LP16 250V 5A 5Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal

241.0 INR/Piece

Get a Price/Quote

Product Details:

IP Rating IP67
Usage Outdoor and indoor electronic devices, industrial control equipment
Features Waterproof, dustproof, vibration resistant, easy installation, secure locking
Components Plastic shell, 5 pin socket, solder terminals, sealing washer
Power Source External wired connection
Interface Solder terminal 5 pin female socket
Power Supply Wired
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP16 250V 5A 5Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 241.0 INR/Piece

Relative Humidity 95%
Contact Material Copper alloy with gold plating
Mounting Type Panel mount
Locking System Threaded coupling with gasket
Mechanical Life >500 mating cycles
Connection Method Solder
Insulation Resistance >1000M at 500V DC
Pins Configuration 5 pins female
Contact Resistance 5m
Sealing Gasket Silicone rubber
Flame Resistance UL94-V0
Cable Diameter Range 5-8mm
Shell Material High-strength plastic (PA66)

LP16 250V 5A 5Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal Product Specifications

Power Source External wired connection
Input Solder Terminal
Weight Approx. 23g
Product Type Waterproof Power Connector
Color Black
Output 5 Pin Female Socket
Dimension (L*W*H) Approx. 55mm x 22mm x 22mm
Frequency 50/60Hz
Rated Voltage 250V AC/DC
Function Power connection for electronic equipment in harsh environments
Size LP16 (16mm panel cut-out)
Current Rating 5A
Interface Solder terminal 5 pin female socket
IP Rating IP67
Application LED lighting, automation, machinery, outdoor equipment
Thickness Shell wall approx. 2mm
Usage Outdoor and indoor electronic devices, industrial control equipment
Supply Voltage 250V
Power Supply Wired
Operating Temperature -20C to +80C
Capacity 5A max current per pin
Features Waterproof, dustproof, vibration resistant, easy installation, secure locking
Components Plastic shell, 5 pin socket, solder terminals, sealing washer

Relative Humidity 95%
Contact Material Copper alloy with gold plating
Mounting Type Panel mount
Locking System Threaded coupling with gasket
Mechanical Life >500 mating cycles
Connection Method Solder
Insulation Resistance >1000M at 500V DC
Pins Configuration 5 pins female
Contact Resistance 5m
Sealing Gasket Silicone rubber
Flame Resistance UL94-V0
Cable Diameter Range 5-8mm
Shell Material High-strength plastic (PA66)

LP16 250V 5A 5Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting mode:Easy locking type
Insertion and extraction force:1.5N Max
Wire specification:UL2464 24AWG*2C
Contact dimension:Phi 1.0x5
Temperature and humidity:-4080C, 40C, 85%RH
Mating cycle:>1700 times
Operating Voltage:250V
Diameter range:36mm
Screw torque:42-53 (N.m)

Reliable Waterproof Performance

With its IP67 certification, silicone rubber gasket, and rugged threaded coupling, the LP16 socket offers excellent sealing against water and dust ingress. Its high-strength plastic shell adds impact resistance, ensuring reliable operation in both indoor and outdoor environments.

Versatile Applications Across Industries

Engineered for use in industrial control, automation, LED lighting, and outdoor machinery, the LP16 connector is perfect wherever secure and weatherproof power connections are critical. Its compatibility with 5-8mm cables and panel mount design facilitate broad integration.

Superior Safety and Durability

Utilizing flame-resistant materials (UL94-V0 rated), gold-plated contacts for low resistance, and a 500+ mechanical life, this socket upholds industry standards for safety and longevity. It consistently delivers dependable power connections even in harsh conditions.

FAQ's of LP16 250V 5A 5Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal:

Q: How do I install the LP16 5-Pin Female Socket on a panel?

A: To install, first prepare a 16mm diameter panel cut-out and place the socket through the hole. Secure it with the included sealing washer and use the threaded coupling to fasten tightly, ensuring a water and dustproof connection.

Q: What devices or environments is this connector best suited for?

A: The LP16 5-pin connector is ideal for both outdoor and indoor electronic equipment, such as LED lighting, automation systems, industrial control equipment, and machinery that require resilient waterproof and dustproof power connections.

Q: What are the benefits of the IP67 waterproof rating for this connector?

A: An IP67 waterproof rating means the connector can withstand immersion in water up to 1 meter and blocks out dust completely. This ensures its reliability in wet, dusty, or harsh environments, greatly extending equipment lifespan.

Q: What process is used for making electrical connections with this socket?

A: The LP16 socket features solder terminals. Wires are prepared, inserted into the terminals, and then soldered for a secure, low-resistance connection. This method is robust and suitable for industrial applications.

Q: When should I choose a socket with a gold-plated copper alloy contact?

A: Gold-plated copper alloy contacts minimize oxidation and contact resistance, making them the preferred choice in applications where consistent, long-term electrical performance and vibration resistance are necessary.

Q: What is the maximum current and voltage supported by each pin?

A: Each pin of the LP16 female socket supports up to 5A of current and 250V AC/DC, providing ample capacity for most industrial and electronic power applications.

Q: Where is this connector typically mounted, and how does it secure the connection?

A: This connector is designed for panel mounting, usually installed on equipment enclosures or distribution boxes. The threaded coupling with a silicone gasket ensures a secure, waterproof fit that withstands vibration and environmental exposure.
