel plating and gold-plated contacts?

A: The metal shell with nickel plating delivers excellent mechanical strength, corrosion and impact resistance. Gold-plated contacts offer superior electrical conductivity and minimize oxidation, ensuring highly reliable and long-lasting power transmission.
