LP20 500V 12A 5Pin Female Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal

Name: LP20 500V 12A 5Pin Female Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 521.0 INR
Availability: InStock

521.0 INR/Piece

Get a Price/Quote

Product Details:

Output To compatible 5-pin male connector
Components Metal shell, 5 solder terminals, sealing gasket
Usage Industrial, outdoor, waterproof power applications
IP Rating IP67 (waterproof, dustproof)
Input 5-pin female socket
Power Supply Panel mount or cable connection
Features Metal body, IP67 waterproof, corrosion-resistant, secure locking
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP20 500V 12A 5Pin Female Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 521.0 INR/Piece

LP20 500V 12A 5Pin Female Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal Product Specifications

Interface Solder terminal, 5-pin
Capacity 12A per pin
Weight Approx. 40g
Function Power connection in harsh or outdoor environments
Dimension (L*W*H) Approx. 33mm diameter panel mounting
Operating Temperature -40C to +80C
Thickness Standard panel thickness: 2-6 mm
Product Type Waterproof Power Connector Socket
Frequency 50/60Hz supported
Color Black and metallic silver
Application Industrial machinery, automation, LED lighting, power distribution
Power Source External/cable supplied
Supply Voltage 500V max
Features Metal body, IP67 waterproof, corrosion-resistant, secure locking
Rated Voltage 500V AC/DC
Components Metal shell, 5 solder terminals, sealing gasket
Output To compatible 5-pin male connector
Input 5-pin female socket
Current Rating 12A per pin
Size LP20 Series (See drawing for detailed dimensions)
Power Supply Panel mount or cable connection
Usage Industrial, outdoor, waterproof power applications
IP Rating IP67 (waterproof, dustproof)

Standards Compliance RoHS Compliant
Flame Resistance UL94 V-0 rated insulation
Connector Gender Female socket
Contact Material Copper alloy, gold plated
Mating Cycle Durability More than 500 mating cycles
Shell Material Zinc alloy with nickel plating
Mounting Type Panel mount with nut and gasket included
Sealing Method Rubber gasket and internal sealing ring
Termination Style Solder terminals for secure connection

LP20 500V 12A 5Pin Female Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting Mode:Quickly bayonet connect
Cable Specification:1.0mm2 1.5mm2 /1816AWG
Diameter Range:7mm 9mm
Operating Voltage(AC.V.rms):500V
Withstand Voltage(AC.V)1min:2500V
Durability:>500 mating & unmating cycles
Temperature Rating:-40C80C

Superior Waterproof and Dustproof Protection

Designed with an IP67 rating, the LP20 5-Pin Female Socket withstands immersion in water and complete protection from dust ingress. Its rubber gasket and internal sealing ring ensure optimal sealing, making it a resilient choice for outdoor and challenging industrial applications.

Robust Build for Reliable Performance

Constructed with a zinc alloy shell and nickel plating, this connector offers exceptional resistance to corrosion and mechanical stress. The gold-plated copper alloy contacts sustain up to 12A per pin at 500V, maintaining stable power delivery over more than 500 mating cycles.

Easy Panel Mount Installation

With panel mount customization and a supplied nut and gasket, the LP20 socket can be quickly and securely installed on panels of 2-6mm thickness. Solder terminals enable sturdy wiring for safe, long-lasting connections in industrial settings.

FAQ's of LP20 500V 12A 5Pin Female Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal:

Q: How does the LP20 5-pin female socket ensure a waterproof and dustproof connection?

A: The connector achieves an IP67 rating through an integrated rubber gasket and internal sealing ring. These features prevent water and dust infiltration, making the socket suitable for outdoor and harsh environments.

Q: What is the process for installing this panel mount connector?

A: Installation involves mounting the connector through a panel cutout (2-6mm thickness). Secure it with the included nut and gasket, then solder wires to the provided terminals for a reliable connection.

Q: When should I use this power connector in my application?

A: Use the LP20 5-pin female socket for power distribution in environments exposed to water, dust, or mechanical stress, such as industrial machinery, automation, outdoor LED lighting, or power panels.

Q: What are the benefits of using solder terminals in this connector?

A: Solder terminals offer a solid, vibration-resistant connection that reduces the risk of loose wires in dynamic or rugged settings, ensuring electrical reliability.

Q: Where is this connector most effectively utilized?

A: This connector performs best in industrial settings and outdoor applications where a waterproof, dustproof, and interference-free power connection is essential.

Q: How durable is the LP20 5-pin female socket during repeated connections?

A: The socket supports over 500 mating cycles without compromising performance, thanks to high-quality materials and robust mechanical design.

Tell us about your requirement

Price:

Quantity

Select Unit

50
100
200
250
500
1000+

Additional detail

Mobile number
