LP20 10A 7Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal

Name: LP20 10A 7Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 551.0 INR
Availability: InStock

551.0 INR/Piece

Get a Price/Quote

Product Details:

Components Plastic + Metal Shell, Solder Pins
IP Rating IP67
Operating Temperature -25C to +85C
Features Waterproof, Solder-type, Durable, Dustproof
Input Solder terminal input
Output Solder terminal output
Power Supply AC / DC
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP20 10A 7Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal Price And Quantity

Price 551.0 INR/Piece
Minimum Order Quantity 100 Piece

Cable Diameter Range 6mm - 12mm
Salt Spray Resistance >48 hours
Number of Pins 7 pins
Shielding Yes, metal shell for EMI protection
Flammability Rating UL94 V-0
Dielectric Withstanding Voltage 1500V AC/minute
Contact Material Copper alloy with gold plating
Shell Material Plastic & Zinc Alloy Metal Mix
Mechanical Life >500 mating cycles
Contact Resistance <5m
Sealing Method Silicone gasket and screw collar
Mounting Type Cable mount
Insulation Resistance >2000M at 500VDC
Mating Style Push-pull self-locking

LP20 10A 7Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal Product Specifications

Interface 7 pin male solder terminal
Application Outdoor Electrical Connection, Power Transmission, Industrial Control
Power Source External power supply
Color Black and silver
Supply Voltage Up to 500V AC
Usage Industrial, Outdoor, LED lighting, Equipment connection
Capacity 10A per pin
Frequency 50/60Hz
Function Power connector for electrical devices
Dimension (L*W*H) Approx. 70mm x 28mm x 28mm
Power Supply AC / DC
Size LP20 series (approx. 20mm panel cutout)
Thickness Standard shell thickness (details not specified)
IP Rating IP67
Features Waterproof, Solder-type, Durable, Dustproof
Operating Temperature -25C to +85C
Components Plastic + Metal Shell, Solder Pins
Weight Approximately 45g
Rated Voltage 500V AC
Current Rating 10A
Output Solder terminal output
Input Solder terminal input
Product Type 7 Pin Power Connector Male Plug

Cable Diameter Range 6mm - 12mm
Salt Spray Resistance >48 hours
Number of Pins 7 pins
Shielding Yes, metal shell for EMI protection
Flammability Rating UL94 V-0
Dielectric Withstanding Voltage 1500V AC/minute
Contact Material Copper alloy with gold plating
Shell Material Plastic & Zinc Alloy Metal Mix
Mechanical Life >500 mating cycles
Contact Resistance <5m
Sealing Method Silicone gasket and screw collar
Mounting Type Cable mount
Insulation Resistance >2000M at 500VDC
Mating Style Push-pull self-locking

LP20 10A 7Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Take advantage of our reduced clearance pricing on the illustrious LP20 10A 7Pin Male Plug! This transcendent, IP67 waterproof power connector is crafted using a unique blend of plastic and zinc alloy, ensuring both lightness and rugged durability. Featuring a push-pull self-locking mating style and premium copper alloy gold-plated contacts, this connector offers incomparable shielded performance against EMI. Ideal for industrial and outdoor applications, it delivers stable power transmission with 10A per pin and up to 500V AC supply. Order today to secure unmatched reliability in your electrical installations!

Application, Features & Competitive Advantages

The LP20 10A 7Pin Male Plug excels in industrial machinery, outdoor lighting, power transmission, and equipment interconnection. Its main features include an IP67 waterproof rating, push-pull self-locking mechanism, and robust plastic-metal hybrid shell. Shielded against EMI and designed with gold-plated copper contacts, it ensures uncompromised connectivity. With a mechanical life of over 500 cycles and high resistance to salt spray and extreme temperatures, this connector offers clear competitive advantages for demanding environments.

Certifications, Payment Terms & Goods Transport Details

The LP20 10A 7Pin Male Plug conforms to UL94 V-0 flammability standards, ensuring certified safety for industrial use. Payment terms are arranged as per client agreement, supporting easy order processing. Goods can be shipped FOB from major Indian ports, with streamlined shipment channels for timely delivery. Our rates are competitive, and each unit is packed to guarantee safe transport, so clients receive goods in optimal condition.

FAQ's of LP20 10A 7Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal:

Q: How is the LP20 10A 7Pin Male Plug installed?

A: The LP20 plug uses a solder terminal interface for secure attachment, and its push-pull self-locking system ensures quick and reliable connection during installation.

Q: What makes this connector suitable for outdoor and industrial use?

A: Its IP67 waterproof rating, EMI shielding, and wide operating temperature range make it ideal for harsh environments, such as outdoor LED lighting, industrial machinery, and equipment connections.

Q: When should I choose this power connector over other options?

A: Choose the LP20 plug when durability, high current capacity (10A/pin), and protection against dust, water, and EMI are critical for your application.

Q: Where can the LP20 10A 7Pin connector be used?

A: It is suitable for outdoor electrical connections, LED lighting systems, industrial control panels, and power transmission setups in commercial and industrial facilities.

Q: What are the main benefits of the push-pull self-locking mechanism?

A: The push-pull self-locking design provides fast, secure mating and unmating, reducing installation time while preventing accidental disconnection during operation.
