LP16 400V 10A 2Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal

Name: LP16 400V 10A 2Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 326.0 INR
Availability: InStock

326.0 INR/Piece

Get a Price/Quote

Product Details:

Power Source Mains
Usage Industrial power applications, outdoor equipment
Output Electrical connection interface
IP Rating IP67
Features Waterproof, dustproof, corrosion resistant, flame-retardant, easy installation
Components Plastic shell, solder terminals, sealing gaskets
Interface Solder terminal
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP16 400V 10A 2Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal Price And Quantity

Price 326.0 INR/Piece
Minimum Order Quantity 100 Piece

Mechanical Lock Twist lock mechanism
Contact Resistance 2.5m
Mating Cycle Durability >500 cycles
Connection Method Solder terminal connection
Insulation Resistance >500M at 500V DC
Contact Material Brass with silver plating
Mounting Style Cable mount, panel mount with optional accessories
Cable Diameter Range 6mm to 8mm
Wire Gauge Compatibility 18-14 AWG
Sealing Ring Material Silicone rubber
Environmental Protection UV resistant, suitable for outdoor use
Shell Material Plastic (PA66, flame retardant)
Connector Type 2-pin male plug
Standards Compliance IEC 60529, CE certified
Flammability Rating UL94-V0

LP16 400V 10A 2Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal Product Specifications

Current Rating 10A
Components Plastic shell, solder terminals, sealing gaskets
Capacity 10A current capacity
Application LED lighting, machinery, industrial automation, outdoor power connection
Size LP16 series
Frequency 50/60Hz compatible
Power Supply AC
Operating Temperature -25C to +85C
Supply Voltage 400V AC
IP Rating IP67
Input 2-pin male connector
Output Electrical connection interface
Features Waterproof, dustproof, corrosion resistant, flame-retardant, easy installation
Color Black
Product Type Power Connector Plug
Interface Solder terminal
Power Source Mains
Function Provides waterproof electrical power connection
Weight Approx. 30g
Rated Voltage 400V
Thickness Standard shell thickness
Usage Industrial power applications, outdoor equipment
Dimension (L*W*H) Approx. 62.5mm x 23mm x 23mm

Mechanical Lock Twist lock mechanism
Contact Resistance 2.5m
Mating Cycle Durability >500 cycles
Connection Method Solder terminal connection
Insulation Resistance >500M at 500V DC
Contact Material Brass with silver plating
Mounting Style Cable mount, panel mount with optional accessories
Cable Diameter Range 6mm to 8mm
Wire Gauge Compatibility 18-14 AWG
Sealing Ring Material Silicone rubber
Environmental Protection UV resistant, suitable for outdoor use
Shell Material Plastic (PA66, flame retardant)
Connector Type 2-pin male plug
Standards Compliance IEC 60529, CE certified
Flammability Rating UL94-V0

LP16 400V 10A 2Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Withstanding Voltage:2500V
Temperature Rise:10A 30C ,12A 40C ,15A 50C
Insertion and Extraction Force:1.2N Max
Working Temperature:-4080C
Connection Mode:Quick plug connection
Operating Voltage:400V

Reliable and Versatile Power Connection

The LP16 400V 10A 2Pin Male Plug is engineered to deliver dependable electrical connections in industrial and outdoor environments. Its IP67 waterproof and dustproof design, along with robust flame-retardant housing, makes it ideal for use in harsh conditions. Compatible with a range of wire gauges and mounting options, it fits a variety of power applications including machinery, LED lighting, and industrial automation systems.

Engineered for Safety and Durability

This connector features a twist-lock mechanical lock, silicone rubber seals, and a rugged PA66 housing, providing superior resistance to moisture, dust, UV rays, and corrosion. The internal components use silver-plated brass for low contact resistance and high insulation, ensuring operational safety. Its compliance with IEC 60529 and CE certification further underscores its reliability and top-notch build quality.

FAQ's of LP16 400V 10A 2Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal:

Q: How does the LP16 2Pin Male Plug achieve its waterproof rating?

A: The LP16 connector utilizes a silicone rubber sealing ring and a tightly fitted flame-retardant PA66 plastic shell, which together deliver IP67-rated protection. This ensures it remains waterproof and dustproof, making it highly suitable for outdoor installations and industrial settings.

Q: What are the recommended applications for this connector?

A: This connector is ideal for industrial power supply, outdoor equipment, LED lighting, machinery, and automation systems. Its robust, UV-resistant construction and broad application range make it suitable for both indoor and outdoor environments that demand reliable power connections.

Q: Where can the LP16 2Pin Plug be mounted?

A: The LP16 plug supports both cable mounting and panel mounting with optional accessories, offering installation flexibility for various configurations in equipment or distributed power networks.

Q: What process is involved in connecting wires to this plug?

A: Connecting wires is done via the solder terminal interface. Wires with gauges between 18-14 AWG can be securely soldered to the brass terminals, ensuring a stable, low-resistance connection for consistent electrical performance.

Q: What are the key benefits of using this connector in industrial applications?

A: Key benefits include excellent waterproofing (IP67), high current and voltage support (10A, 400V AC), flame-retardant and corrosion-resistant materials, secure twist lock mechanism, and compatibility with a wide range of cable diameters and wire gauges. All these features contribute to reliable, durable, and safe power connections.

Q: When should I choose this connector for my project?

A: Choose the LP16 2Pin Male Plug when you need a secure, waterproof, and durable electrical connection, especially in environments exposed to moisture, dust, or mechanical stress, such as outdoor installations or heavy-duty industrial settings.

Q: What standards and certifications does this product comply with?

A: This product is CE certified and conforms to the IEC 60529 standard for ingress protection, assuring you of its high quality, safety, and suitability for global industrial markets.
