DH20 500V 20A 3Pin Female Socket IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal

444.0 INR/Piece

Get a Price/Quote

Product Details:

Features Metal Shell, Waterproof, Dustproof, Corrosion Resistant
IP Rating IP67
Power Source External Power Source
Charging Voltage 500V Max
Output 3 Pin Output Connection
Input 3 Pin Female
Usage Industrial Equipment Power Connections
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

DH20 500V 20A 3Pin Female Socket IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 444.0 INR/Piece

Humidity Resistance Up to 95% RH
Insulation Resistance >2000 M at 500V DC
Sealing Method Rubber Gasket & Screw Cap
Connector Type 3 Pin Female Socket
Housing Material Zinc Alloy
Flame Retardant Yes
Shielding Metal shielding for interference protection
Mating Cycle >500 mating cycles
Locking System Bayonet lock
Cable Diameter 8-12mm (supported)
Contact Resistance 5m
Contact Material Copper alloy with silver plating
Mounting Type Front Panel Mount

DH20 500V 20A 3Pin Female Socket IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal Product Specifications

Application Machinery, Electric Panels, Outdoor Power Supply
Weight Approx. 130g
Charging Voltage 500V Max
Frequency 50/60Hz
Color Silver / Metal
Product Type Waterproof Power Socket
Power Source External Power Source
Dimension (L*W*H) Diameter: 24mm, Length: 62mm (excluding connectors)
IP Rating IP67
Supply Voltage 500V
Features Metal Shell, Waterproof, Dustproof, Corrosion Resistant
Function Power Connector Socket
Operating Temperature -40C to +80C
Components Metal Shell, Solder Terminals, Gasket, Cap
Interface Panel Mount, Solder Terminal
Power Supply AC/DC Supported
Current Rating 20A
Input 3 Pin Female
Thickness Shell thickness: Approx. 1.5mm
Usage Industrial Equipment Power Connections
Capacity 20A Max Current
Size DH20 Series Size
Rated Voltage 500V
Output 3 Pin Output Connection

Humidity Resistance Up to 95% RH
Insulation Resistance >2000 M at 500V DC
Sealing Method Rubber Gasket & Screw Cap
Connector Type 3 Pin Female Socket
Housing Material Zinc Alloy
Flame Retardant Yes
Shielding Metal shielding for interference protection
Mating Cycle >500 mating cycles
Locking System Bayonet lock
Cable Diameter 8-12mm (supported)
Contact Resistance 5m
Contact Material Copper alloy with silver plating
Mounting Type Front Panel Mount

DH20 500V 20A 3Pin Female Socket IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Experience the kingly power and glorious performance of the DH20 500V 20A 3Pin Female Socket-our best-selling, customizable metal connector designed for invincible durability. Enjoy a noble Price Cut on this robust IP67-rated waterproof power connector featuring a sturdy zinc alloy shell, bayonet locking, and metal shielding for flawless interference protection. With over 500 mating cycles, ultimate humidity resistance, and flame-retardant build, it's the prime choice for industrial and outdoor power applications. Suitable for various voltage and current needs, this connector delivers secure connections every time.

Unmatched Versatility and Application Excellence

The DH20 500V 20A 3Pin Female Socket IP67 Metal Waterproof Power Connector excels in diverse industrial environments. Its powerful, waterproof build enables usage in machinery, electric panels, and outdoor power supply settings. It offers notable advantages such as invincible sealing, high current capacity, and protection against dust and corrosion. Application areas include factories, construction sites, control rooms, and heavy-duty outdoor equipment requiring reliable, safe, and continuous power supply. Its robust design ensures uninterrupted operation even in the harshest conditions.

Reliable Supply and Streamlined Payment Solutions

Our DH20 3Pin Power Connector is ready for bulk distribution with steady supply ability to major industries. Freight arrangements are efficiently managed to ensure timely drop-off and minimize client outlay. We accommodate versatile payment terms for buyer convenience, supporting smooth transactions with secure packaging that protects each unit during transit. As a reputable exporter, importer, manufacturer, and wholesaler in India, our logistics network ensures safe, reliable delivery to your location every time.

FAQ's of DH20 500V 20A 3Pin Female Socket IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal:

Q: How does the DH20 500V 20A 3Pin Female Socket ensure waterproof and dustproof performance?

A: This connector is sealed with a rubber gasket and screw cap, meeting IP67 standards to provide reliable waterproof and dustproof protection for outdoor and industrial power connections.

Q: What are the main advantages of using the DH20 3Pin Power Connector in industrial environments?

A: The connector offers strong metal shielding for interference protection, flame retardancy, and robust construction, ensuring invincible reliability even in high-humidity or harsh working conditions.

Q: Where can the DH20 500V 20A 3Pin Female Socket be applied?

A: It is widely applied in industrial machinery, electric panels, and outdoor power supply systems, providing secure and steady power in settings such as factories and construction sites.

Q: What is the process for mounting this connector in equipment panels?

A: The female socket is designed for front panel mounting, utilizing its bayonet lock for a secure and quick installation, and is compatible with cable diameters from 8mm to 12mm.

Q: How does the packaging and delivery process protect clients' investment?

A: Each socket is packaged securely to prevent damage during transit. Freight and drop-off logistics are managed efficiently, ensuring the product reaches clients in optimal condition while keeping outlay reasonable.
