LP20 250V 5A 9Pin Male Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal

376.0 INR/Piece

Get a Price/Quote

Product Details:

IP Rating IP67
Interface 9 Pin Male Solder Terminal
Power Supply Electrical
Features Waterproof, Dustproof, Corrosion Resistant, Robust Metal Shell
Operating Temperature -20C to +85C
Power Source AC/DC Powered
Usage Industrial/Outdoor Equipment
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP20 250V 5A 9Pin Male Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 376.0 INR/Piece

LP20 250V 5A 9Pin Male Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal Product Specifications

Current Rating 5A
Weight Approx. 45g
Capacity 5A per pin
Operating Temperature -20C to +85C
Power Supply Electrical
Interface 9 Pin Male Solder Terminal
Features Waterproof, Dustproof, Corrosion Resistant, Robust Metal Shell
Frequency 50/60Hz
Product Type Waterproof Power Connector
Dimension (L*W*H) Approx. 38mm x 28mm (Diameter x Length)
IP Rating IP67
Rated Voltage 250V AC
Output 9 Pin Male Socket
Supply Voltage 250V AC Max
Components Male Socket, Metal Shell, Solder Contacts
Input Solder Terminal Connection
Color Silver (Metal Shell)
Thickness Standard Shell Thickness
Function Power/Signal Connector
Size LP20 Series
Power Source AC/DC Powered
Application LED Lighting, Automation, Outdoor Power Supply
Usage Industrial/Outdoor Equipment

Vibration Resistance IEC 60512-4 compliant
Contact Resistance <5m
Ingress Protection IP67 (Waterproof and Dustproof)
Flame Retardancy UL94-V0
Cable Diameter Range 6-12mm
Mounting Type Panel Mount
Contact Material Copper Alloy with Gold Plating
Insulation Resistance >2000M (at 500V DC)
Number of Pins 9
Locking Mechanism Threaded Coupling
Shell Material Zinc Alloy
Connector Type Male Socket
Mating Cycle Durability >500 cycles

LP20 250V 5A 9Pin Male Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting Mode:Quickly bayonet connect
Cable Specification:0.34mm2 0.75mm2 /22-20AWG
Diameter Range:7mm 10mm
Operating Voltage:400V
Withstand Voltage(AC.V)1min:1500V
Durability:> 500 mating & unmating cycles
Temperature Rating:-40C80C

Superior Durability and Reliability

Designed with a robust zinc alloy shell and gold-plated contacts, this connector delivers excellent protection against wear and environmental challenges. The IP67 rating ensures that it remains unaffected by dust and water, extending its service life even in tough conditions. With over 500 mating cycles and high resistance to vibration (IEC 60512-4 compliant), this connector is built for enduring performance in industrial applications.

Secure and Flexible Installation

The LP20 connector features a threaded coupling mechanism for secure panel mounting, reducing the risk of accidental disconnection. Supporting cable diameters from 6 to 12mm and solder terminal connections, it offers easy and flexible installation to accommodate various cable types and setups. Its compact design ensures compatibility with standard panel cut-outs and equipment housings.

Versatile Industrial and Outdoor Applications

Ideal for sectors such as automation, LED lighting, and outdoor power distribution, the connector supports both AC and DC power with a maximum supply voltage of 250V. Its flame-retardant UL94-V0 rating and wide operating temperature range (-20C to +85C) provide enhanced safety and reliability, making it suitable for a wide array of demanding environments in India and abroad.

FAQ's of LP20 250V 5A 9Pin Male Socket IP67 Waterproof Power Connector Metal Shell Solder Terminal:

Q: How do I install the LP20 9Pin Male Socket Power Connector for panel mounting?

A: To install the LP20 connector, prepare a suitable panel cut-out, insert the connector, and secure it in place using the threaded coupling system. Solder your wires to the corresponding pins, ensuring proper connections according to your device's wiring requirements. The connector is compatible with cables ranging from 6 to 12mm in diameter.

Q: What are the primary benefits of the IP67 waterproof and dustproof rating?

A: The IP67 rating ensures that the connector is completely protected against dust entry and can withstand temporary submersion in water. This makes it ideal for outdoor and industrial environments where exposure to harsh weather, moisture, and particulates is common.

Q: When should I use this connector in my industrial or outdoor applications?

A: This connector is best suited for situations where reliable power and signal transmission are essential, especially in challenging environments. Applications include LED lighting, automation systems, and outdoor power supplies where durability, safety, and resistance to vibration are required.

Q: Where can I source the LP20 250V 5A 9Pin connector in India?

A: The LP20 connector is available through distributors, exporters, importers, manufacturers, traders, and wholesalers across India. Check with your local industrial electrical suppliers for availability or contact authorized providers specializing in power connectivity solutions.

Q: What process should I follow for maintaining optimal performance?

A: Regularly inspect the connector for physical damage or corrosion. Ensure the threaded coupling is tight and that the connections are secure. Clean the contacts if needed and ensure the sealing remains intact to maintain the IP67 protection.

Q: What is the maximum current and voltage capacity per pin for this connector?

A: Each of the 9 pins can handle a maximum current of 5A with a rated voltage of up to 250V AC, making it suitable for both signal and power applications within these limits.

Q: How does the connector ensure safety and reliability in harsh environments?

A: The connector features a flame-retardant UL94-V0 shell, high insulation resistance, and vibration resistance per IEC 60512-4. Combined with the IP67 protection, sturdy metal shell, and secure coupling, these features guarantee safe and consistent operation in various challenging industrial settings.
