LP20 20A 4Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal

Name: LP20 20A 4Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 492.0 INR
Availability: InStock

492.0 INR/Piece

Get a Price/Quote

Product Details:

IP Rating IP67
Components Female socket, flange mount, metal shell, solder terminals
Output Solder terminals (4-pin female)
Features Waterproof, dustproof, corrosion resistant, metal housing, secure connection
Power Source Panel mount or device powered
Power Supply Not applicable (connector only)
Usage Suitable for outdoor or harsh environment power connections
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP20 20A 4Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 492.0 INR/Piece

Mounting Type Flange mount (panel mount)
Material Metal shell with engineering thermoplastic insert
Contact Material Copper alloy with gold plating
Connector Type Female socket
Locking Mechanism Bayonet lock
Pin Arrangement 4-pin
Shell Protection Corrosion and impact resistant metal shell
Sealing Double O-ring design
Flammability Rating UL94-V0 insulator

LP20 20A 4Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Product Specifications

Color Black and silver
Power Supply Not applicable (connector only)
Function Power connector for electrical and electronic equipment
Usage Suitable for outdoor or harsh environment power connections
Size Panel cut-out diameter approx. 24mm
Power Source Panel mount or device powered
Operating Temperature -40C to +80C
Product Type Flange mount power connector socket
Supply Voltage Up to 500V AC/DC
Application Industrial equipment, lighting, stage equipment, automation
Frequency 50/60Hz (as per connected supply)
Rated Voltage 500V AC/DC
Capacity 20A 4-pin connection
Interface 4 Pin (Female socket), solder terminal
Input Solder terminals (4-pin female)
Components Female socket, flange mount, metal shell, solder terminals
Current Rating 20A
Dimension (L*W*H) 40mm x 29mm x 29mm (approximate overall size)
Output Solder terminals (4-pin female)
IP Rating IP67
Features Waterproof, dustproof, corrosion resistant, metal housing, secure connection
Weight Approx. 38 grams

Mounting Type Flange mount (panel mount)
Material Metal shell with engineering thermoplastic insert
Contact Material Copper alloy with gold plating
Connector Type Female socket
Locking Mechanism Bayonet lock
Pin Arrangement 4-pin
Shell Protection Corrosion and impact resistant metal shell
Sealing Double O-ring design
Flammability Rating UL94-V0 insulator

LP20 20A 4Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:500V
Withstanding voltage:2500V
Mating cycle:1700 Times
Contact resistance:< 1.0mOhm
Temperature and humidity:-40+80C; 40C, 85%RH
Contact dimension:Phi 2.7x3

Seamless Integration and Secure Fit

Thanks to its flange-mount design and bayonet locking mechanism, the LP20 4Pin Female Socket guarantees a strong, vibration-resistant connection. Its double O-ring seals and corrosion-resistant metal shell make it perfectly suited for outdoor or harsh industrial environments that demand sturdy power distribution.

Superior Protection and Reliability

Designed for harsh conditions, this connector features an IP67 waterproof rating and UL94-V0 flame resistance for maximum safety. The gold-plated contacts further ensure excellent conductivity and minimal power loss, even in challenging settings such as automation lines or stage equipment.

Versatile Applications and Easy Installation

Ideal for industrial machinery, lighting setups, and automated systems, this connector supports 20A at up to 500V AC/DC. Solder terminals allow for straightforward connection, making it a preferred choice among engineers, electricians, and technicians throughout India and globally.

FAQ's of LP20 20A 4Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal:

Q: How does the LP20 20A 4Pin Female Socket ensure a secure connection?

A: This connector features a bayonet locking mechanism and flange mount design, delivering a reliable, vibration-resistant connection that stays secure even in demanding operational environments.

Q: What types of applications is this socket suitable for?

A: The LP20 4Pin Female Socket is ideal for industrial equipment, outdoor lighting, stage setups, automation systems, and any application requiring a high-current, waterproof, and dustproof power connection.

Q: When should I consider using an IP67-rated power connector?

A: You should use an IP67-rated connector like this when connections may be exposed to water, dust, or extreme weather, such as in outdoor installations, factory automation, or rugged environment applications.

Q: Where can this connector be installed?

A: Designed for flange (panel) mounting, this socket can be installed on equipment enclosures, control panels, or any compatible flat surface with a 24mm cut-out.

Q: What is the process for connecting wires with this socket?

A: Wires are attached to the LP20 4Pin Female Socket by soldering them onto the internal solder terminals, ensuring a stable and low-resistance electrical connection.

Q: What benefits does the metal shell and double O-ring seal provide?

A: The metal shell offers exceptional corrosion and impact resistance, while the double O-ring seal guarantees a watertight and dustproof fit, ensuring reliable performance in harsh environments.

Q: What safety features are included in this connector?

A: Its UL94-V0 flame-resistant insulator, corrosion-resistant housing, gold-plated contacts, and IP67 sealing together provide comprehensive safety against fire, moisture, and environmental hazards.
