YT-RJ45 IP67 Waterproof Male Plug Ethernet Connector Panel Mount PCB Shield

Name: YT-RJ45 IP67 Waterproof Male Plug Ethernet Connector Panel Mount PCB Shield
Brand: CONNECTOR DEVICES
Price: 225.0 INR
Availability: InStock

225.0 INR/Piece

Get a Price/Quote

Product Details:

Components Plug, Lock Nut, O-Ring, Connector Terminal, Protective Cover
Usage Outdoor and harsh environment networking
IP Rating IP67 Waterproof
Input RJ45 Male Plug
Interface RJ45 Female (Front Panel) / RJ45 Male (Cable End)
Features UV Resistant, Dustproof, Corrosion Resistant, Panel Mountable
Output RJ45 Panel Mount Socket
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YT-RJ45 IP67 Waterproof Male Plug Ethernet Connector Panel Mount PCB Shield Price And Quantity

Minimum Order Quantity 100 Piece
Price 225.0 INR/Piece

Flammability Rating UL94V-0
Contact Resistance 30 m
Durability 750 Mating Cycles
Mounting Type Panel Mount with Lock Nut
Cable Compatibility Cat5, Cat5e, Cat6 Ethernet Cables
Shielding 360 Shielded for EMI Protection
Material High-Strength Thermoplastic and Nickel-Plated Brass
Number of Pins/Contacts 8P8C (8 contacts)
Insulation Resistance 500 M at 500V DC
Sealing Type O-Ring and Gasket Sealed

YT-RJ45 IP67 Waterproof Male Plug Ethernet Connector Panel Mount PCB Shield Product Specifications

Usage Outdoor and harsh environment networking
Function Ethernet cable termination and waterproof RJ45 connectivity
Size Standard RJ45 Size
Current Rating 1.5A Max
Weight Approx. 32g
Dimension (L*W*H) Approx. 65mm x 22mm x 22mm
Rated Voltage DC 125V/AC 125V
Interface RJ45 Female (Front Panel) / RJ45 Male (Cable End)
Color Black and Metal Silver
Components Plug, Lock Nut, O-Ring, Connector Terminal, Protective Cover
Capacity Supports 1 port/channel
Power Source Passive, cable powered
Operating Temperature -25C to +85C
Input RJ45 Male Plug
Output RJ45 Panel Mount Socket
Frequency TYP 60Hz
IP Rating IP67 Waterproof
Thickness Standard Panel Thickness 1-4mm
Features UV Resistant, Dustproof, Corrosion Resistant, Panel Mountable
Product Type IP67 Waterproof RJ45 Ethernet Connector
Application LAN, Networking Equipment, Industrial Ethernet Connections

Flammability Rating UL94V-0
Contact Resistance 30 m
Durability 750 Mating Cycles
Mounting Type Panel Mount with Lock Nut
Cable Compatibility Cat5, Cat5e, Cat6 Ethernet Cables
Shielding 360 Shielded for EMI Protection
Material High-Strength Thermoplastic and Nickel-Plated Brass
Number of Pins/Contacts 8P8C (8 contacts)
Insulation Resistance 500 M at 500V DC
Sealing Type O-Ring and Gasket Sealed

YT-RJ45 IP67 Waterproof Male Plug Ethernet Connector Panel Mount PCB Shield Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting Mode:1/4 bayonet connecting type
Cable Specification:0.15mm2 0.2mm2 /2624AWG
Diameter Range:5.5mm 7mm
Operating Voltage(AC.V.rms):42V
Durability:> 500 mating & unmating cycles

Built for Extreme Environments

Designed with an IP67 waterproof rating, the YT-RJ45 connector ensures dustproof, UV resistant, and corrosion-resistant performance. The O-ring and gasket seal, along with robust thermoplastic and nickel-plated brass housing, make it highly reliable for outdoor and industrial networking challenges.

Reliable Shielded Connectivity

The 360 shielding effectively minimizes electromagnetic interference (EMI), ensuring consistent and secure data transmission even in high-noise environments. Its insulation resistance of 500 M at 500V DC further assures data integrity for sensitive or mission-critical network setups.

Seamless Installation and Use

Easy to integrate with standard panel thicknesses from 1-4mm using the included lock nut, this RJ45 connector supports plug-and-play connections for Cat5, Cat5e, and Cat6 cables. The included protective cover safeguards the contacts when not in use, enhancing its longevity and performance.

FAQ's of YT-RJ45 IP67 Waterproof Male Plug Ethernet Connector Panel Mount PCB Shield:

Q: How do I install the YT-RJ45 IP67 Waterproof Ethernet Connector on my panel?

A: To install, drill a panel hole matching the connector diameter (22mm). Insert the connector, secure it from the rear with the lock nut, ensuring the O-ring is in place for an airtight seal. Connect your RJ45 cable to the male plug, then terminate the front side with standard Ethernet cables.

Q: What types of Ethernet cables are compatible with this connector?

A: This connector is designed to support Cat5, Cat5e, and Cat6 Ethernet cables, offering flexible compatibility for a range of networking applications from basic LANs to advanced industrial systems.

Q: When should I use an IP67-rated connector like this?

A: You should use an IP67-rated connector in environments exposed to dust, water, UV, or strong chemicals-such as outdoor networks, industrial automation, or harsh field installations-to ensure long-term reliability and protection.

Q: Where can the YT-RJ45 connector be utilized most effectively?

A: It is ideal for outdoor communications cabinets, industrial control panels, wireless access points, marine networking, and anywhere robust, weather-resistant Ethernet connectivity is required.

Q: What benefit does 360 EMI shielding provide for my network?

A: The 360 metal shielding reduces electromagnetic interference, helping maintain a strong, consistent signal and minimizing data loss or transmission errors in electrically noisy environments such as factories or near heavy equipment.

Q: How durable is this Ethernet connector in terms of mating cycles?

A: It is rated for up to 750 mating cycles, meaning it can be repeatedly connected and disconnected reliably, which is beneficial for setups where cables may need frequent reconfiguration or maintenance.

Q: What is the process for maintaining its waterproof and dustproof features?

A: Ensure the O-ring and gasket are correctly positioned during installation. Always use the protective cover when disconnected, and periodically check seals for wear, especially if installed in harsh environments, to keep the IP67 protection effective.
