LP20 500V 10A 7Pin Female Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal

Name: LP20 500V 10A 7Pin Female Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 687.0 INR
Availability: InStock

687.0 INR/Piece

Get a Price/Quote

Product Details:

Usage Power connector for industrial equipment and outdoor applications
Output Up to 500V, 10A
Features Waterproof, dustproof, robust plastic and metal shell, easy-to-install solder terminal
Interface 7-pin female, solder type
Input Up to 500V, 10A
Power Source External Power Supply
Power Supply AC/DC
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP20 500V 10A 7Pin Female Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal Price And Quantity

Price 687.0 INR/Piece
Minimum Order Quantity 100 Piece

LP20 500V 10A 7Pin Female Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal Product Specifications

IP Rating IP67
Supply Voltage 500V Max
Weight Approx. 38g
Components Plastic body, metal shell, solder terminals
Rated Voltage 500V
Size LP20 standard size (Plug diameter ~20mm)
Function Waterproof electrical connection for power transmission
Product Type Female Power Plug
Application Power distribution, automation equipment, LED lighting, machinery
Operating Temperature -25C to +85C
Thickness Shell thickness approx. 2 mm
Features Waterproof, dustproof, robust plastic and metal shell, easy-to-install solder terminal
Dimension (L*W*H) Approx. 77mm length x 28mm diameter
Output Up to 500V, 10A
Usage Power connector for industrial equipment and outdoor applications
Interface 7-pin female, solder type
Power Source External Power Supply
Input Up to 500V, 10A
Capacity 10A per pin max
Frequency 50/60Hz
Power Supply AC/DC
Current Rating 10A
Color Black/Blue

Shell Material Plastic (PA66) with metal ring
Insulation Resistance 2000M @ 500V DC
Locking Mechanism Threaded coupling
Withstanding Voltage 1500V AC/min
Contact Material Copper alloy, gold plated contacts
Connection Method Solder terminals
Environmental Protection IP67 Waterproof, dustproof
Mounting Type Panel mount or cable mount
Contact Resistance 5m
Flame Retardant Rating UL94-V0
Number of Pins 7 pin
Cable Range 5-9mm
Connector Series LP20

LP20 500V 10A 7Pin Female Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting Mode:Latching Lock connect
Cable Specification:1.01.5mm/18-16AWG
Diameter Range:7mm 10mm
Operating Voltage:500V
Withstand Voltage(AC.V)1min:2500V
Durability:>1500 mating & unmating cycles

Rugged and Reliable Waterproof Design

Built to handle tough environmental conditions, the LP20 power connector features an IP67 waterproof and dustproof rating. Its robust PA66 plastic construction with a reinforced metal ring ensures longevity while maintaining strong electrical contact integrity. Whether used indoors or outdoors, it safeguards power transmission even in harsh industrial or outdoor settings.

Versatile Connection Options

This connector offers flexible mounting, supporting both panel and cable configurations. With solder terminals and a threaded coupling mechanism, installation is simple, secure, and vibration-resistant. Suitable for cables with a diameter range of 5-9mm, it adapts effortlessly to your system's requirements.

Optimized for Industrial Applications

Engineered for demanding applications, the LP20 connector is ideal for power distribution, automation equipment, LED lighting, and machinery. Its UL94-V0 flame retardant rating and withstanding voltage of 1500V AC/min provide enhanced safety and reliability, making it suitable for critical and high-power industrial operations.

FAQ's of LP20 500V 10A 7Pin Female Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal:

Q: How is the LP20 7-pin female plug typically installed?

A: The LP20 connector can be installed through panel mounting or direct cable mounting. Its solder terminal design requires connecting wires via soldering to each pin, and the threaded coupling ensures a secure and waterproof fit.

Q: What applications are suitable for this power connector?

A: This connector is ideal for use in industrial power distribution, automation equipment, LED lighting, and outdoor machinery. Its robust waterproof and dustproof construction makes it suitable for environments exposed to moisture and dust.

Q: When should I choose the LP20 7-pin connector over other connectors?

A: The LP20 is preferable when you need a reliable, waterproof, and dustproof connection for transmitting power (up to 500V, 10A) in industrial or outdoor environments, or where flame retardancy and ruggedness are essential.

Q: Where can this connector be used in terms of environmental conditions?

A: With an IP67 rating and operating temperature range from -25C to +85C, the LP20 connector can be used in both indoor and outdoor settings exposed to water, dust, and varying temperatures, such as factories, construction sites, or outdoor installations.

Q: What is the process for connecting wires to the LP20 connector?

A: Wires should be stripped appropriately and soldered to the individual gold-plated copper alloy pins. The connector's threaded mechanism then secures the joining parts, maintaining a waterproof seal.

Q: What are the key benefits of using the LP20 connector?

A: Key benefits include high reliability under harsh conditions, easy and secure installation, gold-plated contacts for minimal resistance, strong waterproof and dustproof protection, and compliance with stringent flame retardant standards (UL94-V0).

Tell us about your requirement

Price:

Quantity

Select Unit

50
100
200
250
500
1000+

Additional detail

Mobile number
