DH24 400V 10A 10Pin Male Plug IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal

Name: DH24 400V 10A 10Pin Male Plug IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal
Brand: CONNECTOR DEVICES
Price: 1045.0 INR
Availability: InStock

1045.0 INR/Piece

Get a Price/Quote

Product Details:

Output Multi-pin electrical
IP Rating IP67
Components Metal shell, solder terminals, sealing gasket
Power Supply Electrical
Power Source External electrical supply
Operating Temperature -40C to +85C
Input Multi-pin electrical
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

DH24 400V 10A 10Pin Male Plug IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 1045.0 INR/Piece

Salt Spray Test >48 hours
Contact Material Copper alloy with silver plating
Insulation Resistance >1000 M at 500V DC
Vibration Resistance 10-2000Hz, acceleration 15g
Shell Material Die-cast zinc alloy with nickel plating
Pins 10 pins
Protection Cap Optional, for plug protection when unmated
Mounting Type Cable mount / Inline free plug
Mechanical Life >500 mating cycles
Cable Diameter Range 8mm - 12mm
Flammability Rating UL94 V-0
Connection Type Screw-on locking coupling
Terminal Type Solder type
Contact Resistance 5 m
Standards Compliance IEC 61076-2-101
Sealing Method Rubber O-ring and grommet

DH24 400V 10A 10Pin Male Plug IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal Product Specifications

Output Multi-pin electrical
Product Type Male Plug Connector
IP Rating IP67
Components Metal shell, solder terminals, sealing gasket
Capacity 10A per pin
Dimension (L*W*H) Approx. 110mm x 37mm x 37mm
Rated Voltage 400V AC/DC
Size DH24 form factor
Supply Voltage 400V
Power Supply Electrical
Thickness Standard shell thickness (approx. 2mm)
Application Industrial machinery, automation, heavy-duty outdoor equipment
Power Source External electrical supply
Color Silver
Operating Temperature -40C to +85C
Input Multi-pin electrical
Function Power connection for industrial and outdoor equipment
Current Rating 10A
Features Waterproof, dustproof, corrosion resistant, robust metal shell
Usage Power transmission in harsh or wet environments
Weight Approx. 250g
Frequency 50/60Hz
Interface 10 Pin male circular interface

Salt Spray Test >48 hours
Contact Material Copper alloy with silver plating
Insulation Resistance >1000 M at 500V DC
Vibration Resistance 10-2000Hz, acceleration 15g
Shell Material Die-cast zinc alloy with nickel plating
Pins 10 pins
Protection Cap Optional, for plug protection when unmated
Mounting Type Cable mount / Inline free plug
Mechanical Life >500 mating cycles
Cable Diameter Range 8mm - 12mm
Flammability Rating UL94 V-0
Connection Type Screw-on locking coupling
Terminal Type Solder type
Contact Resistance 5 m
Standards Compliance IEC 61076-2-101
Sealing Method Rubber O-ring and grommet

DH24 400V 10A 10Pin Male Plug IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:400V
Temperature and humidity:-4080C; 40C, 85%RH
Wire Gauge:1.01.5mm/18 -16AWG
Withstand voltage(AC.V)1min:2500V
Mating Cycle:1700 Times

Superior Protection for Demanding Environments

Designed with an IP67-rated metallic shell, the DH24 400V 10A 10Pin Male Plug ensures exceptional resistance to dust, water, and corrosion. Its construction prioritizes longevity, making it an excellent choice for industrial sites and outdoor electrical installations where dependable power connection is crucial.

Versatile and Reliable Performance

Accommodating high current and voltage requirements-up to 400V and 10A per pin-this connector is suitable for critical power transmission in automation systems, heavy-duty machinery, and equipment requiring high operational reliability. The plug is engineered to comply with international standards, delivering consistent and safe service.

Ease of Installation and Maintenance

The DH24 plug features solder terminals and a screw-on locking coupling for straightforward assembly and secure attachment. With an intuitive cable mounting design, it fits cables ranging from 8mm to 12mm and allows for more than 500 mating cycles, ensuring a lasting power connection with minimal maintenance needs.

FAQ's of DH24 400V 10A 10Pin Male Plug IP67 Metal Waterproof Power Connector Metal Shell Solder Terminal:

Q: How is the DH24 400V 10A 10Pin Male Plug installed?

A: Installation is performed via cable mounting using solder terminals for wire attachment. The screw-on locking coupling secures the connection, while the rubber O-ring and grommet provide a watertight seal. Cables with diameters between 8mm and 12mm are supported, ensuring compatibility with standard industrial wiring.

Q: What makes the DH24 connector suitable for outdoor or harsh environments?

A: With an IP67 rating, die-cast zinc alloy shell, and corrosion-resistant nickel plating, the DH24 connector withstands dust, water, and extreme temperatures (-40C to +85C). Its robust build and sealing technology make it ideal for demanding industrial and outdoor settings.

Q: When should the protection cap be used with this connector?

A: The optional protection cap is recommended whenever the plug is unused or disconnected. This helps maintain the IP67 protection by preventing dust, moisture, or contaminants from entering the connector's interface.

Q: Where is the DH24 plug typically used?

A: It is commonly employed in industrial machinery, automation equipment, and heavy-duty outdoor power distribution systems that require high-reliability connectors. Its rugged design suits both stationary and mobile electrical installations.

Q: What is the benefit of the connector's screw-on locking coupling?

A: The screw-on locking mechanism ensures a stable, vibration-resistant connection, reducing the risk of accidental disconnection even in environments with high mechanical stress or frequent movement.

Q: How does the DH24 plug ensure electrical safety and longevity?

A: It adheres to IEC 61076-2-101 and UL94 V-0 standards, features insulation resistance over 1000 M, and demonstrates mechanical endurance with over 500 mating cycles. The silver-plated contacts guarantee optimal conductivity and minimal contact resistance.
