LP12 Series 150V 5A 6Pin Female Inline IP67 Waterproof Power Connector Plastic Shell Solder Terminal

272.0 INR/Piece

Get a Price/Quote

Product Details:

Interface Solder terminal, 6 pins
Input Depends on wires terminated, supports up to 5A 150V
Output Inline cable output
Power Supply AC/DC
Components Plastic shell, 6 solder terminals, sealing ring
Power Source External electrical power
Usage Power transmission in harsh/outdoor environments
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP12 Series 150V 5A 6Pin Female Inline IP67 Waterproof Power Connector Plastic Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 272.0 INR/Piece

Cable Diameter Range 4mm - 8mm
Flame Rating UL94 V-0
Mechanical Life >1000 mating cycles
Sealing Method Integrated O-ring gasket
Mounting Type Inline cable mount
Material High-quality plastic shell
Contact Resistance 5m
RoHS Compliance Yes
Connection Type Female socket, solder termination
Number of Pins 6 (female)
Insulation Resistance >500M at 500V DC
Contact Material Copper alloy with gold-plated contacts

LP12 Series 150V 5A 6Pin Female Inline IP67 Waterproof Power Connector Plastic Shell Solder Terminal Product Specifications

Operating Temperature -25C to +80C
Rated Voltage 150V
Features Dustproof, waterproof, corrosion resistant, quick connect/disconnect
Usage Power transmission in harsh/outdoor environments
Frequency DC/50-60Hz AC
IP Rating IP67
Function Waterproof power connection for inline cable applications
Size M12 (panel cutout diameter approx. 12 mm)
Components Plastic shell, 6 solder terminals, sealing ring
Power Source External electrical power
Capacity 5A per contact
Color Black
Power Supply AC/DC
Thickness Approx. 21 mm diameter
Application LED lighting, industrial equipment, outdoor machinery, automation
Output Inline cable output
Input Depends on wires terminated, supports up to 5A 150V
Supply Voltage 150V max
Interface Solder terminal, 6 pins
Current Rating 5A max
Dimension (L*W*H) Approx. 64mm (L) x 21mm ()
Product Type Inline Waterproof Power Connector
Weight Approx. 18g

Cable Diameter Range 4mm - 8mm
Flame Rating UL94 V-0
Mechanical Life >1000 mating cycles
Sealing Method Integrated O-ring gasket
Mounting Type Inline cable mount
Material High-quality plastic shell
Contact Resistance 5m
RoHS Compliance Yes
Connection Type Female socket, solder termination
Number of Pins 6 (female)
Insulation Resistance >500M at 500V DC
Contact Material Copper alloy with gold-plated contacts

LP12 Series 150V 5A 6Pin Female Inline IP67 Waterproof Power Connector Plastic Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting mode:Easy locking type
Insertion and extraction force:1.8N Max
Wire specification:UL246424AWG*2C
Rated Current:5A
Contact dimension:Phi 1.0x6
Temperature and humidity:-4080C, 40C,85%RH
Mating cycle:>1700 times

Rugged Waterproof Design

Rated at IP67, this connector is constructed to withstand outdoor and industrial conditions. The integrated O-ring gasket and corrosion-resistant materials protect against dust, water, and environmental hazards, ensuring uninterrupted performance even in harsh applications.

Reliable Electrical Performance

Gold-plated contacts within a copper alloy structure minimize contact resistance and support up to 5A per pin at 150V. High insulation resistance (>500M at 500V DC) and a UL94 V-0 flame rating deliver secure power connections for sensitive equipment.

Versatile Application

Ideal for demanding installations, the LP12 Series connector is suitable for LED lighting, industrial automation, outdoor machinery, and more. Its inline female socket, robust plastic shell, and convenient solder terminals support a wide range of power transmission needs.

FAQ's of LP12 Series 150V 5A 6Pin Female Inline IP67 Waterproof Power Connector Plastic Shell Solder Terminal:

Q: How is the LP12 Series 6Pin Power Connector installed?

A: The connector uses an inline cable mount with solder terminals. Wires are soldered to each of the six gold-plated pins, and the plastic shell is then secured. The integrated O-ring provides a tight seal when the device is assembled.

Q: What environments is this connector suitable for?

A: With its IP67 dustproof and waterproof rating, UL94 V-0 flame-resistant shell, and operating temperature range of -25C to +80C, this connector is perfect for both indoor and outdoor use, including harsh industrial and exposed environments.

Q: When should I choose this connector over other types?

A: Select this connector when you require a reliable, waterproof, and corrosion-resistant power connection for applications up to 150V and 5A, particularly where frequent unplugging or rugged conditions are expected, such as in automation or outdoor lighting.

Q: Where can the LP12 Series connector be used?

A: It's widely used in applications like LED lighting, industrial machinery, automation systems, and outdoor equipment. Its robust build makes it ideal for installations that demand secure power transmission in challenging settings.

Q: What is the connection process for this female 6-pin connector?

A: Solder each wire to its corresponding terminal, ensuring secure and proper contact. Once soldered, fit the cable into the shell, and tighten the assembly to ensure the O-ring gasket maintains the IP67 seal.

Q: How does this connector benefit my installation?

A: This connector simplifies quick connect/disconnect actions, reduces downtime for maintenance, and extends equipment lifespan through its durable build, gold-plated contacts, and superior environmental protection.

Q: What is the mechanical life and reliability of this product?

A: Tested for over 1,000 mating cycles and built with high-quality materials, this connector offers dependable, long-term use in rigorous electrical and environmental conditions, ensuring stable performance over time.
