LP24 150V 5A 24Pin Male Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal

Name: LP24 150V 5A 24Pin Male Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 646.0 INR
Availability: InStock

646.0 INR/Piece

Get a Price/Quote

Product Details:

Input 24-pin male interface
Features Waterproof, dustproof, robust metal shell, corrosion-resistant, screw locking
Interface 24-pin male socket, solder type
Components Metal shell, 24-pole solder terminals, sealing gasket
Power Source External via mating connector
IP Rating IP67
Operating Temperature -40C to 80C
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP24 150V 5A 24Pin Male Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal Price And Quantity

Price 646.0 INR/Piece
Minimum Order Quantity 100 Piece

LP24 150V 5A 24Pin Male Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal Product Specifications

Features Waterproof, dustproof, robust metal shell, corrosion-resistant, screw locking
Input 24-pin male interface
Capacity 24 contacts
Application Power & signal transmission in machinery, lighting, and panel connection
Components Metal shell, 24-pole solder terminals, sealing gasket
Interface 24-pin male socket, solder type
Weight Approx. 120g
Thickness Shell: 2mm
IP Rating IP67
Operating Temperature -40C to 80C
Usage Industrial, Outdoor applications, Automation equipment
Current Rating 5A per contact
Supply Voltage 150V max
Function Power connection and signal transmission in demanding environments
Power Supply Not applicable (Passive connector)
Power Source External via mating connector
Frequency DC or 50/60Hz AC
Color Metallic Silver and Black
Size Standard LP24 series
Dimension (L*W*H) Approx. 47mm x 47mm x 73mm (flange included)
Rated Voltage 150V AC/DC
Product Type Power Connector Socket
Output 24-pin male solder terminal

Mounting Type Panel mount, flanged
Cable Diameter Range 8~12mm
Norm Compliance IEC 61076-2-101, RoHS compliant
Insulation Resistance >5000M @500V DC
Flammability Rating UL94-V0
Contact Material Gold-plated brass
Contact Resistance 2.5m
Seal Material Silicone rubber
Locking Mechanism Threaded screw coupling
Mating Cycle Durability >500 cycles
Shell Material Nickel-plated zinc alloy

LP24 150V 5A 24Pin Male Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:150v
Insertion and extraction force:22N Max
Contact diameter:Phi 1.0x24
Temperature and humidity:-40+80C; 40C, 85%RH
Mating cycle:1700 times
Screw torque:42-53 (Nm)

Superior Environmental Protection

Designed for harsh settings, the LP24 connector offers IP67 waterproof and dustproof sealing. Its silicone rubber gasket and robust metal shell protect against moisture, contaminants, and corrosion, making it reliable for both indoor and extended outdoor use. The nickel-plated finish further enhances durability in demanding applications such as industrial automation, machinery, and lighting.

Secure and Reliable Connection

This connector utilizes a threaded screw locking mechanism for firm coupling during use. It supports over 500 mating cycles, ensuring long service life. The gold-plated brass contacts reduce contact resistance (2.5m), ensuring stable connections and consistent power or signal transmission, even under vibration or mechanical stress in automation and industrial settings.

FAQ's of LP24 150V 5A 24Pin Male Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal:

Q: How is the LP24 24Pin Male Socket typically used in industrial and outdoor applications?

A: The LP24 connector is used for reliable power and signal transmission in machinery, lighting systems, and automation equipment. Its waterproof design and robust shell allow it to operate effectively in demanding environments where exposure to moisture and dust is common.

Q: What makes the LP24 connector suitable for harsh environmental conditions?

A: This connector offers IP67 ingress protection, a robust nickel-plated metal shell, and silicone rubber sealing. These features protect it against dust, water immersion, mechanical impact, and corrosion, ensuring stable performance outdoors or in industrial settings.

Q: When should I choose this connector over other types?

A: Choose the LP24 socket when you require a secure, waterproof, and vibration-resistant connection for transmitting both power and signals in environments prone to dust, moisture, or mechanical stress, such as factories, outdoor lighting, or automation panels.

Q: Where can the LP24 24Pin Male Socket be mounted?

A: The LP24 socket is designed for panel mount using a flanged structure, allowing installation on equipment panels, control boxes, or distribution enclosures common in industrial or automation applications.

Q: What is the process for connecting wires to the terminals of this connector?

A: Wires are soldered directly to the 24 individual terminals inside the connector. After soldering, secure the shell using the threaded screw coupling and ensure the silicone gasket is properly seated for IP67 sealing.

Q: What benefits does the gold-plated brass contact provide?

A: Gold plating on brass contacts minimizes contact resistance, enhances corrosion resistance, and provides stable electrical performance, resulting in improved reliability for both power and signal transmissions.
