LP12 125V 5A 2Pin Female Plug IP67 Inline Waterproof Power Connector

180.0 INR/Piece

Get a Price/Quote

Product Details:

Output 2 Pin Connection
Components Shell, Insert, Sealing Gasket, Contacts
Features Inline Design, Waterproof, Dustproof, Easy Installation, Corrosion Resistant
Input 2 Pin Female
Interface 2 Pin Female Plug
IP Rating IP67
Operating Temperature -40C to +85C
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP12 125V 5A 2Pin Female Plug IP67 Inline Waterproof Power Connector Price And Quantity

Price 180.0 INR/Piece
Minimum Order Quantity 100 Piece

LP12 125V 5A 2Pin Female Plug IP67 Inline Waterproof Power Connector Product Specifications

Capacity 5A
Power Supply AC
Output 2 Pin Connection
Color Black
Product Type Inline Waterproof Power Connector
Application Power Supply, LED Lighting, Industrial Automation, Electrical Wiring
Thickness Approx. 19 mm (Outer diameter)
Components Shell, Insert, Sealing Gasket, Contacts
Usage Outdoor/Indoor Electrical Equipment
Current Rating 5A
Features Inline Design, Waterproof, Dustproof, Easy Installation, Corrosion Resistant
Weight Approx. 40g
Dimension (L*W*H) Approx. 65mm (Length) x 19mm (Diameter)
Size LP12 Series
Supply Voltage 125V
Function Power Connection
Input 2 Pin Female
Rated Voltage 125V AC
IP Rating IP67
Interface 2 Pin Female Plug
Frequency 50/60Hz
Power Source Electric
Operating Temperature -40C to +85C

Cable Diameter Range 4.5mm to 7mm
Contact Resistance 5m
Insulation Resistance > 500M at 500V DC
Contact Plating Tin Plated
Connector Type Female Plug
Flame Retardant Level UL94-V0
Material Nylon PA66, Copper Alloy Contacts
Mounting Type Inline/Cable Mount
Sealing Method Screw Lock, Rubber Gasket
Withstand Voltage 1500V AC/minute
Mechanical Life >= 3000 Mating Cycles

LP12 125V 5A 2Pin Female Plug IP67 Inline Waterproof Power Connector Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting mode:Easy locking type
Insertion and extraction force:0.6N Max
Wire specification:UL246424AWG*2C
Rated Current:5A
Contact dimension:Phi 1.0x2
Temperature and humidity:-4080C, 40C, 85%RH
Mating cycle:1700 times

Reliable and Durable Construction

Engineered with high-quality Nylon PA66 and copper alloy contacts, the LP12 series ensures excellent mechanical strength and electrical performance. The connector's flame-retardant shell, corrosion-resistant body, and robust design guarantee extended service life and safety, even under demanding conditions.

Designed for Seamless Outdoor and Indoor Use

With an IP67 rating and a comprehensive sealing system using a screw lock and rubber gasket, the LP12 Female Plug delivers waterproof and dustproof protection. It withstands challenging environments, making it suitable for outdoor electrical systems, LED installations, and industrial automation equipment.

Effortless Installation and Flexible Application

The inline/cable mount design facilitates quick, straightforward installation with minimal tools. Supporting a cable diameter range of 4.5mm to 7mm, it adapts to diverse wiring requirements, enhancing its usability in both new and retrofit electrical setups.

FAQ's of LP12 125V 5A 2Pin Female Plug IP67 Inline Waterproof Power Connector :

Q: How do I install the LP12 2Pin Female Plug?

A: To install the LP12 2Pin Female Plug, strip the cables to fit the 4.5mm-7mm diameter range, connect the conductors to the tin-plated copper alloy contacts inside the connector, then screw-lock the housing securely with the included rubber gasket to achieve waterproof sealing.

Q: What applications is this connector best suited for?

A: The LP12 connector is ideal for power supply, LED lighting, industrial automation, and general electrical wiring, both indoors and outdoors, thanks to its reliable performance, IP67 waterproof rating, and flame-retardant construction.

Q: When should I use this waterproof connector?

A: Use the LP12 connector when you need secure, weather-resistant power connections for AC electrical equipment, particularly in environments prone to moisture, dust, or outdoor exposure.

Q: Where can the LP12 2Pin Female Plug be effectively used?

A: It can be used in residential, commercial, and industrial settings-anywhere you require durable, waterproof power connectors, such as outdoor lighting installations, automation systems, and heavy-duty electrical wiring.

Q: What benefits does the screw lock and rubber gasket sealing offer?

A: The screw lock and rubber gasket ensure a tight, waterproof seal (IP67), protecting internal contacts from water and dust ingress, thus extending connector longevity and enhancing operational safety.

Q: How does the connector ensure electrical safety and reliability?

A: The LP12 plug is flame-retardant (UL94-V0), withstands up to 1500V AC, and offers both low contact resistance and high insulation resistance, minimizing electrical risks and ensuring stable power connections.
