YM24 35A 2Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal

Name: YM24 35A 2Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 587.0 INR
Availability: InStock

587.0 INR/Piece

Get a Price/Quote

Product Details:

Power Supply Wire Connection
Components Male Plug with Plastic Shell
Operating Temperature -40C to +80C
Usage Electric Power Transmission, Outdoor/Industrial Applications
Features Waterproof, Dustproof, Corrosion Resistant, High Current Capacity, Easy Installation
Interface Solder Terminal
Input 2 Pin Male Plug
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YM24 35A 2Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 587.0 INR/Piece

Seal Type Rubber Sealing Ring
Locking System Threaded Coupling Nut
Protection Level IP67 Rated, Outdoor Environment Ready
Mating Cycle Durability >2000 Mating Cycles
Number of Pins 2 Pins
Mounting Type Cable/Panel Mount
Flammability Rating UL94-V0
Connector Gender Male
Mechanical Life Long Life - Durable Construction
Shell Material High Strength Plastic
Contact Material Copper Alloy, Silver Plated
Cable Diameter Range 10-14mm

YM24 35A 2Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal Product Specifications

Frequency 50/60Hz
Power Source Wired Power
Color Black
Capacity 35A Rated Current
IP Rating IP67
Product Type Waterproof Power Connector
Input 2 Pin Male Plug
Weight 110g
Thickness Standard Shell Thickness
Function Power Connector
Output Solder Terminal
Dimension (L*W*H) Approx. 97mm (Length) x 36mm (Diameter)
Features Waterproof, Dustproof, Corrosion Resistant, High Current Capacity, Easy Installation
Usage Electric Power Transmission, Outdoor/Industrial Applications
Supply Voltage Up to 500V
Current Rating 35A
Interface Solder Terminal
Rated Voltage 500V AC/DC
Size YM24 Shell
Application LED Lighting, Machinery, Industrial Equipment, Automation, Outdoor Power
Components Male Plug with Plastic Shell
Operating Temperature -40C to +80C
Power Supply Wire Connection

Seal Type Rubber Sealing Ring
Locking System Threaded Coupling Nut
Protection Level IP67 Rated, Outdoor Environment Ready
Mating Cycle Durability >2000 Mating Cycles
Number of Pins 2 Pins
Mounting Type Cable/Panel Mount
Flammability Rating UL94-V0
Connector Gender Male
Mechanical Life Long Life - Durable Construction
Shell Material High Strength Plastic
Contact Material Copper Alloy, Silver Plated
Cable Diameter Range 10-14mm

YM24 35A 2Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting mode:latching lock
Contact diameter:phi 3.0x3
Operating voltage(AC.V.rms):500V
Withstand voltage(AC.V)1min:2500V
Contact resistance:< 2.5mohm
Temperature and humidity:-4080C, 40C, 85%RH
Mating cycle:1700 times

Superior Waterproof Performance

Designed to withstand challenging environments, the YM24 connector boasts an IP67 rating, making it completely waterproof and dustproof. The rubber sealing ring and robust threaded locking system ensure reliability in outdoor and industrial settings, whether in rain, dust, or high-moisture conditions. This connector offers the durability and protection necessary for mission-critical power transmission.

High Current and Voltage Capability

With a rated capacity of 35A and supporting voltages up to 500V AC/DC, this 2-pin male plug is ideal for applications requiring stable, high-current power delivery. Its silver-plated copper alloy terminals guarantee low resistance, optimal conductivity, and consistent power for LED lighting systems, heavy-duty machinery, and other high-demand equipment.

Flexible and Easy Installation

The YM24 is engineered for convenience, with a standard shell size suited for 10-14mm cable diameters and both cable and panel mounting options. Its solder terminal interface simplifies wiring, while the threaded coupling nut provides effortless yet secure connectivity. This user-oriented design streamlines installation and maintenance in various industrial and outdoor scenarios.

FAQ's of YM24 35A 2Pin Male Plug IP67 Waterproof Power Connector Plastic Shell Solder Terminal:

Q: How do I install the YM24 35A 2Pin Male Plug power connector?

A: Installation is straightforward: Prepare your cable (diameter 10-14mm), solder the wires onto the terminals, insert the cable into the shell, and secure by tightening the threaded coupling nut. It supports both cable and panel mounting for flexible integration.

Q: What environments or applications is this connector suited for?

A: The YM24 connector is ideal for outdoor and industrial environments thanks to its IP67 waterproof and dustproof rating. It is commonly used in LED lighting, industrial equipment, automation, and outdoor power transmission, especially in harsh weather or high-moisture areas.

Q: When should I use a connector with an IP67 rating?

A: An IP67-rated connector, like the YM24, should be used whenever you require protection against water immersion and dust ingress. It is especially critical for outdoor installations or industrial machinery exposed to challenging environmental conditions.

Q: Where can this connector be mounted?

A: This connector offers flexible mounting options: it can be installed on cables directly or mounted on panels, making it suitable for a wide range of power transmission setups in industrial or outdoor environments.

Q: What are the benefits of the rugged plastic shell and silver-plated contacts?

A: The high-strength plastic shell provides excellent mechanical protection against impacts and harsh conditions, while the silver-plated copper alloy contacts deliver reliable, high-conductivity connections and resist corrosion for a long lifespan.

Q: How does the threaded locking system improve connection reliability?

A: The threaded coupling nut ensures a secure mechanical and electrical connection, preventing accidental disconnects and providing stable performance even in environments subject to vibrations or movement.

Q: What is the process for maintaining or replacing the connector?

A: Maintenance typically involves inspecting the sealing ring and connection points for debris or wear. Since it supports over 2,000 mating cycles, connectors can be disconnected and reconnected as needed. If replacement is necessary, simply unscrew the coupling nut, desolder the terminals, and swap in the new unit.
