YW16 500V 10A 3Pin Metal Male Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal

Name: YW16 500V 10A 3Pin Metal Male Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 407.0 INR
Availability: InStock

407.0 INR/Piece

Get a Price/Quote

Product Details:

Output Panel Mount Connection
Interface Solder Terminal
Power Supply Wired
Usage Industrial Power Supply Connectors
Thermal Conductivity Standard for Metal Shell
IP Rating IP67
Features Waterproof, Dustproof, Durable Construction
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YW16 500V 10A 3Pin Metal Male Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal Price And Quantity

Price 407.0 INR/Piece
Minimum Order Quantity 100 Piece

Contact Material Copper Alloy with Silver Plating
Number of Pins 3
Mounting Type Panel Mount Type
Connector Gender Male Socket
Contact Resistance 5m
Insulation Resistance >1000M (at 500V DC)
Flame Retardant UL94-V0
Compatibility YW16 Series Connectors
Connection Method Solder Type
Sealing Gasket Material Silicone Rubber
Safety Certifications CE, RoHS, IP67
Shell Material Nickel-plated Zinc Alloy
Mechanical Life 500 Mating Cycles
Standards Compliance IEC60529, RoHS

YW16 500V 10A 3Pin Metal Male Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal Product Specifications

Supply Voltage 500V
Current Rating 10A
Rated Voltage 500V AC/DC
Operating Temperature -40C to +80C
Product Type Metal Male Socket
Components Metal Shell, Solder Terminals
IP Rating IP67
Weight Approx. 32g
Color Silver
Thermal Conductivity Standard for Metal Shell
Application Waterproof Electrical Connection
Size YW16 Series Standard
Dimension (L*W*H) Approx. 50mm (L) x 20mm (Diameter)
Power Source Electric Powered
Features Waterproof, Dustproof, Durable Construction
Input 3 Pin Male
Usage Industrial Power Supply Connectors
Power Supply Wired
Output Panel Mount Connection
Function Power Connection
Capacity 10A
Thickness Standard Metal Shell
Frequency 50/60Hz (typical usage)
Interface Solder Terminal

Contact Material Copper Alloy with Silver Plating
Number of Pins 3
Mounting Type Panel Mount Type
Connector Gender Male Socket
Contact Resistance 5m
Insulation Resistance >1000M (at 500V DC)
Flame Retardant UL94-V0
Compatibility YW16 Series Connectors
Connection Method Solder Type
Sealing Gasket Material Silicone Rubber
Safety Certifications CE, RoHS, IP67
Shell Material Nickel-plated Zinc Alloy
Mechanical Life 500 Mating Cycles
Standards Compliance IEC60529, RoHS

YW16 500V 10A 3Pin Metal Male Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:500V
Withstanding voltage:2500V
Contact resistance:< 5.0mOhm
Contact dimension:Phi 1.5x3
Insertion and extraction force:1.8N Max
Mating cycle:1700 Times
Temperature and humidity:-40+80C; 40C, 85%RH
Screw torque:42-53 (N.m)

Built for Industrial Reliability

Engineered for tough industrial applications, the YW16 500V 10A 3Pin Metal Male Socket ensures consistent performance with its nickel-plated zinc alloy shell and flame retardant UL94-V0 rating. Its superior insulation and contact resistance safeguard your equipment, providing stable connections even in challenging environments.

Waterproof and Dustproof Protection

Thanks to its IP67 certified sealing and durable silicone rubber gasket, this connector delivers excellent resistance to water and dust ingress. Perfect for outdoor and harsh-duty operations, it maintains safe power transmission regardless of weather or site conditions.

Easy Installation and Versatile Applications

With its solder terminal interface and panel mount design, the YW16 connector is quick and straightforward to install. Its compatibility with YW16 Series connectors adds versatility, making it a reliable choice for electric-powered industrial setups in manufacturing, automation, and more.

FAQ's of YW16 500V 10A 3Pin Metal Male Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal:

Q: How is the YW16 3Pin Metal Male Socket installed on a panel?

A: The socket utilizes a panel mount design and is affixed using the included mounting hardware. Electrical connections are made by soldering wires to the provided terminals, ensuring a secure and reliable attachment.

Q: What environments can the YW16 connector operate in?

A: With its IP67 waterproof and dustproof rating, this connector is ideal for both indoor and outdoor applications, including industrial, manufacturing, and automation settings that require rugged and protected power connections.

Q: When should I use this connector over other types?

A: The YW16 3Pin Metal Male Socket is best utilized when durability, water resistance, high current (up to 10A), and reliable mechanical performance are required-especially in industrial environments subject to exposure and vibration.

Q: What process is used for making electrical connections?

A: Connections are established by soldering appropriate wires to the silver-plated copper alloy terminals. This solder type method ensures superior conductivity and long-term mechanical resilience.

Q: Where is this connector commonly used?

A: This connector is widely used in machinery, control panels, outdoor electrical systems, and other industrial power supply setups that demand secure and waterproof connections.

Q: What are the benefits of the YW16 Metal Male Socket design?

A: The robust metal shell, high insulation, flame retardancy, and silver-plated contacts provide excellent safety, durability, and low contact resistance, ensuring stable operation and extended service life in harsh conditions.

Q: Is this connector compliant with international safety standards?

A: Yes, the YW16 connector meets IEC60529, CE, and RoHS standards, ensuring safety, environmental compliance, and peace of mind for critical electrical installations.
