LP20 500V 20A 4Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal

Name: LP20 500V 20A 4Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 482.0 INR
Availability: InStock

482.0 INR/Piece

Get a Price/Quote

Product Details:

Charging Voltage Up to 500V
Features Waterproof, dustproof, corrosion resistant, strong mechanical strength
Output Up to 500V, 20A
Input Up to 500V, 20A
Power Source Wired power
IP Rating IP67
Usage Electrical power distribution
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP20 500V 20A 4Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 482.0 INR/Piece

Sealing Type O-ring and threaded coupling
Shell Material Plastic + Metal
Contact Resistance < 5 m
Flame Retardancy UL94-V0
Durability > 500 mating cycles
Standards Compliance CE, RoHS
Number of Contacts 4 (4Pin)
Wire Range 1.5mm2-2.5mm2 cable supported
Insulation Resistance > 2000 M
Locking Mechanism Screw type
Connection Type Male Plug
Mounting Method Cable mount
Contact Material Copper alloy, gold plated
Withstand Voltage 1500V AC/1min

LP20 500V 20A 4Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal Product Specifications

Input Up to 500V, 20A
Power Source Wired power
Color Black & Silver
Charging Voltage Up to 500V
Features Waterproof, dustproof, corrosion resistant, strong mechanical strength
Weight Approx. 55g
Output Up to 500V, 20A
Rated Voltage 500V
Product Type Male Plug Connector
IP Rating IP67
Usage Electrical power distribution
Supply Voltage 500V maximum
Dimension (L*W*H) 70mm x 34mm x 34mm (approx.)
Operating Temperature -40C to +80C
Interface Solder terminal
Size Shell size 20mm
Current Rating 20A
Capacity 4Pin, 20A max
Application Outdoor power equipment, LED lighting, industrial automation
Function Waterproof power connection for outdoor/industrial equipment
Thickness Shell thickness approx. 2 mm
Power Supply AC or DC power systems
Components Contact pins, plastic+metal shell, solder terminals, O-ring seal
Frequency Applicable for 50/60Hz systems
Thermal Conductivity Standard for electrical connectors

Sealing Type O-ring and threaded coupling
Shell Material Plastic + Metal
Contact Resistance < 5 m
Flame Retardancy UL94-V0
Durability > 500 mating cycles
Standards Compliance CE, RoHS
Number of Contacts 4 (4Pin)
Wire Range 1.5mm2-2.5mm2 cable supported
Insulation Resistance > 2000 M
Locking Mechanism Screw type
Connection Type Male Plug
Mounting Method Cable mount
Contact Material Copper alloy, gold plated
Withstand Voltage 1500V AC/1min

LP20 500V 20A 4Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting Mode:Quickly bayonet connect
Cable Specification:2.5mm2 4mm2 /1412AWG
Diameter Range:8mm 12mm
Operating Voltage(AC.V.rms):500V
Withstand Voltage(AC.V)1min:2500V
Contact Resistance:<1mOhm
Durability:>1500 mating & unmating cycles
Temperature Rating:-40C80C

Reliable Waterproof Connection for Harsh Environments

Designed with an IP67 rating, the LP20 500V 20A 4Pin Male Plug delivers a waterproof and dustproof solution ideal for outdoor and industrial power sources. Its O-ring and threaded coupling mechanism, combined with a flame-retardant shell, ensure maximum durability and reliability in wet, dusty, or high-stress conditions.

High Performance and Safety Standards

Supporting up to 500V and 20A with low contact resistance (< 5 m) and high insulation resistance (> 2000 M), the LP20 plug guarantees safe, efficient power distribution. CE and RoHS compliance, gold-plated copper alloy contacts, and a mechanically strong plastic+metal shell add to its robust design and operational safety.

Versatile and Easy to Install

This connector features solder terminals for a secure interface and supports a cable range of 1.5mm2 to 2.5mm2, making installation straightforward. Its cable mount design and screw-type locking mechanism ensure quick, reliable assembly in a variety of applications, from outdoor LED lighting to complex industrial automation systems.

FAQ's of LP20 500V 20A 4Pin Male Plug IP67 Waterproof Power Connector Plastic+Metal Shell Solder Terminal:

Q: How do I install the LP20 500V 20A 4Pin Male Plug?

A: To install the LP20 plug, strip your cable to fit the supported 1.5mm2-2.5mm2 range, solder the wires onto the gold-plated contact pins, and secure the cable using the screw-type locking mechanism. Ensure the O-ring is in place for maximum waterproofing before coupling the plug.

Q: What are the main benefits of using this connector for outdoor equipment?

A: This connector offers robust waterproofing (IP67), corrosion resistance, and mechanical strength, making it ideal for outdoor and industrial environments. The flame-retardant shell and gold-plated contacts ensure safe and stable power connections, even in harsh conditions.

Q: When is this connector suitable for use?

A: Use the LP20 plug whenever you need a secure, watertight, and durable power connection, especially in outdoor applications, high-moisture environments, or anywhere reliable power distribution is essential, such as LED lighting, automation, or industrial power equipment.

Q: Where can I use the LP20 4Pin male plug?

A: This connector is widely used in outdoor power supplies, LED lighting installations, industrial automation setups, and anywhere a rugged, waterproof, high-current connector is required. It is commonly applied in both commercial and industrial sectors.

Q: What is the process for ensuring proper sealing and waterproofing?

A: Proper sealing involves making sure the O-ring remains intact during assembly and the threaded coupling is tightly secured. This combination ensures an IP67-rated seal, making the connection resistant to water and dust ingress.

Q: How does this connector ensure long-term durability?

A: The LP20 is crafted with a plastic+metal shell and features gold-plated copper alloy contacts for corrosion resistance. It is rated for over 500 mating cycles, and the flame-retardant material (UL94-V0) further adds to its longevity and safety.

Q: What safety standards does the LP20 connector meet?

A: The connector complies with CE and RoHS standards, has high insulation resistance, can withstand up to 1500V AC for 1 minute, and features flame-retardant materials. These certifications ensure safe operation in a range of electrical systems.
