LP16 400V 10A 4Pin Female Inline IP67 Waterproof Power Connector Plastic Shell Solder Terminal

359.0 INR/Piece

Get a Price/Quote

Product Details:

IP Rating IP67
Usage Industrial Power Application
Input 4 Pin Female Inline
Features Waterproof, Dustproof, Corrosion Resistant, Impact Resistant
Power Supply AC/DC
Operating Temperature -40C to +85C
Components Connector Shell, Pins, Solder Terminal, Sealing Rings
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP16 400V 10A 4Pin Female Inline IP67 Waterproof Power Connector Plastic Shell Solder Terminal Price And Quantity

Price 359.0 INR/Piece
Minimum Order Quantity 100 Piece

Connection Type Inline Solder
Sealing Method Compression Sealing Rings
Flame Retardant Grade UL94 V-0
Pin Configuration 4 Pin Female
Environmental Resistance UV Resistant, Weatherproof
Mechanical Life 500 Mating Cycles
Shell Material Plastic (High Quality Thermoplastic)
Standards Compliance IEC, RoHS
Contact Material Copper Alloy with Tin Plated
Mounting Type Cable Inline
Wire Range 2.5mm2

LP16 400V 10A 4Pin Female Inline IP67 Waterproof Power Connector Plastic Shell Solder Terminal Product Specifications

Product Type Waterproof Power Connector
IP Rating IP67
Input 4 Pin Female Inline
Supply Voltage 400V
Usage Industrial Power Application
Size 16mm Diameter
Components Connector Shell, Pins, Solder Terminal, Sealing Rings
Function Power Connection and Distribution
Thickness Standard Shell Thickness
Power Source Cable Connected
Features Waterproof, Dustproof, Corrosion Resistant, Impact Resistant
Current Rating 10A
Dimension (L*W*H) Approx. 70mm x 23mm x 23mm
Weight Approx 30g
Power Supply AC/DC
Application Outdoor and Indoor Power Transmission
Capacity 10A Max
Interface Solder Terminal
Color Black
Operating Temperature -40C to +85C
Output 4 Pin Female Inline
Frequency 50/60Hz
Rated Voltage 400V

Connection Type Inline Solder
Sealing Method Compression Sealing Rings
Flame Retardant Grade UL94 V-0
Pin Configuration 4 Pin Female
Environmental Resistance UV Resistant, Weatherproof
Mechanical Life 500 Mating Cycles
Shell Material Plastic (High Quality Thermoplastic)
Standards Compliance IEC, RoHS
Contact Material Copper Alloy with Tin Plated
Mounting Type Cable Inline
Wire Range 2.5mm2

LP16 400V 10A 4Pin Female Inline IP67 Waterproof Power Connector Plastic Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Plug/Socket:Female Connector/Dock
Temperature rise:10A 30C ,12A 40C ,15A 50C
Contact resistance:< 2.5mOhm
Contact dimension:1.5*4 mm
Insertion and extraction force:2.4N Max
Mating cycle:1700 times
Vibration:Frequency:5200Hz, Amplitude:5mm, Speed :10m/s, No instantaneous short circuit in 0.10us
Temperature and humidity:-4080C, 40C,85%RH.
Salt spray:PH6.5-7.2,NaCl,5% 48H

Superior Protection for Industrial Environments

With an IP67 waterproof rating and corrosion-resistant thermoplastic shell, this connector offers outstanding defense against moisture, dust, and UV rays. The UL94 V-0 flame retardant rating and robust sealing technology ensure safe operation in demanding settings, making it perfect for both outdoor and indoor usage.

Reliable and Safe Power Transmission

Designed for a maximum voltage of 400V and a current rating of 10A, the LP16 connector facilitates stable power distribution. The solder terminal connection type and copper alloy (tin-plated) contacts provide low resistance and reduce the risk of power loss, essential for critical industrial applications.

Flexible and Simple Installation

Its inline solder terminal configuration, compression sealing rings, and standard 16mm diameter allow for simple assembly and integration into existing systems. Supporting cable wire sizes up to 2.5mm2, installation and maintenance are quick and straightforward, making it convenient for various professionals in India.

FAQ's of LP16 400V 10A 4Pin Female Inline IP67 Waterproof Power Connector Plastic Shell Solder Terminal:

Q: How is the LP16 400V 10A 4Pin connector installed?

A: Installation involves soldering the power wires to the internal terminals, then securing the assembly with compression sealing rings. This provides a secure, moisture-resistant connection suitable for both indoor and outdoor applications.

Q: What benefits does the IP67 waterproof rating provide?

A: An IP67 rating ensures the connector is completely protected against dust ingress and can withstand immersion in water up to 1 meter deep, making it ideal for environments exposed to rain, humidity, or temporary flooding.

Q: When should I use this connector in power applications?

A: This connector is recommended for situations requiring secure, weather-resistant power distribution, such as outdoor industrial equipment, renewable energy setups, or anywhere robust protection from the elements is necessary.

Q: Where can the LP16 connector be utilized effectively?

A: Because of its flame retardant, UV resistant, and weatherproof features, the LP16 connector performs reliably in manufacturing plants, construction sites, and both outdoor and indoor power transmission installations.

Q: What is the process for maintaining the connector over time?

A: Routine inspection is advised to check the integrity of the sealing rings and solder joints. The connector's design allows for up to 500 mating cycles, which supports periodic disconnect and reconnect operations without significant wear.

Q: What are the main advantages of using a copper alloy with tin-plated contacts?

A: Copper alloy with tin plating ensures excellent conductivity, corrosion resistance, and longevity. This combination minimizes energy loss and enhances long-term electrical performance, crucial for industrial environments.
