LP12 125V 5A 3Pin Male Plug IP67 Waterproof Power Connector

261.0 INR/Piece

Get a Price/Quote

Product Details:

Interface 3-pin male
Power Supply AC
Input 3-pin male connector
Operating Temperature -20C to +85C
Usage Outdoor and industrial waterproof connection
Components Male plug, contacts, outer shell
Output Electrical power transmission
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP12 125V 5A 3Pin Male Plug IP67 Waterproof Power Connector Price And Quantity

Minimum Order Quantity 100 Piece
Price 261.0 INR/Piece

LP12 125V 5A 3Pin Male Plug IP67 Waterproof Power Connector Product Specifications

Function Male plug for waterproof power connections
Frequency 50/60 Hz
Current Rating 5A
Usage Outdoor and industrial waterproof connection
IP Rating IP67
Output Electrical power transmission
Components Male plug, contacts, outer shell
Dimension (L*W*H) Approx. 55 mm (L) x 20 mm (D)
Features Waterproof, dustproof, robust, quick-connect, anti-corrosion
Power Source Electrical
Application LED lighting, outdoor equipment, industrial machinery
Capacity 5A
Color Black
Thickness Standard
Size LP12 series
Operating Temperature -20C to +85C
Input 3-pin male connector
Rated Voltage 125V
Product Type Waterproof Power Connector
Power Supply AC
Weight 18g
Interface 3-pin male
Supply Voltage 125V AC

Insulation Resistance >500 M at 500V DC
Contact Resistance 5 m
Sealing Method Silicone gasket
Mounting Type Cable mount
Locking System Bayonet
Contact Material Copper with gold plating
Housing Material High strength flame-retardant plastic
Dielectric Withstanding Voltage 1500V AC/minute
Flame Retardant Standard UL94 V-0
Cable Range 4-6.5 mm
Mating Cycles >500 times

LP12 125V 5A 3Pin Male Plug IP67 Waterproof Power Connector Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting mode:Easy locking type
Wire specification:UL246424AWG*2C
Rated Current:5A
Contact dimension:Phi1.0x3
Temperature and humidity:-4080C
Mating cycle:1700 times
Operating Voltage:125v

Engineered for Extreme Conditions

Built to withstand harsh environments, this connector boasts an IP67 waterproof rating, superior insulation, and a broad operating temperature range. Its high-strength, flame-retardant housing ensures durability in demanding outdoor and industrial settings, making it perfect for applications where reliability is non-negotiable.

Quick, Secure, and Reliable Connections

Featuring a bayonet locking system and advanced silicone gasket sealing, the LP12 plug offers rapid installation and robust sealing against water and dust. Its gold-plated copper contacts reduce resistance and maintain optimal performance with over 500 mating cycles, ensuring hassle-free long-term usage.

Versatile Applications and Safety Compliance

Compliant with UL94 V-0 flame retardancy standards, this power connector suits LED lighting, industrial equipment, and more. Supporting AC supply voltage up to 125V and current up to 5A, the LP12 guarantees safe, consistent power in distribution, manufacturing, and integration use cases.

FAQ's of LP12 125V 5A 3Pin Male Plug IP67 Waterproof Power Connector :

Q: How do I install the LP12 125V 5A 3Pin Male Plug for outdoor connections?

A: To install, strip your cable (4-6.5 mm), attach the wires to the gold-plated copper contacts, and assemble the connector body. Ensure the silicone gasket is properly positioned, then use the bayonet locking system to securely fasten the plug, achieving a waterproof seal.

Q: What makes the LP12 connector suitable for industrial and outdoor use?

A: The LP12's high-strength flame-retardant plastic housing, gold-plated copper contacts, silicone gasket sealing, and IP67 waterproof rating protect against dust, water, heat, and corrosion, ensuring dependable operation in challenging environments.

Q: When should I use the LP12 3Pin Male Plug over other connectors?

A: Choose the LP12 when you require a 125V, 5A, 3-pin connector with superior waterproof, dustproof, anti-corrosion, and flame-retardant features, particularly for outdoor, LED lighting, and industrial machinery applications.

Q: Where can the LP12 3Pin Male Plug be effectively applied?

A: The connector is ideal for outdoor LED lighting setups, industrial equipment, machinery, and any context requiring robust, weatherproof electrical power connections.

Q: What is the process for ensuring the connector's waterproof protection?

A: The LP12 achieves its IP67 waterproof protection through a precise assembly of its silicone gasket and bayonet locking system. Always ensure these components are properly engaged during installation for maximum sealing.

Q: What are the main benefits of using this waterproof power connector?

A: Key benefits include enhanced safety from water and dust ingress, rapid and secure connections, long service life with over 500 mating cycles, and compliance with rigorous safety standards, making it a cost-effective solution for demanding applications.
