LP24 Series 400V 10A 12Pin Male Plug IP67 Waterproof Power Connector

703.0 INR/Piece

Get a Price/Quote

Product Details:

Power Source Electric
IP Rating IP67
Size Standard
Color Black
Rated Voltage 400 Volt (V)
Usage & Applications Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal
Features Best Quality
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP24 Series 400V 10A 12Pin Male Plug IP67 Waterproof Power Connector Price And Quantity

Price 703.0 INR/Piece
Minimum Order Quantity 100 Piece

LP24 Series 400V 10A 12Pin Male Plug IP67 Waterproof Power Connector Product Specifications

IP Rating IP67
Material Plastic+Metal
Color Black
Usage & Applications Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal
Power Source Electric
Size Standard
Features Best Quality
Rated Voltage 400 Volt (V)

LP24 Series 400V 10A 12Pin Male Plug IP67 Waterproof Power Connector Trade Information

Supply Ability 1000 Piece Per Month
Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:400V
Insertion and extraction force:22N Max
Withstanding voltage:2000V
Wire Gauge:1.01.5mm/18 -16AWG
Temperature and humidity:-40+80C; 40C, 85%RH
Mating cycle:1700 times
Screw torque:42-53 (N.m)

Superior Protection with IP67 Rating

The LP24 Series 12Pin Male Plug ensures reliable operation in wet and dusty settings. Its IP67 certification means the connector remains fully functional after immersion in water and protects internal components from fine dust, making it highly suited for both indoor and outdoor applications in harsh environments.

Flexible and Durable Construction

Constructed from a blend of sturdy plastic and metal materials, the connector offers excellent durability and resistance to wear and tear. The solder terminal design ensures secure electrical connections and the standard size fits seamlessly into existing electrical systems, reducing installation challenges.

FAQ's of LP24 Series 400V 10A 12Pin Male Plug IP67 Waterproof Power Connector:

Q: How does the IP67 rating benefit the LP24 Series 400V 12Pin Male Plug?

A: The IP67 rating assures that the male plug is dust-tight and can withstand immersion in water up to 1 meter, making it ideal for use in demanding environments where moisture or dust may be present.

Q: What are the common usage applications of this waterproof power connector?

A: This connector is widely used in industrial power distribution, outdoor lighting systems, machinery, marine equipment, and other applications where a secure, waterproof electrical connection is essential.

Q: Where can this 12Pin male plug be installed?

A: The LP24 Series connector can be installed in environments exposed to dust, water, or other harsh elements, such as factories, construction sites, outdoor setups, and marine settings, ensuring robust electrical connectivity.

Q: What is the installation process for this plug?

A: Installation involves soldering the wire to the terminal pins within the connector, ensuring a strong mechanical and electrical bond. The plug can then be secured to its corresponding socket or panel mount using the standard fitting.

Q: When should I choose a 400V 10A 12Pin connector over other types?

A: Select this connector when your application demands the transmission of higher voltages and currents, as well as reliable, waterproof, and dustproof performance, especially in multi-pin configurations for complex wiring systems.

Q: What are the key benefits of using a plastic and metal shell construction?

A: A hybrid plastic and metal shell offers enhanced strength, corrosion resistance, and thermal stability while keeping the connector lightweight, ensuring long-lasting durability in challenging conditions.
