LP12 5A 4Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal

306.0 INR/Piece

Get a Price/Quote

Product Details:

Operating Temperature -40C to +85C
Interface 4-Pin Solder Terminal
Output 4-pin female interface
Features Metal shell, waterproof, anti-dust, corrosion-resistant, secure lock system
IP Rating IP67 Waterproof
Thermal Conductivity Standard/aluminium alloy casing
Power Supply Electrical cable
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP12 5A 4Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Price And Quantity

Price 306.0 INR/Piece
Minimum Order Quantity 100 Piece

Insulation Resistance >1000M @ 500V DC
Flange Mount Hole Diameter 2.5mm
Durability >=500 mating cycles
Sealing Ring Material Silica gel
Standards Compliance CE, RoHS
Flame Retardant Level UL94 V-0
Shell Material Zinc alloy with nickel plating
Pin Number 4-pin
Contact Resistance 5m
Mating Plug Model LP12-4P male plug
Mounting Type Flange panel mount
Contact Material Copper alloy with gold plating
Coupling Threaded locking
Connector Gender Female

LP12 5A 4Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Product Specifications

Power Supply Electrical cable
Weight Approx. 16g
Thickness 2mm (mounting flange)
Current Rating 5A
Product Type Power connector socket
Capacity Supports up to 5A current
Thermal Conductivity Standard/aluminium alloy casing
Power Source Electric
Application Power distribution, industrial automation, outdoor equipment
Color Silver, Black
Size LP12 Series
Components Connector body, flange, solder terminals, sealing ring
Usage Panel mount power supply connector
Input 4-pin female (solder terminal)
Function Waterproof electrical power connection
Rated Voltage 250V AC
Frequency 50/60Hz
Operating Temperature -40C to +85C
Supply Voltage Up to 250V AC
IP Rating IP67 Waterproof
Features Metal shell, waterproof, anti-dust, corrosion-resistant, secure lock system
Interface 4-Pin Solder Terminal
Dimension (L*W*H) Flange: 22mm diameter, 4mm thickness
Output 4-pin female interface

Insulation Resistance >1000M @ 500V DC
Flange Mount Hole Diameter 2.5mm
Durability >=500 mating cycles
Sealing Ring Material Silica gel
Standards Compliance CE, RoHS
Flame Retardant Level UL94 V-0
Shell Material Zinc alloy with nickel plating
Pin Number 4-pin
Contact Resistance 5m
Mating Plug Model LP12-4P male plug
Mounting Type Flange panel mount
Contact Material Copper alloy with gold plating
Coupling Threaded locking
Connector Gender Female

LP12 5A 4Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:250V
Contact resistance:< 5.0mohm
Contact dimension:Phi 1.0x2
Insertion and extraction force:0.6N Max.
Mating cycle:1700 times
Temperature and humidity:-4080C, 40C,85%RH
Wire specification:UL2464 24AWG*2C
Connecting mode:Easy locking type

Excellent Durability and Protection

Constructed with a metal zinc alloy shell and nickel plating, the LP12 connector offers substantial resistance to mechanical stress, corrosion, and harsh weather. The IP67 waterproof rating ensures dust and water ingress protection, enhancing reliability for outdoor and industrial applications.

Secure, Reliable Connection

The threaded locking mechanism maintains a stable connection, reducing the risk of accidental disconnection or power failure. Gold-plated copper contacts maintain excellent conductivity over 500+ mating cycles, ensuring lasting electrical performance.

Versatile Mounting and Usage

Designed for flange panel mounting, the LP12 5A 4Pin socket fits easily into control panels and enclosures. Its compatibility with the LP12-4P male plug and wide -40C to +85C operating range make it ideal for power distribution, automation systems, and outdoor equipment.

FAQ's of LP12 5A 4Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal:

Q: How is the LP12 5A 4Pin Female Socket installed onto a panel?

A: The connector features a flange panel-mount design with 2.5mm diameter mounting holes. Secure it to your panel using appropriate screws. The rear terminals are designed for soldering wires, providing a firm and enduring electrical connection.

Q: What level of environmental protection does the connector offer?

A: With an IP67 waterproof rating, the LP12 5A 4Pin socket is fully protected against dust and can withstand temporary immersion in water, making it suitable for outdoor and industrial settings where exposure to moisture or dust is prevalent.

Q: When is this power connector most beneficial to use?

A: This connector is particularly advantageous in scenarios where a reliable, waterproof power connection is required, such as in industrial automation, outdoor machinery, and power distribution systems. Its durability and sealing make it ideal for demanding environments.

Q: Where can the LP12 5A 4Pin connector be used?

A: It's commonly utilized in electrical panels, equipment cabinets, and outdoor installations. Its robust shell and watertight sealing make it suitable for use in industries like automation, machinery, and outdoor electrical equipment.

Q: What is the typical process for connecting wires to this socket?

A: Strip the insulation from your wires, then solder each wire to the respective 4-pin solder terminals at the back of the connector. Ensure proper insulation and strain relief after soldering for long-term reliability.

Q: What are the main benefits of the LP12 5A 4Pin Female Socket?

A: Key benefits include secure threaded locking to prevent disconnection, high resistance to water and dust ingress, robust construction for longevity, gold-plated contacts for excellent conductivity, and compliance with CE and RoHS safety standards.

Q: Is the LP12 5A 4Pin socket compatible with other connectors?

A: It is designed to mate specifically with the LP12-4P male plug for a seamless and secure connection.
