DH24 400V 10A 10Pin Female Socket IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal

Name: DH24 400V 10A 10Pin Female Socket IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 691.0 INR
Availability: InStock

691.0 INR/Piece

Get a Price/Quote

Product Details:

Operating Temperature -40C to +85C
Output Pin Contacts
Power Source External Electrical Supply
Input Socket
Usage Electrical Equipment Connection
Power Supply AC
IP Rating IP67
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

DH24 400V 10A 10Pin Female Socket IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal Price And Quantity

Price 691.0 INR/Piece
Minimum Order Quantity 100 Piece

Shell Material Zinc Alloy, Nickel Plated
Contact Resistance 5m
Mechanical Life 500 Mating Cycles
Sealing Method Rubber Gasket/O-Ring
Flame Retardant Grade UL94-V0
Contact Material Gold-plated Copper
Connector Style Panel Mount
Wire Connection Method Solder Terminal
Vibration Resistance 10-500Hz, 15g
Dielectric Strength 1500V AC/min
Insulation Resistance 2000M at 500VDC
Mounting Type Chassis/Panel Mount
Cable Diameter Range 10mm-12mm

DH24 400V 10A 10Pin Female Socket IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal Product Specifications

Application Industrial, Outdoor, Power Distribution, Automation
Product Type Waterproof Power Connector
Interface 10-Pin Solder Terminal
Components 10-Pin Female Socket, Metal Shell, Solder Terminals
Rated Voltage 400V
Features Waterproof, Dustproof, Metal Shell, Corrosion Resistant, Screw Lock
IP Rating IP67
Weight Approx. 96g
Function Power Connector Female Socket
Power Supply AC
Usage Electrical Equipment Connection
Dimension (L*W*H) Approx. 72mm x 37mm x 37mm
Current Rating 10A
Supply Voltage 400V
Input Socket
Capacity 10A Maximum Current
Power Source External Electrical Supply
Output Pin Contacts
Size DH24 Standard
Operating Temperature -40C to +85C
Color Silver
Frequency 50/60Hz

Shell Material Zinc Alloy, Nickel Plated
Contact Resistance 5m
Mechanical Life 500 Mating Cycles
Sealing Method Rubber Gasket/O-Ring
Flame Retardant Grade UL94-V0
Contact Material Gold-plated Copper
Connector Style Panel Mount
Wire Connection Method Solder Terminal
Vibration Resistance 10-500Hz, 15g
Dielectric Strength 1500V AC/min
Insulation Resistance 2000M at 500VDC
Mounting Type Chassis/Panel Mount
Cable Diameter Range 10mm-12mm

DH24 400V 10A 10Pin Female Socket IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:400V
Temperature and humidity:-4080C; 40C, 85%RH
Wire Gauge:1.01.5mm/18 -16AWG
Withstand voltage(AC.V)1min:2500V
Mating Cycle:1700 Times

Superior Construction for Challenging Environments

Engineered with a nickel-plated zinc alloy shell and gold-plated copper contacts, this connector provides exceptional conductivity and resilience. The IP67 rating ensures watertight sealing, even under harsh outdoor conditions, making it perfect for industrial and automation setups. The robust flame retardant design protects equipment and operators alike.

Flexibility and Easy Installation

With a versatile panel/chassis mount and screw-lock mechanism, the DH24 connector simplifies secure installations. Its solder terminals offer a reliable wire connection method, allowing users to achieve solid contact integrity even in settings with intense vibrations or frequent handling.

FAQ's of DH24 400V 10A 10Pin Female Socket IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal:

Q: How is the DH24 400V 10A 10Pin Female Socket typically installed?

A: This connector is designed for panel or chassis mount applications. Secure installation is achieved via a screw-lock mechanism, ensuring a tight fit and stable connection. Solder terminals facilitate precise electrical connections.

Q: What benefits does the IP67 rating provide for this connector?

A: The IP67 rating guarantees complete protection against dust and water immersion up to 1 meter for 30 minutes. This makes the connector highly suitable for outdoor and industrial environments where exposure to harsh conditions is common.

Q: When should I use a connector with a metal shell and gold-plated contacts?

A: Opt for a connector with these features when you require superior durability, corrosion resistance, and reliable electrical conductivity, especially in moist, industrial, or high-vibration environments.

Q: Where can the DH24 10-pin socket be used?

A: This power connector is ideal for usage in electrical equipment connections across industries such as power distribution, automation, outdoor installations, and any application requiring high current capacity and robust sealing.

Q: What is the recommended cable diameter for this female socket?

A: It supports cables with diameters ranging from 10mm to 12mm, allowing the use of sufficiently thick cables to handle its maximum rated current of 10A.

Q: How does the connector ensure long-lasting mechanical performance?

A: It is engineered for up to 500 mating cycles with superior vibration resistance (10-500Hz, 15g), making it reliable for frequent connections and disconnections without loss of performance.
