YU-USB USB2.0 Female-Female Plug IP67 Waterproof Data Connector

271.0 INR/Piece

Get a Price/Quote

Product Details:

Features Waterproof, dustproof, corrosion-resistant, panel mount
Usage Waterproof USB data connection
Interface USB 2.0 Female-Female
Charging Voltage 5V
IP Rating IP67
Input USB 2.0 Female
Components Housing, cap, sealing ring, contacts
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YU-USB USB2.0 Female-Female Plug IP67 Waterproof Data Connector Price And Quantity

Price 271.0 INR/Piece
Minimum Order Quantity 100 Piece

Insulation Resistance 1000M at 500V DC
Cap Included Yes
Connector Gender Female-Female
Sealing Method Rubber O-ring gasket and sealing cap
Compatibility Compatible with USB 1.1 and USB 2.0 devices
Environmental Protection UV resistant
Cable Length Not applicable (connector only)
Material High-strength plastic, gold-plated contacts
Flame Retardant Grade UL94-V0
Contact Resistance 30m
Mounting Type Panel mount with locking nut

YU-USB USB2.0 Female-Female Plug IP67 Waterproof Data Connector Product Specifications

Thickness Standard USB thickness
Supply Voltage 5V DC (USB standard)
Rated Voltage 250V AC
Application Outdoor USB connectivity, industrial control, data transfer
Interface USB 2.0 Female-Female
Product Type Waterproof USB connector
Usage Waterproof USB data connection
Features Waterproof, dustproof, corrosion-resistant, panel mount
Components Housing, cap, sealing ring, contacts
Current Rating 1.5A max (USB 2.0)
Input USB 2.0 Female
Capacity Supports data up to 480Mbps
IP Rating IP67
Weight 28g
Dimension (L*W*H) Approx. 58mm x 22mm x 22mm
Size Standard panel mount size
Charging Voltage 5V
Output USB 2.0 Female
Color Black
Power Supply USB-powered
Function Data transfer and connectivity
Operating Temperature -20C to +60C
Power Source USB powered

Insulation Resistance 1000M at 500V DC
Cap Included Yes
Connector Gender Female-Female
Sealing Method Rubber O-ring gasket and sealing cap
Compatibility Compatible with USB 1.1 and USB 2.0 devices
Environmental Protection UV resistant
Cable Length Not applicable (connector only)
Material High-strength plastic, gold-plated contacts
Flame Retardant Grade UL94-V0
Contact Resistance 30m
Mounting Type Panel mount with locking nut

YU-USB USB2.0 Female-Female Plug IP67 Waterproof Data Connector Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Mating Cycles:500
Dielectric Withstanding Voltage:500V/AC
Receptacle Housing:PBT, Black
Connection mode:Quick bayonet connection
Contact:Copper Alloy
Coupling Ring:PA66, Black
Standard:USB2.0

Superior Environmental Protection

Engineered to withstand challenging conditions, the YU-USB connector features IP67 waterproofing, UV resistance, and a flame-retardant housing. The use of a rubber O-ring gasket and sealing cap secures the panel mount against dust and moisture, making it ideal for outdoor installations or industrial environments that demand reliable and long-lasting connections.

Efficient Data Transfer and Versatile Application

With USB 2.0 compatibility and support for data speeds up to 480Mbps, this female-to-female connector easily integrates into data transfer systems requiring secure, rapid communication. The connector is perfect for situations where waterproof USB connections are essential, such as in outdoor controllers, information panels, or industrial equipment.

Durable and Reliable Design

Built using high-strength plastic and gold-plated contacts, the YU-USB connector ensures durability, corrosion resistance, and excellent conductivity. It boasts a flame retardant grade of UL94-V0 and a secure locking nut mounting, delivering long service life and reliable operation even in demanding settings.

FAQ's of YU-USB USB2.0 Female-Female Plug IP67 Waterproof Data Connector:

Q: How does the YU-USB USB2.0 Female-Female Plug ensure waterproofing and dustproofing?

A: This connector features an IP67 rating, achieved via a robust rubber O-ring gasket and a sealing cap. These components work together to prevent water and dust ingress, ensuring reliability in both indoor and outdoor applications.

Q: What types of environments are suitable for installing this USB connector?

A: The YU-USB connector is designed for environments that require resilience to water, dust, extreme temperatures, and UV exposure, such as outdoor setups, industrial panels, and automation control systems.

Q: When should I use a panel mount USB connector like this model?

A: A panel mount USB connector is ideal when a stable, tamper-resistant, and waterproof USB connection is necessary-commonly required in industrial equipment, outdoor digital displays, or any setting needing permanent installation and environmental protection.

Q: What is the process for installing the YU-USB connector?

A: To install, mount the connector onto a panel using the supplied locking nut. Then, insert the O-ring gasket for sealing and attach the cap when not in use to maintain its IP67 rating. No cable assembly is needed as this model is designed specifically for direct panel mounting.

Q: How is data transferred and devices powered with this connector?

A: Data is transferred at rates up to 480Mbps (USB 2.0 standard) between two USB devices through the female-to-female ports. It supports USB-powered devices with a rated voltage of 5V DC and a current rating of up to 1.5A.

Q: What are the main benefits of using the YU-USB Female-Female Plug?

A: The primary advantages include robust waterproofing, dust and UV resistance, fast data transfer, easy panel mounting, and long-lasting durability provided by high-strength materials and gold-plated contacts.
