YT RJ45 Cat5e Female Socket PCB Dual Port IP67 Waterproof Ethernet Connector

Name: YT RJ45 Cat5e Female Socket PCB Dual Port IP67 Waterproof Ethernet Connector
Brand: CONNECTOR DEVICES
Price: 376.0 INR
Availability: InStock

376.0 INR/Piece

Get a Price/Quote

Product Details:

Operating Temperature -40C to +85C
Interface RJ45 female (dual port), PCB mount
Features Dual port, waterproof, dustproof, corrosion-resistant, easy PCB mount, industrial design
Usage Ethernet/network interface for industrial environments
IP Rating IP67
Output RJ45 Ethernet (Cat5e)
Components PCB socket, sealing gasket, housing
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YT RJ45 Cat5e Female Socket PCB Dual Port IP67 Waterproof Ethernet Connector Price And Quantity

Price 376.0 INR/Piece
Minimum Order Quantity 100 Piece

Mounting Style Panel mount with sealing gasket
Connector Type RJ45 8P8C Female
Withdrawal Force 8N
Data Rate Support 10/100/1000 Mbps (Gigabit Ethernet)
Compliance RoHS compliant, UL certified
Housing Material High strength thermoplastic, waterproof metal sleeve
Wire Compatibility Cat5e Ethernet cables (24-26 AWG)
Panel Thickness Support Up to 3mm
Insertion Force 50N
Number of Ports 2
Sealing Type With gasket, IP67 rated waterproof and dustproof
Shielding Full metal shielded housing
Waterproof Depth Up to 1 meter for 30 minutes (IP67)
Flame Class UL94 V-0
Contact Plating Gold plated contacts
Mating Cycles 750

YT RJ45 Cat5e Female Socket PCB Dual Port IP67 Waterproof Ethernet Connector Product Specifications

Function PCB mount ethernet connectivity, signal transfer, dual port networking
Dimension (L*W*H) Approx. 46mm x 35mm x 26mm
Operating Temperature -40C to +85C
IP Rating IP67
Weight Approx. 28g
Capacity Supports dual Ethernet channels
Frequency Suitable up to 100MHz (Cat5e)
Output RJ45 Ethernet (Cat5e)
Rated Voltage 125V AC
Components PCB socket, sealing gasket, housing
Size Standard panel mount size
Application Industrial automation, outdoor networking, waterproof ethernet connections, equipment interface
Interface RJ45 female (dual port), PCB mount
Current Rating 1.5A max/contact
Features Dual port, waterproof, dustproof, corrosion-resistant, easy PCB mount, industrial design
Product Type RJ45 Dual Port Ethernet Socket
Thickness Standard Connector Thickness
Color Black, Silver
Input RJ45 Ethernet (Cat5e)
Usage Ethernet/network interface for industrial environments

Mounting Style Panel mount with sealing gasket
Connector Type RJ45 8P8C Female
Withdrawal Force 8N
Data Rate Support 10/100/1000 Mbps (Gigabit Ethernet)
Compliance RoHS compliant, UL certified
Housing Material High strength thermoplastic, waterproof metal sleeve
Wire Compatibility Cat5e Ethernet cables (24-26 AWG)
Panel Thickness Support Up to 3mm
Insertion Force 50N
Number of Ports 2
Sealing Type With gasket, IP67 rated waterproof and dustproof
Shielding Full metal shielded housing
Waterproof Depth Up to 1 meter for 30 minutes (IP67)
Flame Class UL94 V-0
Contact Plating Gold plated contacts
Mating Cycles 750

YT RJ45 Cat5e Female Socket PCB Dual Port IP67 Waterproof Ethernet Connector Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Diameter range:5.57mm
Contact resistance:< 30mohm
Durability:> 500 cycles
Insulation Resistance:> 500Mohm
Contact diameterxnumber:8
Operating voltage (AC):500V
Working Temperature:-4080C

Dual Port Reliability for Industrial Networking

Supporting two independent Ethernet channels, this connector is ideal for complex networking in industrial automation, outdoor communication stations, and harsh environments. The dual ports allow flexible design options, while full metal shielding prevents electromagnetic interference and ensures stable 10/100/1000 Mbps data transfer.

IP67 Waterproof and Dustproof Protection

Designed with a sealed waterproof metal sleeve and gasket, this RJ45 socket maintains strong connectivity even when exposed to moisture, dust, or outdoor elements. Its IP67 rating means it can withstand immersion in water up to 1 meter deep for 30 minutes, ensuring uninterrupted performance in the toughest conditions.

Built for Longevity and Safety

Constructed with high-strength thermoplastic and corrosion-resistant metal, this socket endures up to 750 mating cycles and is flame rated UL94 V-0 for enhanced safety. Compliance with RoHS and UL standards makes it suitable for critical industrial and commercial installations.

FAQ's of YT RJ45 Cat5e Female Socket PCB Dual Port IP67 Waterproof Ethernet Connector:

Q: How does the IP67 rating benefit industrial and outdoor Ethernet applications?

A: The IP67 rating ensures that the connector is both waterproof and dustproof-capable of withstanding water immersion up to 1 meter for 30 minutes. This level of protection allows secure Ethernet connections in environments exposed to moisture, dirt, or weather, such as factories or outdoor networking installations.

Q: What is the recommended process for panel mounting this RJ45 dual port socket?

A: To mount, insert the connector into a pre-cut panel hole up to 3mm thick. Use the included sealing gasket to achieve a watertight fit, then secure with the provided slotted nut or screws. This ensures both mechanical stability and environmental sealing for industrial use.

Q: Where can this Ethernet connector be used effectively?

A: Ideal for industrial automation systems, outdoor electronic equipment, waterproof networking solutions, and equipment interfaces requiring dual Ethernet connections, this connector is suited for environments needing reliable and ruggedized PCB-mount network sockets.

Q: What cables and data speeds are supported by this dual port socket?

A: This connector is compatible with Cat5e Ethernet cables (24-26 AWG) and supports 10/100/1000 Mbps data rates, suitable for Gigabit Ethernet. It operates effectively within 100MHz frequency, making it ideal for high-speed data transmission.

Q: How is the socket maintained over its lifespan and what is its mating cycle rating?

A: With gold-plated contacts and corrosion-resistant housing, minimal maintenance is needed beyond simple periodic inspection. The socket supports up to 750 mating cycles, ensuring long-term durability and reliable connectivity in industrial settings.

Q: What are the main benefits of the full metal shielded housing and gold-plated contacts?

A: Full metal shielding protects against EMI/RFI, preserving data integrity in electrically noisy environments, while gold-plated contacts enhance corrosion resistance and provide consistent, dependable electrical conductivity.
