YM20 20A 2Pin Male Plug IP68 Waterproof Power Connector Plastic Shell Solder Terminal

Name: YM20 20A 2Pin Male Plug IP68 Waterproof Power Connector Plastic Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 343.0 INR
Availability: InStock

343.0 INR/Piece

Get a Price/Quote

Product Details:

Input 2-Pin Male Solder Terminal
Components Plastic shell, internal solder terminals, sealing ring
IP Rating IP68
Output 2-Pin Male Output
Operating Temperature -25C to +85C
Power Source Wired Electric
Interface 2 Pin Solder Terminal
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YM20 20A 2Pin Male Plug IP68 Waterproof Power Connector Plastic Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 343.0 INR/Piece

Mating Style Threaded coupling
Insulation Resistance >1000M at 500V DC
Mounting Type Inline cable mount
Contact Resistance 5m
Cable Outer Diameter Supported 6mm to 12mm
Flame Retardancy UL94V-0
Shell Material High-Strength Plastic (PA66)
Contact Material Brass with gold plating
Connector Gender Male Plug
Mechanical Life >500 mating cycles
Sealing Method O-ring and gland nut sealing

YM20 20A 2Pin Male Plug IP68 Waterproof Power Connector Plastic Shell Solder Terminal Product Specifications

Capacity 20A Current Capacity
Dimension (L*W*H) Approx. 89 mm x 28 mm x 28 mm
Power Source Wired Electric
Operating Temperature -25C to +85C
Size YM20 (20mm shell diameter)
Input 2-Pin Male Solder Terminal
Components Plastic shell, internal solder terminals, sealing ring
Application Led lighting, industrial automation, power and signal transmission
Color Black
Thickness Shell Thickness Approx. 2mm
Function Power Connector
Usage For outdoor/industrial power connections
Weight Approx. 75g
Rated Voltage 500V AC/DC
Output 2-Pin Male Output
Power Supply Electrical
Supply Voltage Up to 500V
Current Rating 20A
Product Type Power Connector Plug
IP Rating IP68
Interface 2 Pin Solder Terminal
Features Waterproof, Dustproof, Corrosion resistant, Easy installation
Frequency 50/60Hz

Mating Style Threaded coupling
Insulation Resistance >1000M at 500V DC
Mounting Type Inline cable mount
Contact Resistance 5m
Cable Outer Diameter Supported 6mm to 12mm
Flame Retardancy UL94V-0
Shell Material High-Strength Plastic (PA66)
Contact Material Brass with gold plating
Connector Gender Male Plug
Mechanical Life >500 mating cycles
Sealing Method O-ring and gland nut sealing

YM20 20A 2Pin Male Plug IP68 Waterproof Power Connector Plastic Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:500V
Withstanding voltage:2500V
Insertion and extraction force:4.0N Max
Screw torque:42-53 (N.m)
Mating cycle:1700 Times
Temperature and humidity:-4080C; 40C, 85%RH
Contact dimension:Phi 2.7*2

Rugged Waterproof Design

The connector's IP68 rating, O-ring, and gland nut sealing make it highly resistant to water and dust. This reliability extends operating possibilities, ensuring steadfast power and signal transmission in adverse environments for outdoor and industrial use.

High-Performance Materials

Featuring a high-strength PA66 plastic shell and gold-plated brass contacts, the YM20 connector ensures optimal conductivity, corrosion resistance, and long-lasting performance. Its flame-retardant structure offers enhanced safety in demanding applications.

Versatile Mounting & Applications

Designed for easy installation on cables sized 6mm to 12mm, this inline male plug suits a variety of power and signal needs. It's a go-to solution for LED lighting, automation systems, and other industrial uses demanding robust, dependable connections.

FAQ's of YM20 20A 2Pin Male Plug IP68 Waterproof Power Connector Plastic Shell Solder Terminal:

Q: How does the YM20 20A 2Pin Male Plug ensure waterproof and dustproof performance?

A: The YM20 connector uses an IP68-rated design with O-ring and gland nut sealing to provide complete protection against water ingress and dust, making it suitable for harsh outdoor and industrial operational conditions.

Q: What is the process for installing the YM20 male plug on a cable?

A: Installation involves soldering your wires to the internal 2-pin terminals, then securing the cable with the threaded coupling, O-ring, and gland nut to ensure a tight, waterproof seal for cable diameters between 6mm and 12mm.

Q: When should I use the YM20 connector in my power or signal transmission projects?

A: Choose the YM20 connector when you require reliable, waterproof connections for outdoor lighting, industrial automation, power distribution, or any setting where protection from moisture and dust is vital.

Q: Where can the YM20 2Pin Male Plug be utilized effectively?

A: This connector is ideal for environments such as outdoor LED lighting, industrial machinery, automation systems, marine applications, and any location where strong, weatherproof electrical connections are essential.

Q: What are the benefits of using a connector with a PA66 plastic shell and gold-plated brass contacts?

A: The PA66 plastic shell offers exceptional mechanical strength and flame retardancy, while gold-plated brass contacts ensure superior conductivity and resistance to corrosion, resulting in enhanced durability and reliable long-term performance.

Q: How reliable is the YM20 plug over repeated usage cycles?

A: The YM20 connector is designed for more than 500 mating cycles, ensuring sustained performance and reliability even with frequent connections and disconnections over its service life.
