YM20 10A 8Pin Female Socket IP68 Waterproof Power Connector Panel Mount Plastic Shell Solder Terminal

Name: YM20 10A 8Pin Female Socket IP68 Waterproof Power Connector Panel Mount Plastic Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 450.0 INR
Availability: InStock

450.0 INR/Piece

Get a Price/Quote

Product Details:

Features Waterproof, dustproof, panel mountable, corrosion resistant
Output 8-pin electrical connection
Interface Solder terminal, 8-pin
Power Source Cable powered
Components Connector body, panel mount nut, sealing ring
Operating Temperature -25C to +85C
Input 8-pin female socket
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YM20 10A 8Pin Female Socket IP68 Waterproof Power Connector Panel Mount Plastic Shell Solder Terminal Price And Quantity

Price 450.0 INR/Piece
Minimum Order Quantity 100 Piece

YM20 10A 8Pin Female Socket IP68 Waterproof Power Connector Panel Mount Plastic Shell Solder Terminal Product Specifications

Current Rating 10A
Rated Voltage 500V AC/DC
Power Supply External
Dimension (L*W*H) 37mm (diameter) x 59mm (length)
Size Shell size: YM20
Weight Approx. 32g
IP Rating IP68
Supply Voltage 500V max
Capacity 10A current per contact
Frequency 50/60Hz
Thickness Panel thickness compatibility: 2-6mm
Usage Wiring and cable connections for outdoor equipment
Input 8-pin female socket
Product Type Panel mount power connector
Operating Temperature -25C to +85C
Function Power transmission and distribution in industrial environments
Components Connector body, panel mount nut, sealing ring
Power Source Cable powered
Interface Solder terminal, 8-pin
Output 8-pin electrical connection
Application LED lighting, industrial equipment, machinery, automation
Color Black
Features Waterproof, dustproof, panel mountable, corrosion resistant

Shell Material High-strength plastic (nylon PA66)
Mating Cycle Durability >500 cycles
Contact Material Copper alloy with gold-plated contacts
Mounting Type Panel mount
Sealing Ring Material Silicone rubber
Compliance RoHS compliant
Locking Mechanism Threaded coupling
Cable Diameter Range 7mm to 12mm
Termination Method Solder terminal
Flame Retardant Grade UL94 V-0

YM20 10A 8Pin Female Socket IP68 Waterproof Power Connector Panel Mount Plastic Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:500V
Withstanding voltage:2500V
Insertion and extraction force:4.0N Max
Screw torque:42-53 (N.m)
Mating cycle:1700 Times
Temperature and humidity:-4080C; 40C, 85%RH
Contact dimension:Phi 2.7*2

Superior Waterproof Protection

With its IP68 waterproof rating and silicone rubber sealing ring, the YM20 8Pin Female Socket is engineered to prevent water ingress, making it suitable for harsh outdoor environments. Whether used in industrial lighting, automation, or heavy machinery, this connector maintains dependable performance and secure connections even when exposed to rain, dust, or moisture.

High-Performance Electrical Transmission

The connector's gold-plated copper alloy contacts and high-strength PA66 nylon shell ensure excellent conductivity, low contact resistance, and superior durability. It handles up to 10A per contact at voltages up to 500V AC/DC, meeting the high-current demands of industrial equipment and power distribution systems with consistent efficiency.

Versatile and Easy Installation

Designed for panel mounting, the YM20 connector accommodates a range of cable sizes (7-12mm) and panel thicknesses (2-6mm). Its threaded coupling mechanism and solder terminals enable straightforward installation and maintenance, allowing professionals to set up reliable wiring solutions quickly and safely in various applications.

FAQ's of YM20 10A 8Pin Female Socket IP68 Waterproof Power Connector Panel Mount Plastic Shell Solder Terminal:

Q: How is the YM20 8Pin Female Socket installed on panels?

A: The YM20 socket is designed for panel mounting. Simply insert the connector body through a pre-cut hole (suitable for its 37mm diameter), secure it with the included panel mount nut, and ensure the silicone rubber seal is in place to maintain waterproof protection. Solder your wires to the solder terminals before final assembly.

Q: What types of cables are compatible with this connector?

A: This connector supports cables with diameters ranging from 7mm to 12mm, making it suitable for a wide variety of power and signal cables commonly used in industrial and outdoor equipment wiring.

Q: When should this waterproof connector be used?

A: You should use the YM20 connector in applications that require robust protection against water, dust, and corrosion, such as outdoor LED lighting, industrial machines, and automation equipment-especially where exposure to harsh environments is expected.

Q: Where can this connector be applied within an industrial setup?

A: The YM20 8Pin Female Socket is ideal for installation on control panels, junction boxes, machinery housings, and other surfaces where secure and reliable power distribution or signal connections are necessary.

Q: What are the primary benefits of choosing the YM20 8Pin Female Socket?

A: Key benefits include its IP68 waterproof and dustproof performance, high-current and voltage capacity, flame-retardant housing, corrosion resistance, and long-term reliability over more than 500 mating cycles. Its RoHS compliance also aligns with modern safety and environmental standards.

Q: How does the threaded coupling mechanism enhance connector performance?

A: The threaded coupling ensures a tight and secure fit between the socket and plug, preventing accidental disconnection, while enhancing the integrity of the waterproof and dustproof seal.
