LP24 USB3 Female-Female Socket IP67 Waterproof Data Connector Panel Mount (Push Lock)

435 INR/Piece

Get a Price/Quote

Product Details:

Interface USB3.0 Female-to-Female Socket
Components Plastic/metal shell, USB 3.0 contacts, sealing gasket
Charging Voltage 5V
Operating Temperature -40C to +85C
Output USB 3.0 Type-A Female
Power Supply USB bus-powered
Usage Industrial, outdoor, marine, automotive, data communication
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP24 USB3 Female-Female Socket IP67 Waterproof Data Connector Panel Mount (Push Lock) Price And Quantity

Price 435 INR/Piece
Minimum Order Quantity 100 Piece

Compliance RoHS, CE
Contact Resistance 30 m
Storage Temperature -55C to +105C
Flame Retardant Level UL94-V0
Panel Cut-Out Diameter Approx. 24 mm
Insulation Resistance 1000 M at 500V DC
Shell Plating Nickel
Mounting Type Panel mount with push lock
Mating Cycles 1500 times
Connector Type Female-Female (Type-A both sides)
Material High-quality plastic and nickel-plated brass
Sealing Gasket Included (silicone rubber)

LP24 USB3 Female-Female Socket IP67 Waterproof Data Connector Panel Mount (Push Lock) Product Specifications

Rated Voltage 30V DC
Usage Industrial, outdoor, marine, automotive, data communication
IP Rating IP67
Color Black/Silver
Input USB 3.0 Type-A Female
Supply Voltage 5V DC (typical for USB)
Function USB 3.0 data transmission, waterproof panel mount connection
Dimension (L*W*H) Approx. 54 x 24 x 24 mm
Size 24 mm (panel diameter)
Features Push lock mechanism, waterproof/dustproof, easy installation, corrosion-resistant
Power Source USB-powered
Capacity Up to 5 Gbps data transfer rate
Components Plastic/metal shell, USB 3.0 contacts, sealing gasket
Weight Approx. 28g
Interface USB3.0 Female-to-Female Socket
Application Outdoor/harsh environment data connection ; instrumentation ; automation equipment
Product Type USB panel mount waterproof connector
Current Rating 1.8A max
Output USB 3.0 Type-A Female
Power Supply USB bus-powered
Thickness Approx. 2.5mm (panel)
Operating Temperature -40C to +85C
Charging Voltage 5V

Compliance RoHS, CE
Contact Resistance 30 m
Storage Temperature -55C to +105C
Flame Retardant Level UL94-V0
Panel Cut-Out Diameter Approx. 24 mm
Insulation Resistance 1000 M at 500V DC
Shell Plating Nickel
Mounting Type Panel mount with push lock
Mating Cycles 1500 times
Connector Type Female-Female (Type-A both sides)
Material High-quality plastic and nickel-plated brass
Sealing Gasket Included (silicone rubber)

LP24 USB3 Female-Female Socket IP67 Waterproof Data Connector Panel Mount (Push Lock) Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Rated current:1.5A
Protection Level:IP67
Line diameter range:5.57mm
Contact resistance:<30mohm
Connection mode:Push lock type
Working temperature:-4080C

Robust Waterproof Connectivity

Engineered for harsh environments, the LP24 USB3 IP67 connector ensures waterproof and dustproof performance. The included silicone sealing gasket and push lock mechanism create a secure panel mount, perfect for outdoor, marine, and industrial installations. Nickel-plated brass and flame-retardant plastic provide longevity, even under extreme conditions.

Superior Data Transmission

Supporting up to 5 Gbps transfer rates, this USB 3.0 Type-A female-to-female socket guarantees reliable, high-speed data transmission. Designed for demanding applications such as industrial automation and instrumentation, it maintains excellent contact and insulation resistance, ensuring data integrity and signal quality.

Easy Installation & Wide Application

With its push lock mechanism and standard 24 mm panel cut-out, this connector is simple to install and highly adaptable. Its rugged design makes it suitable for instrumentation panels, automotive applications, or marine data lines, delivering power and data securely in any setting. RoHS and CE compliance assures quality and safety.

FAQ's of LP24 USB3 Female-Female Socket IP67 Waterproof Data Connector Panel Mount (Push Lock):

Q: How does the push lock mechanism benefit installation of the LP24 USB3 connector?

A: The push lock mechanism allows for secure and quick installation of the panel mount connector, minimizing installation time and ensuring a firm, reliable fit. This feature is especially beneficial in industrial and outdoor applications where maintenance access may be limited.

Q: What environments is the LP24 USB3 Female-Female Socket suitable for?

A: This connector is designed for use in outdoor, industrial, marine, automotive, and harsh environments where protection against water, dust, and corrosion is crucial. Its IP67 rating and robust construction ensure dependable operation in demanding conditions.

Q: When should I choose an IP67 rated USB connector like the LP24 for my project?

A: You should select an IP67 rated connector when your application requires a reliable data connection in environments exposed to water, dust, or extreme temperatures, such as equipment for marine vessels, outdoor installations, or industrial automation panels.

Q: What is the maximum data transfer rate supported by this USB 3.0 connector?

A: The LP24 USB3 supports data transfer rates of up to 5 Gbps, aligning with the USB 3.0 standard, which is ideal for high-speed data communication in critical applications.

Q: Where can this connector be mounted?

A: It is designed for panel mounting with a 24 mm cut-out and is suitable for any flat panel system requiring a USB 3.0 interface, including instrumentation consoles, outdoor control panels, and automotive dashboards.

Q: What is the process of installing the LP24 USB3 panel mount connector?

A: Installation involves making a 24 mm diameter cut-out on the panel, placing the connector through the opening, securing it with the provided sealing gasket, and using the push lock mechanism to fasten it in place for a watertight connection.

Q: What benefits does this connector offer for data communication systems?

A: The LP24 USB3 panel mount connector provides reliable high-speed data transmission, robust environmental protection, long service life (up to 1500 mating cycles), and resistance to corrosion, making it ideal for secure and durable USB connections in demanding environments.
