YZ20 500V 20A 12Pin Male Plug IP67 Metal Shell Waterproof Power Connector Solder

1050 INR/Piece

Get a Price/Quote

Product Details:

Interface 12-pin solder type male plug
IP Rating IP67
Power Source Wired, external supply
Usage Industrial machinery, outdoor equipment, temporary power distribution
Operating Temperature -40C to +80C
Power Supply AC/DC
Output Up to 500V, 20A
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YZ20 500V 20A 12Pin Male Plug IP67 Metal Shell Waterproof Power Connector Solder Price And Quantity

Price 1050 INR/Piece
Minimum Order Quantity 100 Piece

Mounting Type Inline plug
Mechanical Life >500 mating cycles
Mating Style Threaded coupling
Connection Type Male plug
Cable Diameter Range 6mm - 12mm
Wire Termination Solder type
Contact Material Copper alloy with silver plating
Number of Pins 12
Corrosion Resistance Excellent due to nickel-plated shell
Flame Retardancy V0 rated materials
Shell Material Zinc alloy with nickel plating
Environmental Protection Complies with RoHS

YZ20 500V 20A 12Pin Male Plug IP67 Metal Shell Waterproof Power Connector Solder Product Specifications

Frequency 50/60Hz
Power Source Wired, external supply
Product Type Male Power Connector Plug
IP Rating IP67
Current Rating 20A
Application Waterproof power connection, outdoor and industrial applications
Color Silver (metal shell)
Function Power connection and transmission in harsh or outdoor environments
Interface 12-pin solder type male plug
Rated Voltage 500V
Supply Voltage 500V max
Output Up to 500V, 20A
Operating Temperature -40C to +80C
Size 20mm (shell diameter)
Dimension (L*W*H) Approx. 110mm x 38mm x 38mm
Power Supply AC/DC
Usage Industrial machinery, outdoor equipment, temporary power distribution
Capacity 20A current handling
Input Up to 500V, 20A
Features Waterproof, dustproof, rugged metal shell, screw coupling
Weight Approx. 260g
Components Metal shell, 12-pin insert, solder contacts

Mounting Type Inline plug
Mechanical Life >500 mating cycles
Mating Style Threaded coupling
Connection Type Male plug
Cable Diameter Range 6mm - 12mm
Wire Termination Solder type
Contact Material Copper alloy with silver plating
Number of Pins 12
Corrosion Resistance Excellent due to nickel-plated shell
Flame Retardancy V0 rated materials
Shell Material Zinc alloy with nickel plating
Environmental Protection Complies with RoHS

YZ20 500V 20A 12Pin Male Plug IP67 Metal Shell Waterproof Power Connector Solder Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Rated Current:20A
Operating Voltage:500V
Withstanding voltage:2500V
Number of Pins:3
Contact resistance:< 1mohm
Contact dimension:Phi 2.7*3
Mating cycle:> 1700 Times
Insertion and extraction force:6N Max

Engineered for Durability and Safety

Constructed with a zinc alloy shell and nickel plating, the YZ20 connector excels in both mechanical strength and corrosion resistance. Its IP67 rating protects against water and dust ingress, while V0-rated flame retardant materials ensure heightened safety even in hazardous conditions.

Flexible Power Transmission for Demanding Environments

Supporting currents up to 20A and voltages up to 500V AC/DC, this 12-pin male plug is designed for industrial machinery, outdoor equipment, and temporary power distribution. The screw coupling mechanism and wide cable compatibility make installation both secure and versatile.

FAQ's of YZ20 500V 20A 12Pin Male Plug IP67 Metal Shell Waterproof Power Connector Solder:

Q: How is the YZ20 male plug installed and terminated?

A: The YZ20 male plug uses a solder type wire termination. Simply strip the insulation from your wires, solder them to the respective contact pins, and assemble the connector, ensuring a secure and reliable electrical connection.

Q: What environments is the YZ20 500V 20A plug best suited for?

A: This connector is designed for harsh and outdoor environments, including industrial machinery, outdoor equipment, and temporary power distribution. Its IP67 rating provides waterproof and dustproof performance, making it ideal for rugged conditions.

Q: What benefit does the threaded coupling provide during use?

A: The threaded (screw) coupling ensures a tight, vibration-resistant connection between the male and female components, minimizing the risk of accidental disconnection and promoting long-term reliability-even under frequent mating and unmating.

Q: When should I use this 12-pin connector instead of a standard plug?

A: Use the YZ20 connector when you require a high-capacity, waterproof solution capable of handling up to 500V and 20A over multiple circuits in one secure assembly, especially in environments exposed to water, dust, or physical stress.

Q: Where can the YZ20 connector be applied for optimal benefit?

A: It excels in power connections for industrial automation, outdoor lighting, construction sites, renewable energy setups, and equipment that demands both water protection and high electrical capacity.

Q: What materials are used in the YZ20 plug, and how do they improve performance?

A: The shell is made from nickel-plated zinc alloy, providing mechanical durability and excellent corrosion resistance. Contacts are crafted from copper alloy with silver plating, ensuring optimal electrical conductivity and minimized contact resistance.
