LP12 5A 3Pin Male Plug IP67 Waterproof Power Connector

731.0 INR/Piece

Get a Price/Quote

Product Details:

Power Source Mains powered
Power Supply Electrical
Components Male plug, sealing gasket, termination screws
IP Rating IP67
Output AC Power
Features Waterproof, dustproof, corrosion-resistant, robust plastic housing
Interface Screw or solder termination
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP12 5A 3Pin Male Plug IP67 Waterproof Power Connector Price And Quantity

Minimum Order Quantity 100 Piece
Price 731.0 INR/Piece

Contact Material Copper alloy, gold plated
Locking Mechanism Threaded coupling
Number of Pins 3 pin male connector
Standards Compliance CE, RoHS
Cable Diameter Range 4mm - 6.5mm
Mating Cycles >500 cycles
Ingress Protection Completely protected against dust and temporary immersion in water
Shell Material High-strength plastic (PA66)
Mounting Type Panel mount or inline cable connection
Flame Retardant Rating UL94-V0

LP12 5A 3Pin Male Plug IP67 Waterproof Power Connector Product Specifications

Supply Voltage 250V max
Rated Voltage 250V AC
Application LED lighting, outdoor signage, industrial automation
Capacity 5A, 3 pin
IP Rating IP67
Output AC Power
Frequency 50-60Hz
Product Type Waterproof Power Connector
Color Black
Power Supply Electrical
Components Male plug, sealing gasket, termination screws
Dimension (L*W*H) Approx. 58mm (L) x 20mm (D)
Current Rating 5A
Power Source Mains powered
Operating Temperature -25C to +85C
Thickness Standard
Function Power connection
Weight Approx. 25g
Usage Outdoor and industrial equipment
Input AC Power
Size 12mm mating diameter
Features Waterproof, dustproof, corrosion-resistant, robust plastic housing
Interface Screw or solder termination

Contact Material Copper alloy, gold plated
Locking Mechanism Threaded coupling
Number of Pins 3 pin male connector
Standards Compliance CE, RoHS
Cable Diameter Range 4mm - 6.5mm
Mating Cycles >500 cycles
Ingress Protection Completely protected against dust and temporary immersion in water
Shell Material High-strength plastic (PA66)
Mounting Type Panel mount or inline cable connection
Flame Retardant Rating UL94-V0

LP12 5A 3Pin Male Plug IP67 Waterproof Power Connector Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting mode:Plug(Male Pin)
Wire specification:UL246424AWG*2C
Rated Current:5A
Contact dimension:Phi 1.0x2
Temperature and humidity:-40+80C; 40C,85%RH
Mating cycle:1700 times
Operating Voltage:250v

Superior Waterproof and Dustproof Design

Built to the IP67 standard, this connector provides complete dust protection and withstands temporary water immersion. Its robust housing ensures long-term reliability in challenging outdoor and industrial environments, making it ideal for applications exposed to moisture, dust, or rain.

Easy and Versatile Installation Options

The LP12 connector offers flexibility with both panel mount and inline cable configurations. With a simple threaded coupling mechanism and compatibility with screw or solder terminations, installation is straightforward for professional electricians and hobbyists alike.

Reliable Performance and Safety

Operating at up to 250V AC and 5A, with gold-plated copper alloy contacts, this connector maintains excellent conductivity and low contact resistance. Certified to UL94-V0 flame retardant, CE, and RoHS standards, it guarantees high safety and consistent functionality.

FAQ's of LP12 5A 3Pin Male Plug IP67 Waterproof Power Connector:

Q: How does the LP12 5A 3Pin Male Plug ensure waterproof and dustproof performance?

A: The LP12 connector achieves IP67 protection, providing complete resistance against dust and temporary immersion in water. This is made possible by its precision-sealed design and high-strength PA66 plastic construction, making it suitable for outdoor and industrial applications.

Q: What is the recommended process for installing this connector in a power system?

A: For installation, the LP12 connector can be panel-mounted or used in an inline configuration. Prepare the cable (4mm-6.5mm diameter), attach the male plug using either screw or solder terminals, and securely fasten the connector via threaded coupling for a watertight seal.

Q: When should this power connector be used over standard plugs?

A: This connector is best used in environments requiring enhanced sealing, durability, and electrical safety-such as outdoor LED systems, signage, and industrial automation-where standard plugs may fail due to moisture, dust, or harsh conditions.

Q: Where can the LP12 3Pin connector be applied?

A: It is suitable for powering outdoor and industrial devices like LED lighting, electronic signboards, automation equipment, and any AC application requiring a robust, low-maintenance connection.

Q: What are the main benefits of the gold-plated copper alloy contacts?

A: Gold-plated copper alloy contacts offer superior conductivity and resist corrosion, ensuring stable current flow and long-term reliable performance, even in demanding environments.

Q: How many mating cycles can the connector withstand?

A: The LP12 connector is rated for more than 500 mating cycles, guaranteeing a long service life even when used in setups that require frequent plugging and unplugging.

Q: Is this connector compliant with safety and quality standards?

A: Yes, it meets UL94-V0 flame-retardant requirements and is CE and RoHS certified, ensuring electrical safety, environmental responsibility, and adherence to industry regulations.
