LP20 500V 20A 3Pin Female Socket IP67 Waterproof Power Connector

Name: LP20 500V 20A 3Pin Female Socket IP67 Waterproof Power Connector
Brand: CONNECTOR DEVICES
Price: 427.0 INR
Availability: InStock

427.0 INR/Piece

Get a Price/Quote

Product Details:

Power Source Electrics
IP Rating IP67
Rated Voltage 500 Volt (V)
Size Standard
Color Silver + Black
Usage & Applications Waterproof Power Connector Metal Shell Solder Terminal
Material Plastic + Metal
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP20 500V 20A 3Pin Female Socket IP67 Waterproof Power Connector Price And Quantity

Price 427.0 INR/Piece
Minimum Order Quantity 100 Piece

LP20 500V 20A 3Pin Female Socket IP67 Waterproof Power Connector Product Specifications

Frequency 50 Hertz (HZ)
Usage & Applications Waterproof Power Connector Metal Shell Solder Terminal
IP Rating IP67
Rated Voltage 500 Volt (V)
Features Best Quality
Power Source Electrics
Color Silver + Black
Material Plastic + Metal
Size Standard

LP20 500V 20A 3Pin Female Socket IP67 Waterproof Power Connector Trade Information

Supply Ability 1000 Piece Per Month
Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:500V
Withstanding voltage:2500V
Mating cycle:1700 Times
Temperature and humidity:-40+80C; 40C,85%RH
Contact dimension:Phi 2.7x3
Screw torque:42-53 (N.m)

Advanced Waterproof Design

Built to endure harsh environments, the LP20 3-Pin Female Socket boasts an IP67 waterproof rating, ensuring dust tightness and protection against temporary immersion in water. This feature makes the connector perfect for outdoor installations, industrial applications, or any setting where moisture or dust is a concern, guaranteeing safe and uninterrupted power supply.

High Voltage and Amperage Support

With a rated voltage of 500V and current capacity of 20A, the LP20 supports robust power delivery. Its solid construction blends quality plastic with a resilient metal shell, offering both electrical stability and mechanical durability-ideal for situations requiring dependable, long-lasting electrical performance.

FAQ's of LP20 500V 20A 3Pin Female Socket IP67 Waterproof Power Connector:

Q: How do I install the LP20 500V 20A 3Pin Female Socket?

A: The LP20 socket features solder terminals for secure wire connections. Installation involves stripping the wire ends, soldering them to the connector's terminals, and assembling the socket body. Always ensure power is switched off before installation, and follow standard electrical safety procedures.

Q: What environments are suitable for using this waterproof power connector?

A: Thanks to its IP67 rating, this connector is ideal for both indoor and outdoor environments prone to moisture or dust. Common applications include industrial sites, outdoor lighting, and equipment exposed to rain or splashes, where a reliable waterproof connection is essential.

Q: When should I choose this 3-pin connector over other types?

A: Choose the LP20 for projects requiring secure, high-voltage (up to 500V) and high-current (20A) power connections, especially where waterproofing and robust physical protection are necessary. Its durable build is favorable in any setting with significant electrical and environmental demands.

Q: Where can I source the LP20 500V 20A Waterproof Power Connector in India?

A: This product is available through various channels in India, including distributors, wholesalers, exporters, importers, and manufacturers. You can inquire through specialized electrical supply stores or authorized dealers with experience in power connectors and industrial electrical components.

Q: What is the process for ensuring the connector remains waterproof after installation?

A: After soldering and cable assembly, ensure the connector is fully tightened and all gaskets or seals are in place, as per the manufacturer's guidelines. This preserves its IP67 waterproof rating and protects the internal electrical connections from moisture.

Q: How is this connector beneficial for commercial or industrial applications?

A: The LP20 offers reliable high-power transmission, robust mechanical protection, and excellent resistance to water and dust. As a result, it minimizes downtime and maintenance costs in demanding industrial or commercial settings, delivering peace of mind and heightened operational safety.
