YU Series USB2.0 Female-Male IP67 Waterproof Data Connector

599 INR/Piece

Get a Price/Quote

Product Details:

Input USB 2.0 Male
Operating Temperature -20C to +80C
Interface USB 2.0 Female-Male
Features Waterproof, Dustproof, Panel Mount, Easy Installation, Durable Housing
Charging Voltage 5V
Components USB Female, USB Male, IP67 Sealing Gasket, Lock Nut
Usage Outdoor and Harsh Environment Data Applications
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YU Series USB2.0 Female-Male IP67 Waterproof Data Connector Price And Quantity

Minimum Order Quantity 100 Piece
Price 599 INR/Piece

Cable Length Customizable or as specified
USB Standard Complies with USB 2.0 (480 Mbps)
Protection Full Sealing - Water & Particle Ingress Protection
Flame Rating UL94 V-0
Material High-strength Nylon, Gold-plated Contacts
Mounting Type Panel Mount with Threaded Nut
Sealing Material Silicone Rubber Gasket
Insulation Resistance 1000M at 500V DC
Contact Resistance 30m
Connector Life Cycle Over 1500 Mating Cycles

YU Series USB2.0 Female-Male IP67 Waterproof Data Connector Product Specifications

Product Type USB 2.0 Waterproof Data Connector
Size Standard USB with Panel Mounting
Rated Voltage DC 5V
Color Black
Components USB Female, USB Male, IP67 Sealing Gasket, Lock Nut
Weight Approx. 32 grams
Power Source USB
Capacity 1 Port
Power Supply USB Powered
Dimension (L*W*H) 62mm x 22mm x 18mm (including panel nut)
Thickness Refer Dimension
Operating Temperature -20C to +80C
Application Industrial Equipment, Outdoor Panels, Marine, Automotive, Automation Systems
Input USB 2.0 Male
Interface USB 2.0 Female-Male
Usage Outdoor and Harsh Environment Data Applications
Frequency DC Only
Current Rating 1.5A Max
Function USB 2.0 Data Transmission and Waterproof Connectivity
Supply Voltage 5V
IP Rating IP67
Charging Voltage 5V
Output USB 2.0 Female
Features Waterproof, Dustproof, Panel Mount, Easy Installation, Durable Housing

Cable Length Customizable or as specified
USB Standard Complies with USB 2.0 (480 Mbps)
Protection Full Sealing - Water & Particle Ingress Protection
Flame Rating UL94 V-0
Material High-strength Nylon, Gold-plated Contacts
Mounting Type Panel Mount with Threaded Nut
Sealing Material Silicone Rubber Gasket
Insulation Resistance 1000M at 500V DC
Contact Resistance 30m
Connector Life Cycle Over 1500 Mating Cycles

YU Series USB2.0 Female-Male IP67 Waterproof Data Connector Trade Information

Delivery Time 7 Days

Product Description

Discover the latest innovation in data connectivity with the YU Series USB2.0 Female-Male IP67 Waterproof Data Connector-now available at a phenomenal promotion! This in-demand connector boasts a first-rate high-strength nylon body, glorious gold-plated contacts, and an unmatchable sealing system for supreme durability. Engineered to excel in outdoor and industrial environments, it supports unbroken USB 2.0 data transmission at 480 Mbps. Its full IP67 protection secures connectivity against water and dust, making it ideal for marine, automotive, and automation applications. Elevate your setup with this top-tier, reliable connector-trusted by distributors, exporters, and installers across India.

Robust Performance and Unrivaled Durability

The YU Series USB2.0 Female-Male IP67 Data Connector is specially designed for outdoor and harsh industrial applications. With panel-mount installation, fully sealed protection, and a rugged nylon build, it delivers unmatchable performance even in challenging settings. This connector's primary advantages include waterproof and dustproof construction, gold-plated contacts for reliable connections, and over 1500 mating cycles for extended life. It's your go-to choice for marine, automotive, and automation systems where dependability is crucial.

Flexible Payment & Global Export - Confidence Assured

Benefit from flexible payment terms tailored to your preference when you charge your order with us. We offer quick dispatch and on-time delivery for global customers. The YU Series connector is exported across key markets including Asia, Middle East, and Africa, with recognized certifications for safety and quality. Trust in speedy fulfillment and certified excellence, ensuring your operations remain seamless wherever you are in the world.

FAQ's of YU Series USB2.0 Female-Male IP67 Waterproof Data Connector:

Q: How does the YU Series USB2.0 connector ensure protection against water and dust?

A: This connector is engineered with an IP67-rated silicone rubber gasket and high-strength nylon housing, providing full sealing and comprehensive protection against both water and particle ingress.

Q: What applications is this data connector best suited for?

A: It is ideal for industrial equipment, outdoor panels, marine installations, automotive systems, and automation environments where robust, waterproof USB connectivity is essential.

Q: What certifications and safety standards does it comply with?

A: The connector features flame-retardant UL94 V-0 materials and is certified to ensure electrical, mechanical, and environmental safety, making it reliable for critical applications.

Q: Where can I use this connector for seamless data transmission?

A: You can deploy it in any harsh or outdoor environment requiring secure and stable USB 2.0 data connections, such as industrial or marine installations or automotive panels.

Q: What are the benefits of using gold-plated contacts in the YU Series connector?

A: Gold-plated contacts ensure optimal conductivity and resistance to corrosion, leading to reliable data transfer and enhanced longevity, even in challenging environments.
