M12 male to Female Adaptor

Name: M12 male to Female Adaptor
Brand: CONNECTOR DEVICES
Price: 1300 INR
Availability: InStock

1300 INR/Piece

Get a Price/Quote

Product Details:

Male End Type M12 4-pin male
Connector M12 male to female
Application Sensor/actuator connectivity, industrial automation
Temperature -25C to +85C
Pairs Single-pair connection
Material Other
Connector Type Right angle, circular
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

M12 male to Female Adaptor Price And Quantity

Minimum Order Quantity 100 Piece
Price 1300 INR/Piece

M12 male to Female Adaptor Product Specifications

Material Other
Wire Gauge 24 AWG (standard for signal)
Insulation Polyamide (PA)
Length Adaptor only, no cable length
Jacket Material N/A - Adaptor housing
Flame Resistance Level UL 94 V-0
Connector Type Right angle, circular
Cable Type Adaptable to shielded cables
Outer Diameter Approx. 16 mm
Connector M12 male to female
Number of Conductor 4 (typical for M12 connectors)
Voltage Rating 250 V AC/DC
Male End Type M12 4-pin male
Capacity Up to 4 A
Sheild Yes, overall braid shield
Cable Length N/A - no cable
Pairs Single-pair connection
Color Black housing
Application Sensor/actuator connectivity, industrial automation
Female End Type M12 4-pin female
Temperature -25C to +85C

Torque 0.6 Nm max
Mounting Type Inline, panel mount adaptable
Locking System Threaded coupling
Ingress Protection IP67 rated
Contact Plating Gold over nickel
Coupling Nut Brass, nickel-plated
Standards IEC 61076-2-101
Insulation Resistance >100 M at 500 V DC
Contact Resistance 5 m

Product Description

Purchase the top-ranking M12 Male to Female Adaptor, designed to capitalise on versatile sensor and actuator connectivity in industrial automation. This right-angle, circular adaptor boasts a superior ingress protection rating of IP67, ensuring resilience in harsh environments. Gold-over-nickel contacts deliver ultra-low contact resistance (5 m), while the robust overall braid shield enhances signal integrity. Find ultimate safety with flame-retardant polyamide housing (UL 94 V-0) and a reliable threaded coupling system. Adaptable for inline or panel mounting, this adaptor supports up to 4 conductors at 250 V and 4 A, meeting IEC 61076-2-101 standards for confidence and consistency.

Advanced Features & Adaptability

The M12 Male to Female Adaptor offers extra features, making it ideal for both specific and general industrial applications. Its flame-retardant polyamide housing, gold-plated contacts, and overall braid shielding ensure maximum durability and signal reliability. This adaptor can be used for sensor or actuator connectivity, especially in industrial automation environments requiring an IP67 rating. The inline and panel mount adaptability further enhances installation flexibility, making this a superior connector solution for machinery and factory systems.

Reliable Supply & Expert Export Services

Order processing is smooth, with reliable rate of supply and secure packaging tailored to prevent product damage. Each adaptor is shipped promptly after confirmation to maintain high customer satisfaction. As a leading distributor, exporter, importer, manufacturer, trader, and wholesaler in India, we offer this product to export markets in Asia, Europe, and the Middle East. Our efficient logistics and meticulous handling guarantee that your M12 adaptors arrive in pristine condition, ready for immediate use.

FAQ's of M12 male to Female Adaptor:

Q: How is the M12 Male to Female Adaptor superior for industrial automation applications?

A: Its IP67 ingress protection, low contact resistance, and gold-over-nickel plated contacts ensure reliable, top-ranking performance in demanding sensor and actuator connectivity.

Q: What are the main material and safety features of this adaptor?

A: The adaptor features a flame-retardant polyamide housing (UL 94 V-0), brass nickel-plated pins, and overall braid shielding for extra signal protection and durability.

Q: Where can this adaptor be used?

A: It is most commonly used in sensor/actuator connectivity within industrial automation systems, and is adaptable for inline or panel mount configurations.

Q: What is the process for order processing and shipping?

A: Orders are processed promptly, with each adaptor securely packaged and shipped quickly to minimize downtime and maintain a reliable supply rate.

Q: How does this product comply with international standards?

A: The M12 adaptor meets IEC 61076-2-101 and provides consistent performance, which makes it suitable for global industrial applications.

Q: What benefits does the braid shield offer?

A: The overall braid shield protects against electromagnetic interference, enhancing the adaptor's performance and ensuring clear, uninterrupted signal transmission.
