YM20 500V 10A 5Pin Female Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal

Name: YM20 500V 10A 5Pin Female Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 495.0 INR
Availability: InStock

495.0 INR/Piece

Get a Price/Quote

Product Details:

Input Solder Terminal
Features Waterproof, Dustproof, Corrosion-resistant, Firm connection
Output 5 Pin Female Plug
Power Source Mains powered
IP Rating IP67
Power Supply AC/DC
Operating Temperature -40C to +85C
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YM20 500V 10A 5Pin Female Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal Price And Quantity

Price 495.0 INR/Piece
Minimum Order Quantity 100 Piece

YM20 500V 10A 5Pin Female Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal Product Specifications

IP Rating IP67
Color Black
Usage Industrial Connectors
Components Plastic Shell, Solder Terminals
Power Source Mains powered
Interface 5-Pin Solder Terminal
Supply Voltage 500V max
Output 5 Pin Female Plug
Size YM20
Input Solder Terminal
Features Waterproof, Dustproof, Corrosion-resistant, Firm connection
Frequency 50/60Hz
Current Rating 10A
Rated Voltage 500V
Product Type Waterproof Power Connector
Application Outdoor and harsh environment electrical connections
Operating Temperature -40C to +85C
Weight Approx 48g
Capacity 10A
Power Supply AC/DC
Function Power connector for electrical equipment
Dimension (L*W*H) Approx 85mm x 34mm (Diameter x Length)

Number of Pins 5
Shell Material High-strength plastic
Environmental Protection Weatherproof, Oil-resistant
Locking Mechanism Threaded coupling
Contact Resistance 5 m
Insulation Resistance >2000 M at 500V DC
Cable Outer Diameter Compatibility 7mm - 12mm
Storage Temperature -40C to +85C
Mounting Method Panel mount
Contact Material Copper alloy
Applicable Standards RoHS Compliant
Connector Type Panel Mount Female Plug
Flame Retardant Rating UL94-V0

YM20 500V 10A 5Pin Female Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:500V
Withstanding voltage:2500V
Insertion and extraction force:8.2N Max
Mating cycle:1700 Times
Screw torque:42-53 (N.m)
Temperature and humidity:-4080C; 40C, 85%RH

Exceptional Environmental Protection

Engineered to meet IP67 standards, the YM20 power connector offers impressive resistance against water, dust, and harsh environmental conditions, making it perfect for demanding industrial and outdoor applications. Its oil-resistant properties further ensure reliable operation in challenging settings where conventional connectors may fail.

Reliable and Safe Power Connection

Featuring a flame-retardant UL94-V0 plastic shell and copper alloy contacts, this connector delivers both safety and stability. Its threaded coupling mechanism ensures a secure fit, preventing accidental disconnects and ensuring continuous power, making it suitable for vital systems and equipment.

Simple Panel Mount Installation

The YM20 is designed for panel-mount integration, supporting a quick and straightforward mounting process. Its solder terminals ensure robust electrical connections that withstand vibration and mechanical stress, promoting longevity and reducing maintenance requirements for industrial operations.

FAQ's of YM20 500V 10A 5Pin Female Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal:

Q: How is the YM20 5Pin Female Plug installed into a control panel?

A: The YM20 connector is specifically designed for panel mount installation. Simply insert the connector through the mounting hole of the panel, then secure it using the threaded coupling to ensure a firm and stable fit. Electrical connections are made by soldering wires to the designated terminals.

Q: What environments is this waterproof power connector suitable for?

A: With its IP67 rating and durable, oil-resistant plastic shell, the YM20 connector excels in outdoor, industrial, and harsh environments. It withstands exposure to water, dust, oils, and extreme temperatures ranging from -40C to +85C, providing reliable performance where ruggedness is essential.

Q: When is it beneficial to use a flame-retardant, high-strength plastic shell connector?

A: A flame-retardant, high-strength shell, such as the UL94-V0 rated plastic in the YM20, is particularly beneficial when equipment is used in areas susceptible to high temperatures or fire hazards. It enhances the safety of electrical systems by preventing the spread of flame and adding robustness to withstand mechanical stress.

Q: Where can the YM20 5Pin Female Plug be used?

A: This connector is ideal for use in industrial machinery, outdoor power systems, and distributed equipment where secure, weatherproof connections are required. Its compliance with RoHS standards and exceptional durability make it suitable for export and use in strict regulatory environments, such as in Namibia and beyond.

Q: What is the process for connecting wires to this plug?

A: To connect wires to the YM20, strip the cable ends to expose the conductive cores, then carefully solder each wire to the appropriate terminal on the connector. Ensure insulation is intact and use heat shrink tubing for additional protection, if needed, before securing the connector in place.

Q: How does the threaded locking mechanism benefit the connection?

A: The threaded coupling provides superior mechanical stability, preventing accidental loosening due to vibrations or external forces. This secure fit ensures uninterrupted power transmission, making it ideal for machinery and equipment operating in dynamic or mobile environments.

Q: What are the key usage advantages of the YM20 5Pin Female Plug in industrial setups?

A: The YM20 offers a reliable, high-capacity electrical connection (10A, 500V) in a corrosion-resistant, waterproof form factor, simplifying maintenance and enhancing system safety. Its robust design withstands environmental and operational stresses, reducing downtime and ensuring continuous equipment operation.
