LP12 125V 5A 6Pin Male Plug IP67 Waterproof Power Connector

285.0 INR/Piece

Get a Price/Quote

Product Details:

Power Source Wired
Input Male Plug Connection
Usage Cable to cable, cable to device waterproof power connection
IP Rating IP67
Components Plug body, pins, sealing ring, locking nut
Operating Temperature -20C to +80C
Output 6 Pin Electrical Interface
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP12 125V 5A 6Pin Male Plug IP67 Waterproof Power Connector Price And Quantity

Minimum Order Quantity 100 Piece
Price 285.0 INR/Piece

LP12 125V 5A 6Pin Male Plug IP67 Waterproof Power Connector Product Specifications

Power Source Wired
Function Electrical Power Connection
Weight Approx. 25g
Size LP12 Series (Plug OD: approx. 12mm)
Input Male Plug Connection
Operating Temperature -20C to +80C
Thickness N/A (cylindrical design)
Dimension (L*W*H) Approx. 60mm x 18mm x 18mm
Output 6 Pin Electrical Interface
Supply Voltage 125V
Color Black/Silver
Power Supply External power source
Features Waterproof, dustproof, anti-corrosion, secure locking system
Usage Cable to cable, cable to device waterproof power connection
Current Rating 5A Max
Capacity 5A current per pin
Rated Voltage 125V AC/DC
IP Rating IP67
Components Plug body, pins, sealing ring, locking nut
Product Type IP67 Waterproof Power Connector
Application LED lighting, Electric vehicles, Marine electronics, Outdoor equipment
Frequency 50/60Hz
Interface 6 pin round male connector

Withstand Voltage 1500V AC/minute
Mounting Type Cable mount
Contact Material Brass with gold plating
Mating Cycle Durability >500 cycles
Cable Diameter Supported 4mm - 6.5mm
Environmental Protection UV resistant, suitable for harsh environments
Insulation Resistance >2000M at 500V DC
Connector Series LP12
Connector Gender Male
Shell Material Nylon PA66
Locking Mechanism Screw coupling
Flammability Rating UL94-V0

LP12 125V 5A 6Pin Male Plug IP67 Waterproof Power Connector Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting mode:Easy locking type
Insertion and extraction force:1.8N Max
Wire specification:UL2464 24AWG*2C
Contact dimension:Phi 1.0x6
Temperature and humidity:-4080C, 40C, 85%RH
Mating cycle:> 1700 times
Operating Voltage:125V

Engineered for Tough Environments

Built using high-quality nylon PA66 and featuring gold-plated brass contacts, the LP12 connector thrives in challenging outdoor settings. It is IP67 waterproof, UV resistant, and carries a UL94-V0 flammability rating for added safety. The connector's rugged design minimizes performance degradation even in marine or industrial applications, ensuring consistent power delivery every time.

Secure and Reliable Power Transmission

The advanced screw coupling mechanism guarantees a firm, vibration-resistant connection during operation. Supporting up to 5A current per pin with an insulation resistance greater than 2000M at 500V DC, this 6-pin male plug connector ensures efficient, stable electrical output. Its robust mating cycle durability (>500 cycles) makes it an excellent choice for repeated connections and disconnections.

Easy Installation and Versatile Application

Cable-mount design supports cable diameters from 4mm to 6.5mm, allowing for flexible integration into various power supply setups. With a compact LP12 series body (plug OD approx. 12mm) and screw-type locking, it simplifies installation-whether connecting LED lighting, electric vehicles, marine electronics, or any outdoor power equipment needing waterproof connectivity.

FAQ's of LP12 125V 5A 6Pin Male Plug IP67 Waterproof Power Connector:

Q: How do I install the LP12 6Pin Male Plug in a cable-to-device power connection?

A: To install, first strip your cable to expose the wires, route them through the sealing ring and locking nut, and solder or crimp the wires to the corresponding pins. Securely fasten the cable with the plug body, then tighten the screw coupling to ensure a waterproof and dustproof seal. Make sure the supported cable diameter is between 4mm and 6.5mm for optimal performance.

Q: What makes the LP12 connector suitable for outdoor or harsh environments?

A: The LP12 connector features an IP67 waterproof rating, UV-resistant nylon PA66 shell, and gold-plated brass contacts for corrosion resistance. Its robust design secures electrical connections even in extreme weather, marine, or dusty industrial environments, making it ideal for outdoor applications such as LED lighting, electric vehicles, and marine electronics.

Q: When should I use this connector's male plug instead of a different type?

A: Use the LP12 male plug when you need a secure, reliable, waterproof (IP67) electrical connection-especially where repeated mating cycles are required. It is ideal for demanding environments that require not only power transfer but also resistance to UV, dust, and moisture, such as outdoor equipment and marine applications.

Q: Where can I apply the LP12 6Pin Power Connector?

A: This connector is versatile and widely used in applications like LED lighting installations, electric vehicle circuits, marine electronic equipment, and various outdoor devices requiring reliable, waterproof power connections. Its cable mount design fits seamlessly into both industrial and commercial power setups.

Q: What is the process for ensuring a waterproof and dustproof connection?

A: After connecting and securing the internal wires, make sure to properly assemble the sealing ring and screw tight the locking nut. The screw coupling mechanism, combined with the integrated sealing components, maintains an IP67-rated seal, protecting the internal contacts from moisture, dust, and corrosion.

Q: How does this connector benefit long-term installations?

A: The LP12 connector's components are engineered for durability, with a mating cycle rating over 500 times and materials designed to resist UV light, moisture, and high temperatures. These features mean less frequent maintenance, reduced risk of connection failure, and sustained reliable performance in extended or permanent installations.
