LP12 125V 5A 4Pin Female Socket IP67 Waterproof Power Connector

207.0 INR/Piece

Get a Price/Quote

Product Details:

Components Nylon body, copper alloy contacts, silicone sealing
Power Source Electrical power grid or DC supply
Features Waterproof, dustproof, secure screw locking, high durability
Interface 4-pin female socket
IP Rating IP67 (waterproof and dustproof)
Operating Temperature -20C to +85C
Power Supply 5A max current capacity
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP12 125V 5A 4Pin Female Socket IP67 Waterproof Power Connector Price And Quantity

Minimum Order Quantity 100 Piece
Price 207.0 INR/Piece

Mating Cycle Durability >500 cycles
Flammability Rating UL94-V0
Withstand Voltage 1500V AC/minute (1min, no breakdown)
Material - Pins Gold-plated copper alloy
Sealing Method Silicone O-ring
Mounting Type Panel mount
Insulation Resistance >1000M at 500V DC
Material - Shell High-performance nylon/PA66
Contact Resistance 5m

LP12 125V 5A 4Pin Female Socket IP67 Waterproof Power Connector Product Specifications

Features Waterproof, dustproof, secure screw locking, high durability
Thickness Panel thickness supported up to 3mm
Function Power connector interface for electronic/electrical equipment
Power Source Electrical power grid or DC supply
Components Nylon body, copper alloy contacts, silicone sealing
Power Supply 5A max current capacity
Operating Temperature -20C to +85C
Interface 4-pin female socket
IP Rating IP67 (waterproof and dustproof)
Current Rating 5A
Frequency 50/60Hz applicable
Application Outdoor LED lighting, industrial equipment, sensors, power distribution
Product Type Waterproof Power Connector Socket
Capacity 5A
Size Panel hole diameter: 12mm
Weight Approx. 18g
Usage Provides waterproof, secure electrical connections
Supply Voltage Up to 125V
Input 4 Pin female socket accepting mating plug
Output Delivers up to 125V/5A to device circuitry
Color Black with blue locking ring
Rated Voltage 125V AC/DC
Dimension (L*W*H) Approx. 32 x 22 x 22 mm

Mating Cycle Durability >500 cycles
Flammability Rating UL94-V0
Withstand Voltage 1500V AC/minute (1min, no breakdown)
Material - Pins Gold-plated copper alloy
Sealing Method Silicone O-ring
Mounting Type Panel mount
Insulation Resistance >1000M at 500V DC
Material - Shell High-performance nylon/PA66
Contact Resistance 5m

LP12 125V 5A 4Pin Female Socket IP67 Waterproof Power Connector Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting mode:Easy locking type
Insertion and extraction force:1.2N Max
Wire specification:UL246424AWG*2C
Rated Current:5A
Contact dimension:Phi 1.0x4
Temperature and humidity:-4080C, 40C, 85%RH
Mating cycle:1700 times

Superior Waterproof and Dustproof Design

Achieve maximum protection with an IP67 rating, ensuring this 4-pin socket remains fully operational even in harsh outdoor conditions. The silicone O-ring and screw-lock system prevent water and dust ingress, safeguarding connections for industrial, lighting, and sensor equipment.

High Performance and Safety Assurance

Built from flame-retardant nylon (UL94-V0) and equipped with gold-plated copper alloy contacts, this power connector ensures excellent conductivity and minimized resistance. With a withstand voltage of 1500V AC and insulation resistance over 1000M, it exceeds rigorous safety standards.

Versatile Mounting & Reliable Durability

Engineered for panel mounting-fitting holes of 12mm diameter and panels up to 3mm thick-this connector suits a range of devices. Its design supports over 500 mating cycles, ensuring a long operational life even in high-use applications.

FAQ's of LP12 125V 5A 4Pin Female Socket IP67 Waterproof Power Connector :

Q: How do I install the LP12 125V 5A 4Pin Female Socket in a panel?

A: To install, drill a 12mm diameter hole in a panel with a maximum thickness of 3mm, insert the socket into the hole, and secure it with the provided screw-lock mechanism. Ensure the silicone O-ring is in place for a watertight seal.

Q: What applications benefit most from using this connector?

A: This connector is especially suitable for outdoor LED lighting, industrial equipment, sensors, and any scenario demanding a secure, waterproof, 4-pin power interface capable of delivering 125V/5A.

Q: When should I choose an IP67-rated power connector?

A: Select an IP67-rated connector when your application demands protection against dust and temporary immersion in water-such as for outdoor installations, exposed industrial environments, or wet locations.

Q: Where can I use this socket for optimal performance?

A: For the best results, use this socket in environments that require robust sealing from moisture and dust, such as exterior lighting setups, outdoor power distribution, heavy machinery, or field-deployed monitoring devices.

Q: What process ensures durable and safe electrical contact?

A: This connector uses gold-plated copper alloy pins and a secure screw-lock system, providing reliable connections with low contact resistance. The silicone O-ring adds an extra layer of sealing, enhancing safety and longevity.

Q: How does the connector ensure user and device safety?

A: The LP12 socket meets high insulation standards (>1000M at 500V DC), has a high flammability resistance (UL94-V0), and can withstand up to 1500V AC without breakdown. These features prevent electrical hazards and guarantee safe operation in critical environments.
