YF24 500V 20A 3Pin PowerCON IP67 Waterproof Female Socket Panel Connector Plastic Shell Solder Terminal

Name: YF24 500V 20A 3Pin PowerCON IP67 Waterproof Female Socket Panel Connector Plastic Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 198.0 INR
Availability: InStock

198.0 INR/Piece

Get a Price/Quote

Product Details:

Features Waterproof design, secure locking mechanism, flame-retardant plastic shell, dustproof, vibration resistant
Components Connector body, solder terminals, mounting gasket
Power Source Wired Electrical Power
Output Panel Mount Connection
Input 3-Pin Female Socket
Interface Solder terminal
Operating Temperature -40C to +80C
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YF24 500V 20A 3Pin PowerCON IP67 Waterproof Female Socket Panel Connector Plastic Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 198.0 INR/Piece

YF24 500V 20A 3Pin PowerCON IP67 Waterproof Female Socket Panel Connector Plastic Shell Solder Terminal Product Specifications

Capacity 20A Max current
Frequency 50/60Hz
Supply Voltage 500V AC
Application Stage equipment, LED displays, Industrial power supply, Outdoor applications
IP Rating IP67
Power Supply AC
Usage Electrical power distribution, industrial equipment
Color Black
Weight 30g (approx)
Thickness Panel thickness supported up to 5mm
Dimension (L*W*H) approx. 45mm x 30mm x 27mm
Function Power connector for secure and waterproof AC power transfer
Product Type IP67 PowerCON Panel Connector
Power Source Wired Electrical Power
Output Panel Mount Connection
Components Connector body, solder terminals, mounting gasket
Rated Voltage 500V AC
Size 24mm Diameter Mount
Current Rating 20A
Features Waterproof design, secure locking mechanism, flame-retardant plastic shell, dustproof, vibration resistant
Interface Solder terminal
Operating Temperature -40C to +80C
Input 3-Pin Female Socket

Connector Gender Female
Terminal Type Solder type
Ingress Protection IP67 (dustproof and waterproof)
Flammability Rating UL94-V0
Locking System Twist-lock
Insulation Resistance >1000M
Cable Diameter Compatibility 7-12mm
Contact Material Copper Alloy with Nickel Plating
Number of Pins 3 Pins
Mechanical Life >5000 mating cycles
Dielectric Withstand Voltage 2000V AC/min
Shell Material Flame-retardant Engineering Plastic
Mounting Method Panel Mount with locking nut

YF24 500V 20A 3Pin PowerCON IP67 Waterproof Female Socket Panel Connector Plastic Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting Mode:Fast Locking
Cable Specification:2.5mm2 4mm2 /1412AWG
Diameter Range:8mm 12mm
Operating Voltage:500V
Withstand Voltage(AC.V)1min:2500V
Durability:> 500 mating & unmating cycles
Temperature Rating:-40C80C

Exceptional Electrical Durability and Protection

Engineered for high-demand environments, the YF24 connector's IP67 rating ensures full protection against water and dust intrusion. The flame-retardant shell (UL94-V0) enhances safety, while the robust twist-lock design provides secure connections, even in vibration-prone settings. Its copper alloy contacts resist corrosion and guarantee over 5000 reliable mating cycles.

Versatile Industrial Applications

Whether you're powering stage equipment, LED displays, or industrial machines, this 3-pin connector delivers stable, high-current performance up to 20A at 500V AC. Its panel mount configuration with solder terminals simplifies installation, making it ideal for outdoor events, electrical distribution, and other demanding setups.

FAQ's of YF24 500V 20A 3Pin PowerCON IP67 Waterproof Female Socket Panel Connector Plastic Shell Solder Terminal:

Q: How does the YF24 3Pin PowerCON socket ensure waterproof and dustproof protection?

A: The YF24 socket is built to IP67 standards, meaning its sealed design completely prevents dust ingress and provides robust protection against water, even during temporary immersion. This makes it ideal for outdoor and industrial environments where exposure to moisture and debris is common.

Q: What type of applications is this connector suitable for?

A: This connector is perfect for AC power transfer in applications such as stage equipment, LED displays, industrial power supplies, and any outdoor setup that demands secure, high-current connections in challenging conditions.

Q: When should I use a PowerCON IP67 panel connector instead of a standard power socket?

A: If your environment is exposed to water, dust, vibrations, or you require a highly secure locking system for safety and uninterrupted power, using an IP67-rated PowerCON connector provides superior durability and protection compared to standard sockets.

Q: Where can this panel connector be mounted?

A: The YF24 panel connector is designed for easy installation on control panels, equipment casings, or distribution boxes, supporting mounting on surfaces with up to 5mm thickness. The locking nut and gasket ensure a tight, waterproof fit.

Q: What is the process for wiring the YF24 connector?

A: The connector uses solder terminals: Strip the cable (7-12mm diameter), solder each conductor to the appropriate terminal, then mount the connector onto the panel using the supplied nut and gasket for a secure, protected connection.

Q: What benefits does the flame-retardant shell offer?

A: The flame-retardant engineering plastic shell (UL94-V0 rated) significantly increases safety by minimizing the risk of ignition or the spread of flames, making it suitable for use in critical or public installations.

Tell us about your requirement

Price:

Quantity

Select Unit

50
100
200
250
500
1000+

Additional detail

Mobile number
