LP20 500V 12A 5Pin Female Inline IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal

573.0 INR/Piece

Get a Price/Quote

Product Details:

Input Solder Terminal
Output Solder Terminal
IP Rating IP67
Operating Temperature -25C to +85C
Power Source Wired
Features Waterproof, Dustproof, Corrosion Resistant, Easy Installation, Robust Plastic+Metal Construction
Power Supply Hardwired/Electrical
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP20 500V 12A 5Pin Female Inline IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 573.0 INR/Piece

Mating Cycles >500
Withstand Voltage 2500V AC (1 min)
Connector Gender Female
Number of Contacts 5 Pins
Flame Retardancy UL94V-0
Connector Type Inline Female, Circular
Insulation Resistance >2000 M at 500VDC
Mounting Type Inline, Cable Mount
Contact Material Copper Alloy, Gold Plated
Contact Resistance 2.5 m
Environmental Protection UV Resistant, Chemical Resistant
Sealing Method Threaded Coupling, O-Ring Seal
Maximum Wire Gauge Up to 2.5mm2
Cable Diameter Range 6mm-12mm
Shielding Unshielded
Shell Material High Performance Thermoplastic and Metal

LP20 500V 12A 5Pin Female Inline IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal Product Specifications

Function Power Connection and Distribution
Input Solder Terminal
Color Black and Silver
Weight Approx. 35g
Capacity 12A
Product Type Female Inline Power Connector
Size 20mm Series Shell
Current Rating 12A
Frequency 50/60 Hz
Power Supply Hardwired/Electrical
Supply Voltage 500V AC/DC
Application Industrial Equipment, Outdoor Power Devices, LED Lighting, Automation
Thickness Approx. 30mm (Body Diameter)
Rated Voltage 500V AC/DC
Components Plastic+Metal Shell, Solder Pins
Interface 5 Pin Female, Solder Terminal
Usage Industrial, Outdoor Power Interconnect
Output Solder Terminal
Operating Temperature -25C to +85C
IP Rating IP67
Dimension (L*W*H) Approx. 85mm (Length) x 29mm (Diameter)
Power Source Wired
Features Waterproof, Dustproof, Corrosion Resistant, Easy Installation, Robust Plastic+Metal Construction

Mating Cycles >500
Withstand Voltage 2500V AC (1 min)
Connector Gender Female
Number of Contacts 5 Pins
Flame Retardancy UL94V-0
Connector Type Inline Female, Circular
Insulation Resistance >2000 M at 500VDC
Mounting Type Inline, Cable Mount
Contact Material Copper Alloy, Gold Plated
Contact Resistance 2.5 m
Environmental Protection UV Resistant, Chemical Resistant
Sealing Method Threaded Coupling, O-Ring Seal
Maximum Wire Gauge Up to 2.5mm2
Cable Diameter Range 6mm-12mm
Shielding Unshielded
Shell Material High Performance Thermoplastic and Metal

LP20 500V 12A 5Pin Female Inline IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting Mode:Quickly bayonet connect
Cable Specification:1.0mm2 1.5mm2 /1816AWG
Diameter Range:7mm 9mm
Operating Voltage:500V
Durability:> 500 mating & unmating cycles
Temperature Rating:-40C80C

Rugged Waterproof Design

With an IP67 rating and robust construction combining thermoplastic and metal, the LP20 connector provides exceptional protection in challenging environments. Its waterproof, dustproof, and UV-resistant features ensure reliable performance outdoors or in industrial settings, keeping connections secure and protected from contaminants.

Easy Installation & Secure Connections

The inline female circular connector uses threaded coupling and an O-ring seal for a quick and safe assembly, minimizing installation effort and reducing the risk of accidental disconnection. Solder terminals support strong wire attachment, rated for over 500 durable mating cycles.

Versatile Industrial and Outdoor Applications

Designed for use in industrial equipment, automation systems, and outdoor electronics-including LED lighting and power distribution-the LP20 ensures steady performance at 500V/12A. Its wide cable diameter compatibility and flame-retardant housing make it ideal for demanding professional settings.

FAQ's of LP20 500V 12A 5Pin Female Inline IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal:

Q: How do I install the LP20 5Pin female inline waterproof connector?

A: To install this connector, prepare your cable with up to 2.5mm2 wires and 6-12mm diameter. Insert the cable through the rear shell, solder your wires to the numbered copper alloy contacts, attach the O-ring, and thread the shell securely, ensuring a tight IP67 seal.

Q: What environments is this connector suitable for?

A: The LP20's IP67 rating, UV and chemical resistance, and operating temperature of -25C to +85C make it suitable for outdoor, industrial, and automation applications, especially where exposure to moisture, dust, or harsh chemicals is expected.

Q: When should I use a 5-pin inline female connector like the LP20?

A: This connector is ideal when you need robust power distribution or control in equipment or lighting requiring up to 12A at 500V, particularly where reliability, weatherproofing, and long-life mating cycles are important.

Q: Where is this connector commonly used?

A: It's commonly used in industrial machinery, automation systems, outdoor lighting (such as LED fixtures), and any application where durable, waterproof power connections are essential.

Q: What are the benefits of its plastic and metal shell construction?

A: Combining thermoplastic and metal in the shell offers enhanced mechanical strength, corrosion resistance, and superior flame retardancy (UL94V-0), making the connector resilient against physical impact and environmental hazards.

Q: How does the LP20 ensure secure electrical contact and long-lasting performance?

A: The gold-plated copper alloy contacts maintain low contact resistance (2.5m), high insulation resistance (>2000M at 500VDC), and sustain over 500 mating cycles, ensuring reliable power transmission and connection longevity.

Q: What is the process and benefit of the threaded coupling and O-ring seal?

A: The threaded coupling combined with the O-ring seal ensures a secure mechanical lock while providing a watertight barrier, which protects the contact area from dust, moisture, and contaminants, thereby extending the connector's operational lifespan.
