Servo Motor 4 Pin Male Socket YD28J4Z-E

Get a Price/Quote

Product Details:

Input 4-pin male socket interface
Power Supply External (as per servo motor system)
Operating Temperature -40C to +85C
Features Waterproof, vibration-resistant, robust construction, secure locking
IP Rating IP67
Interface Circular push-pull type male socket
Usage Servo motor connectivity
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Servo Motor 4 Pin Male Socket YD28J4Z-E Price And Quantity

Minimum Order Quantity 100 Piece

Servo Motor 4 Pin Male Socket YD28J4Z-E Product Specifications

Color Black and Silver
Application Automation, robotics, CNC machines, industrial equipment
Usage Servo motor connectivity
Supply Voltage Up to 250V AC/DC
Interface Circular push-pull type male socket
IP Rating IP67
Input 4-pin male socket interface
Size 28 series
Weight Approx. 20g
Product Type Servo Motor Connector
Power Supply External (as per servo motor system)
Rated Voltage 250V AC/DC
Dimension (L*W*H) Approx. 40mm length, 28mm diameter
Function Electrical connection for servo motor control signals and power
Capacity 4 contacts
Components Body shell, 4-pin insert, locking nut
Current Rating 5A per contact
Output Connection to servo drive or controller
Features Waterproof, vibration-resistant, robust construction, secure locking
Operating Temperature -40C to +85C

Wire Gauge Compatibility AWG 18-22
Insulation Resistance >1000M at 500V DC
Locking Mechanism Push-pull self-locking system
Mounting Type Panel or cable mount
Shell Material Zinc alloy with nickel plating
Mating Cycle Durability Over 500 cycles
Contact Resistance 5m
Number of Pins 4 (male configuration)
Sealing Method Rubber O-ring and grommet
Protection Against Dust/Water Completely dust tight and protected against prolonged immersion
Contact Material Copper alloy with gold-plated contacts
Standards Compliance CE, RoHS compliant
Connector Series YD28

Product Description

Commanding performance meets elite design in the Servo Motor 4 Pin Male Socket YD28J4Z-E. This potent connector, crafted from a zinc alloy shell with nickel plating and embedded with gold-plated copper alloy contacts, ensures a gorgeous combination of durability and reliability. Designed for both panel and cable mounting, its push-pull self-locking mechanism guarantees a secure and waterproof connection. Fully dust tight and IP67 rated, it withstands vibration and extreme environments. Try now to experience uncompromised servo motor connectivity-trusted by professionals across robotics, automation, and CNC systems.

Robust Connectivity for Industrial Applications

The YD28J4Z-E 4 Pin Male Socket excels in plant applications such as automation, robotics, and CNC machinery, delivering high reliability in controlling servo motors. Its advanced sealing with a rubber O-ring and self-locking design provides solid protection against dust, water, and vibration. This connector's elite construction ensures optimal performance for signal and power transfer across heavy-duty machines, guaranteeing smooth operation where commanding connectivity is essential.

Domestic Market Reach and Export Capabilities

Dominant in the domestic mar as a distributor, importer, and manufacturer in India, the Servo Motor 4 Pin Male Socket YD28J4Z-E caters to high-volume needs with outstanding supply ability and competitive rate structures. Exports extend globally, meeting demands of automation and industrial equipment. Flexible payment terms and strong supply chain reliability make it a preferred choice for wholesalers, traders, and OEMs seeking robust electrical connectors for local and international markets.

FAQ's of Servo Motor 4 Pin Male Socket YD28J4Z-E:

Q: How do I install the Servo Motor 4 Pin Male Socket YD28J4Z-E?

A: Installation is straightforward. The socket can be panel or cable mounted using its push-pull self-locking mechanism. Ensure proper alignment of the 4 pins and secure with the locking nut for reliable and waterproof connectivity.

Q: What are the main applications for this servo motor connector?

A: It is suitable for automation, robotics, CNC machines, and other industrial equipment requiring potent, dust-resistant, and waterproof electrical connections for servo motor signals and power supply.

Q: When should I choose the YD28J4Z-E over other connectors?

A: Opt for the YD28J4Z-E when your project demands elite performance, high durability, IP67 protection, and reliable connectivity in demanding or vibration-prone environments.

Q: Where is the YD28J4Z-E socket typically used?

A: The connector is commonly employed in industrial plants, automation systems, and robotics setups across both domestic and export markets, thanks to its robust construction and compliance with CE and RoHS standards.

Q: What benefits does the gold-plated contact material offer?

A: Gold-plated copper alloy contacts provide superior conductivity, corrosion resistance, and maintain low contact resistance, ensuring potent and long-lasting connections for servo motor control and power.
