LP12 100V 3A 7Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal

271.0 INR/Piece

Get a Price/Quote

Product Details:

Thermal Conductivity Standard, Plastic Shell
Operating Temperature -25C to +85C
Power Supply AC/DC Universal
Input Up to 100V, 3A
Usage Outdoor/Industrial Applications
Components Plastic Shell, 7 Solder Terminals, IP67 Sealing Gasket
Interface 7 Pin Female Solder Terminal
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP12 100V 3A 7Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal Price And Quantity

Price 271.0 INR/Piece
Minimum Order Quantity 100 Piece

Number of Pins 7
Material Compliance RoHS Compliant
Contact Resistance <5m
Insulation Resistance >2000M at 500V DC
Mating Cycle Durability >500 cycles
Mounting Type Panel Mount
Shell Material High-Strength Plastic
Connector Gender Female Socket
Contact Material Brass with Tin Plating
Cable Diameter Range 4.5mm - 7mm
Flame Retardant Grade UL94-V0
Vibration Resistance Meet IEC 60512-6-4
Sealing Method Rubber Ring/Gasket

LP12 100V 3A 7Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal Product Specifications

IP Rating IP67
Output Up to 100V, 3A
Features Waterproof, Dustproof, Reliable Plastic Housing, Locked Connection, Easy Installation
Power Source Cable Connected/Electricity
Dimension (L*W*H) Approx. 50mm x 22mm x 22mm
Interface 7 Pin Female Solder Terminal
Product Type Waterproof Power Connector
Current Rating 3A
Components Plastic Shell, 7 Solder Terminals, IP67 Sealing Gasket
Function Power Connection and Signal Transmission
Size 12mm Panel Mount Diameter
Frequency 50/60Hz
Capacity 3A Max Current Carrying Capacity
Input Up to 100V, 3A
Usage Outdoor/Industrial Applications
Color Black
Operating Temperature -25C to +85C
Power Supply AC/DC Universal
Application LED Lighting, Industrial Equipment, Power Systems
Thermal Conductivity Standard, Plastic Shell
Supply Voltage 100V Max
Rated Voltage 100V
Weight Approx. 18g
Thickness Standard Shell Thickness

Number of Pins 7
Material Compliance RoHS Compliant
Contact Resistance <5m
Insulation Resistance >2000M at 500V DC
Mating Cycle Durability >500 cycles
Mounting Type Panel Mount
Shell Material High-Strength Plastic
Connector Gender Female Socket
Contact Material Brass with Tin Plating
Cable Diameter Range 4.5mm - 7mm
Flame Retardant Grade UL94-V0
Vibration Resistance Meet IEC 60512-6-4
Sealing Method Rubber Ring/Gasket

LP12 100V 3A 7Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting mode:Easy locking type
Insertion and extraction force:2.1N Max
Wire specification:UL246424AWG*2C
Rated Current:3A
Contact dimension:Phi 0.8x7
Temperature and humidity:-4080C, 40C,85%RH
Mating cycle:1700 times

Superior Waterproof and Dustproof Protection

Engineered with an IP67 rating and secure rubber gasket, the LP12 connector offers exceptional protection against water infiltration and dust particles, making it a reliable choice for demanding outdoor installations. This high level of sealing safeguards internal contacts, ensuring uninterrupted power and signal transmission in various environmental conditions.

Versatile and Easy Panel Mounting

Designed for quick and straightforward installation, the LP12 7Pin Female Socket features a panel mount configuration with a 12mm mounting diameter. Its solder terminals accommodate cable diameters from 4.5mm to 7mm, supporting a range of wiring requirements. This versatility is ideal for distributors, OEMs, or system integrators seeking a dependable solution for numerous power connection needs.

FAQ's of LP12 100V 3A 7Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal:

Q: How do I install the LP12 100V 3A 7Pin Female Socket in my equipment?

A: The LP12 socket is designed for panel mounting. Simply insert the 12mm diameter socket into the cutout on your panel, secure with the included nut, and solder your wires to the 7-pin terminals. The rubber gasket ensures a firm, waterproof seal, making it suitable for outdoor or industrial enclosures.

Q: What benefits does the IP67 waterproof rating provide for this connector?

A: An IP67 waterproof rating ensures the connector is completely protected from dust ingress and can withstand immersion in water up to 1 meter deep for 30 minutes. This level of protection makes it ideal for outdoor and industrial power applications where exposure to moisture or harsh environments is expected.

Q: When should I use the LP12 connector for my application?

A: Choose the LP12 connector whenever you need a reliable, sealed power and signal transmission solution for LED lighting, power systems, or industrial equipment-especially in settings exposed to vibration, dust, or moisture. Its robust construction and safety certifications make it suitable for critical or harsh environments.

Q: What is the process for wiring and maintaining this 7Pin female socket?

A: Wiring requires soldering cables ranging from 4.5mm to 7mm diameter onto the appropriate pins, following the required pinout for power and signal distribution. Maintenance is minimal due to the robust construction, but it is recommended to periodically inspect the seal and contact resistance for optimal performance.

Q: Where can I source the LP12 7Pin Female Socket in India?

A: The LP12 connector is available through various distributors, exporters, importers, manufacturers, traders, and wholesalers throughout India. Bulk and OEM purchasing options make it accessible for businesses across multiple sectors.

Q: What safety standards and compliance does this connector adhere to?

A: This product is flame-retardant to UL94-V0 standards, vibration resistant as per IEC 60512-6-4, and RoHS compliant. These certifications ensure it meets international safety, environmental, and operational reliability requirements.

Q: How does the LP12 ensure reliable power delivery in demanding environments?

A: With contact materials crafted from tin-plated brass, over 500 mating cycles durability, high insulation resistance (>2000M at 500V DC), and a secure locking mechanism, the LP12 connector offers consistent, safe power and signal transmission even under vibration and harsh environmental conditions.
