LP12 100V 3A 7Pin Male Plug IP67 Waterproof Power Connector

303.0 INR/Piece

Get a Price/Quote

Product Details:

Output Up to 100V, 3A
Input Up to 100V, 3A
Features Waterproof, dustproof, vibration-proof, secure locking mechanism
Power Source Wired connection
Operating Temperature -25C to +85C
Interface 7 Pin Male
Power Supply AC/DC
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP12 100V 3A 7Pin Male Plug IP67 Waterproof Power Connector Price And Quantity

Price 303.0 INR/Piece
Minimum Order Quantity 100 Piece

LP12 100V 3A 7Pin Male Plug IP67 Waterproof Power Connector Product Specifications

Product Type 7Pin Male Plug Power Connector
Dimension (L*W*H) Approx. 55mm x 22mm x 22mm
IP Rating IP67
Usage Outdoor/Indoor electronic device connections
Interface 7 Pin Male
Power Supply AC/DC
Current Rating 3A max
Supply Voltage 100V AC/DC
Function Power Connector
Rated Voltage 100V
Components Connector body, 7-pin contact, locking ring, sealing gasket
Weight Approx. 30g
Features Waterproof, dustproof, vibration-proof, secure locking mechanism
Power Source Wired connection
Frequency 50/60Hz
Output Up to 100V, 3A
Input Up to 100V, 3A
Size Standard LP12 Series Size
Thickness Standard (as per connector type)
Color Black
Capacity 3A per pin
Operating Temperature -25C to +85C
Application LED lighting, power distribution, industrial equipment

Sealing Method Silicone O-ring seal
Cable Diameter Accepted 6-8mm
Mounting Type Cable mount
Shell Material High-strength nylon, flame retardant
Insulation Resistance >1000 M at 500V DC
Standards Compliance CE, RoHS
Locking Method Screw/Ring lock
Flammability Rating UL94-V0
Contact Material Copper alloy with gold-plated contacts
Connector Type Male Plug
Contact Resistance 5m
Mating Cycle Durability >500 cycles
Number of Pins 7

LP12 100V 3A 7Pin Male Plug IP67 Waterproof Power Connector Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting mode:Easy locking type
Insertion and extraction force:2.1N Max
Wire specification:UL2464 24AWG*2C
Mating cycle:> 1700 times
Temperature and humidity:-4080C, 40C,85%RH
Contact dimension:Phi 0.8x7

Designed for Extreme Conditions

Engineered with a high-strength nylon shell and gold-plated copper contacts, the LP12 Male Plug withstands tough environmental challenges, including moisture, dust, and vibrations. Its silicone O-ring and flame-retardant materials guarantee secure and safe power connections outdoors or indoors, making it a dependable choice for harsh operating conditions.

Effortless, Secure Installation

With a screw/ring locking mechanism and cable mount design, installation of the LP12 connector is simple and ensures a tight, tamper-proof fit. The 6-8 mm cable diameter acceptance allows compatibility with a range of cabling, while the IP67 rating means it functions reliably even when exposed to heavy rain or dust.

Versatile Power Solution

Compliant with CE and RoHS standards, the LP12 7Pin Male Plug is adaptable for various applications from industrial automation to LED lighting systems. Rated for 100V and 3A, it supports both AC and DC power supplies, maintains excellent performance from -25C to +85C, and is built for over 500 plugging cycles.

FAQ's of LP12 100V 3A 7Pin Male Plug IP67 Waterproof Power Connector :

Q: How does the LP12 7Pin Male Plug ensure waterproof and dustproof protection?

A: The LP12 connector achieves IP67 waterproof and dustproof protection through its high-strength nylon shell, tightly sealed silicone O-ring, and robust screw/ring locking design. This comprehensive sealing system prevents moisture and particulates from entering, guaranteeing reliable operation in harsh environments.

Q: What are the recommended usage scenarios for the LP12 Power Connector?

A: This connector is ideal for both indoor and outdoor electronic device connections, including LED lighting, industrial equipment, and power distribution systems. Its waterproof and vibration-proof properties make it particularly suitable for applications subjected to challenging weather and mechanical stress.

Q: When should I use a 7-pin male plug like the LP12 in my installation?

A: The LP12 7-pin male plug is best used when multiple power or signal lines are needed in a single, secure, and waterproof connector. Its seven contacts support up to 3A per pin, making it suitable for complex power or control wiring in demanding environments.

Q: Where can the LP12 7Pin Male Plug be effectively installed?

A: Thanks to its cable mount design and IP67 protection, the LP12 connector can be installed on exposed equipment outdoors, in industrial settings, or in any area that requires dependable and weatherproof power connections.

Q: What is the installation process for the LP12 7Pin Male Plug?

A: Installation involves preparing the cable to fit the 6-8 mm diameter specification, attaching the connector body, securely fastening the locking ring, and ensuring the silicone O-ring is in place for a proper seal. This straightforward process delivers a tight and reliable connection.

Q: What benefits does the gold plating on the contacts provide?

A: Gold-plated contacts offer excellent conductivity, resist corrosion, and ensure stable long-term performance through repeated connection cycles. This increases the reliability and lifespan of the connector, especially in environments exposed to humidity and temperature fluctuations.

Tell us about your requirement

Price:

Quantity

Select Unit

50
100
200
250
500
1000+

Additional detail

Mobile number

Other Products in 'Waterproof Power Connector' category

YM20 20A 4Pin Male Plug IP68 Waterproof Power Connector Plastic Shell Solder Terminal Price : 402.0 INR/Piece Minimum Order Quantity : 100 Operating Temperature : 40C to +105C Color : Black Power Source : External electrical circuit Features : Dustproof, waterproof, corrosion resistant, quick connection Rated Voltage : 500V AC IP Rating : IP68 Application : Outdoor lighting, power equipment, marine, automation Size : Shell size 20mm (YM20 series) Power Supply : AC/DC Capacity : 20A max Output : Female counterpart (not included) Input : 4pin male plug, solder terminal type Weight : Approx. 75g Components : Plastic shell, brass goldplated terminals, sealing ring Supply Voltage : Up to 500V AC/DC Function : Power connection for industrial and outdoor applications Current Rating : 20A max Interface : 4pin solder terminal Usage : Cable to cable or device connection Dimension (L*W*H) : Approx. 86mm x 32mm x 32mm Product Type : IP68 Waterproof Power Connector Frequency : 50/60Hz Thickness : Shell thickness approx. 2.0mm

Send Inquiry

LP12 5A 5Pin Female Socket IP67 Waterproof Power Connector Flange Mount Metal Shell Solder Terminal Price : 332.0 INR/Piece Minimum Order Quantity : 100 Operating Temperature : 25C to +85C Color : Silver (Metal Shell) Power Source : Cable/wired Features : Waterproof, corrosion resistant, secure metal locking, easy installation Rated Voltage : 250V AC IP Rating : IP67 Application : Outdoor, industrial, marine, automation, LED, instrumentation Size : Connector diameter: 12mm Power Supply : Through cable connection Capacity : 5A per contact Output : Panel/flange mount connection Input : 5pin FEMALE solder terminals Weight : Approx. 22g Components : Metal shell, 5pin solder terminals, sealing washer, mounting flange Supply Voltage : 250V Max Function : Waterproof electrical connection for power and signal transfer Current Rating : 5A Interface : Solder terminal Usage : Industrial equipment, LED lighting, outdoor power interfaces Dimension (L*W*H) : 31mm x 22mm x 22mm (flange diameter approx. 22mm) Product Type : Waterproof power connector socket Frequency : 50/60 Hz Thickness : Shell thickness approx. 1.5mm
