LP20 5A 9Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal

410.0 INR/Piece

Get a Price/Quote

Product Details:

Power Source External Power
Interface 9 Pin Female, Solder Type
Operating Temperature -25C to +85C
Output Solder Terminal
Power Supply Electrical
Usage Industrial Power and Signal Connection
Features Waterproof, Flange Mount, Metal Construction, Corrosion Resistant, Secure Locking
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP20 5A 9Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Price And Quantity

Price 410.0 INR/Piece
Minimum Order Quantity 100 Piece

Shell Material Zinc Alloy with Nickel Plating
Locking Method Threaded Coupling
Mating Cycle Durability >500 Cycles
Sealing Method Silicone O-Ring
Connector Type Panel Socket
Insulation Resistance 2,000M at 500V DC
Contact Material Brass with Gold Plating
Wire Size Accepted 20-16 AWG
Mounting Type Flange Mount
Contact Resistance 5m

LP20 5A 9Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Product Specifications

Function Power/Signal Connection
Features Waterproof, Flange Mount, Metal Construction, Corrosion Resistant, Secure Locking
Capacity 5A per contact
Rated Voltage 500V AC
Size 20mm Series
Weight Approximately 35g
Product Type Waterproof Power Connector Socket
Usage Industrial Power and Signal Connection
Frequency 50/60Hz
Power Source External Power
IP Rating IP67
Current Rating 5A Per Pin
Interface 9 Pin Female, Solder Type
Operating Temperature -25C to +85C
Application Outdoor, Industrial Equipment, Automation, LED, Marine, Renewable Energy
Components Metal Shell, 9 Female Pins
Power Supply Electrical
Output Solder Terminal
Input Solder Terminal
Color Metallic Silver
Dimension (L*W*H) Flange Diameter: ~26 mm, Length: ~40 mm
Supply Voltage Up to 500V AC

Shell Material Zinc Alloy with Nickel Plating
Locking Method Threaded Coupling
Mating Cycle Durability >500 Cycles
Sealing Method Silicone O-Ring
Connector Type Panel Socket
Insulation Resistance 2,000M at 500V DC
Contact Material Brass with Gold Plating
Wire Size Accepted 20-16 AWG
Mounting Type Flange Mount
Contact Resistance 5m

LP20 5A 9Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:400V
Withstanding voltage:2500V
Mating cycle:1700 Times
Temperature and humidity:-40+80C; 40C,85%RH
Contact dimension:Phi 2.7x3
Screw torque:42-53 (N.m)

Rugged Waterproof Construction

The LP20 9Pin Female Socket features a robust metal shell made from zinc alloy with nickel plating, providing exceptional durability and corrosion resistance. With its IP67 rating and silicone O-ring sealing, the connector ensures reliable protection against water ingress, making it ideal for outdoor and industrial environments where moisture or dust exposure is a concern.

Versatile Industrial Applications

Engineered for versatility, this connector supports both power and signal transmission in a wide range of industrial equipment, automation systems, marine electronics, LED installations, and renewable energy setups. Its flange mount design and secure threaded coupling provide a stable and vibration-resistant interface, making installation straightforward and long-lasting.

FAQ's of LP20 5A 9Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal:

Q: How does the LP20 5A 9Pin Female Socket achieve waterproof sealing?

A: The connector uses a silicone O-ring in combination with a threaded coupling mechanism, providing an IP67-rated seal that effectively prevents water and dust ingress, making it suitable for outdoor and harsh industrial environments.

Q: What is the process for mounting and connecting the LP20 socket?

A: The LP20 socket is designed for panel mounting using its flange. Electrical wires (20-16 AWG) are soldered to the terminals, and the connector is secured with screws through the flange. The threaded coupling ensures a tight, secure fit with its mating counterpart.

Q: When should I choose a flange mount, metal shell connector like this for my application?

A: A flange mount metal shell connector is ideal when you need secure, vibration-resistant, and watertight connections in environments exposed to moisture, dust, or frequent mechanical stresses, such as outdoor equipment, automation panels, or marine systems.

Q: Where can the LP20 socket be used effectively?

A: This connector excels in settings like outdoor industrial installations, automation systems, marine electronics, LED lighting, and renewable energy projects, thanks to its robust build and waterproof capabilities.

Q: What are the benefits of using gold-plated brass contacts in this connector?

A: The gold-plated brass contacts enhance electrical conductivity and reduce contact resistance (down to 5m), ensuring reliable power and signal transfer while also protecting against oxidation and long-term wear.

Q: How durable is the LP20 9Pin Female Socket during repeated use?

A: It is rated for more than 500 mating cycles, ensuring stable, repeatable connections over extended periods even in demanding environments.
