YM20 5A 9Pin Male Plug IP68 Waterproof Power Connector

358.0 INR/Piece

Get a Price/Quote

Product Details:

Input 9 Pin Male Plug
Usage Outdoor and indoor wiring, machinery, lighting, automation systems
Output Cable Connection or Mated Female Connector
Features Waterproof, dustproof, corrosion-resistant, vibration resistant, easy locking/unlocking
Components Main connector body, 9 pin contacts, cable nut, sealing ring
Power Source External Power via Cable
Operating Temperature -40C to +85C
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YM20 5A 9Pin Male Plug IP68 Waterproof Power Connector Price And Quantity

Price 358.0 INR/Piece
Minimum Order Quantity 100 Piece

Contact Material Gold-plated copper alloy
Mounting Type Cable-to-cable or cable-to-chassis
Sealing Method Silicone sealing ring
Insulation Resistance >2000M (at 500V DC)
Contact Resistance 5m
Sheath Material Nylon PA66, flame-retardant
Mating Cycle Durability >500 cycles
Cable Outer Diameter Suitability 5.5mm - 10mm
Flammability Rating UL94 V-0
Connector Type Screw locking

YM20 5A 9Pin Male Plug IP68 Waterproof Power Connector Product Specifications

Thickness Standard (as per interface)
Features Waterproof, dustproof, corrosion-resistant, vibration resistant, easy locking/unlocking
Power Source External Power via Cable
Components Main connector body, 9 pin contacts, cable nut, sealing ring
Function Waterproof power connection for electrical and electronic devices
Power Supply Through Connector
Operating Temperature -40C to +85C
Application Industrial, Automation, Power Distribution, Outdoor Equipment
Current Rating 5A per contact
Frequency 50/60 Hz
IP Rating IP68
Interface 9 Pin Male Circular Interface
Weight Approx. 50g
Size YM20 (Body diameter approx. 20mm)
Product Type Circular Waterproof Power Connector
Capacity 5A per pin
Input 9 Pin Male Plug
Supply Voltage Up to 500V AC
Usage Outdoor and indoor wiring, machinery, lighting, automation systems
Dimension (L*W*H) Approx. 70mm (Length incl. cable nut)
Rated Voltage 500V AC / 700V DC
Color Black
Output Cable Connection or Mated Female Connector

Contact Material Gold-plated copper alloy
Mounting Type Cable-to-cable or cable-to-chassis
Sealing Method Silicone sealing ring
Insulation Resistance >2000M (at 500V DC)
Contact Resistance 5m
Sheath Material Nylon PA66, flame-retardant
Mating Cycle Durability >500 cycles
Cable Outer Diameter Suitability 5.5mm - 10mm
Flammability Rating UL94 V-0
Connector Type Screw locking

YM20 5A 9Pin Male Plug IP68 Waterproof Power Connector Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:500V
Withstanding voltage:2500V
Insertion and extraction force:4.0N Max
Screw torque:42-53 (N.m)
Mating cycle:1700 Times
Temperature and humidity:-4080C; 40C, 85%RH
Contact dimension:Phi 2.7*2

Exceptional Durability and Reliability

Constructed with flame-retardant nylon PA66 and gold-plated copper contacts, the YM20 connector provides superior resistance to corrosion and vibration. Its screw-locking design and integrated silicone sealing ring protect the interface against water, dust, and harsh weather, guaranteeing secure and consistent performance over 500 mating cycles.

Versatile Outdoor and Indoor Application

Designed to withstand rigorous conditions, this connector is suitable for industrial machinery, automation systems, power distribution, and outdoor LED lighting. With an IP68 waterproof rating and support for wide cable diameters, the YM20 ensures dependable connectivity, whether used for cable-to-cable or cable-to-chassis installations.

Easy Installation and Maintenance

Featuring a user-friendly screw locking mechanism and wide compatibility range, the YM20 9Pin Male Plug enables simple and secure installation. The cable nut and sealing ring ensure straightforward assembly, making maintenance and replacement quick on-site without the need for specialized tools.

FAQ's of YM20 5A 9Pin Male Plug IP68 Waterproof Power Connector:

Q: How does the YM20 9Pin Male Plug connector maintain a waterproof seal?

A: The connector utilizes a silicone sealing ring and precision screw-locking mechanism to achieve an IP68 rating, which reliably protects the interface against water, dust, and contaminants in both outdoor and indoor applications.

Q: What are the main benefits of using a gold-plated copper alloy for the contacts?

A: Gold-plated copper alloy offers excellent conductivity and strong resistance to corrosion, ensuring reliable signal transmission, lower contact resistance, and prolonged lifespan even in harsh or humid environments.

Q: Where can the YM20 5A 9Pin connector be effectively used?

A: This connector is designed for environments such as industrial automation, machinery, outdoor lighting, power distribution, and applications exposed to moisture, vibration, or varying temperatures from -40C to +85C.

Q: What is the installation process for this power connector?

A: The screw locking system, combined with the cable nut and silicone ring, allows for simple and secure cable-to-cable or cable-to-chassis mounting. No specialized tools are required; follow the assembly instructions for proper waterproof sealing.

Q: When should I choose a connector with an IP68 rating like this one?

A: An IP68-rated connector is ideal when equipment must be protected from prolonged water exposure, dust ingress, or harsh weather, such as in outdoor, wet, or industrial environments.

Q: What cable sizes are supported by the YM20 9Pin Male Plug?

A: The connector is compatible with cable outer diameters ranging from 5.5mm to 10mm, allowing it to be used with a wide range of power and signal cables common in industrial and automation settings.

Q: How often can this connector be mated and unmated without loss of performance?

A: The YM20 connector is designed to withstand more than 500 mating cycles, making it highly reliable for applications requiring regular connection and disconnection.
