Din Connector Female Panel type

100.00 INR/Piece

Get a Price/Quote

Product Details:

Connector Type Panel Mount, Circular DIN
Connector DIN Female Panel Mount
Application Audio/Video Equipment, Industrial Controls, Instrumentation Panels
Material Nickel-Plated Brass Body, Gold-Plated Contacts
Temperature -20C to +85C Operating Range
Voltage Rating 100V AC/DC
Pairs Single (Individual Signals)
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Din Connector Female Panel type Price And Quantity

Price 100.00 INR/Piece
Minimum Order Quantity 100 Piece

Din Connector Female Panel type Product Specifications

Material Nickel-Plated Brass Body, Gold-Plated Contacts
Sheild Yes, Metal Shielded
Connector DIN Female Panel Mount
Jacket Material Not Applicable (Panel Housing)
Wire Gauge Typically 22-26 AWG (Dependent on Panel Mount Application)
Cable Type Not Included (Connector Only)
Number of Conductor Up to 5 (Standard DIN Panel Types)
Outer Diameter Approximately 16 mm (Panel Housing)
Application Audio/Video Equipment, Industrial Controls, Instrumentation Panels
Connector Type Panel Mount, Circular DIN
Male End Type Not Included (Female Only)
Color Black/Metallic
Female End Type DIN Female Socket
Capacity Depends on Pin Count, Typically 1.5A per Contact
Flame Resistance Level Standard UL94V-0
Length Panel Mount: Cable Length Not Applicable
Voltage Rating 100V AC/DC
Insulation PVC Insulated
Pairs Single (Individual Signals)
Temperature -20C to +85C Operating Range

Contact Resistance Maximum 30 m
Mating Cycles 500 cycles
Panel Cutout Diameter 16 mm (+0.2/-0.1 mm)
Protection Level IP20 (Standard Panel Mount)
Termination Style Solder Cup
Insulation Resistance 1000 M Min at 500V DC
Dielectric Withstand Voltage 500V AC (1 min)
Contact Plating Gold over Nickel
Number of Pins 3, 4, or 5 Pin (as per application)
Mounting Method Chassis/Panel Mount with Locking Thread
Standards Met DIN 41524, RoHS Compliant

Product Description

Add to Cart this in demand Din Connector Female Panel type, engineered for superlative reliability and inestimable performance. Its grandiose design features gold over nickel-plated contacts, ensuring minimal contact resistance (30 m) and robust insulation (1000 M at 500V DC). Suitable for 3, 4, or 5 pins, this affordable panel mount solution matches DIN 41524 standards and RoHS compliance. With a rugged locking thread and metal shielded body, it is perfect for audio/video, instrumentation, and industrial controls. Flame resistant (UL94V-0) and rated for up to 1.5A per contact, this connector promises trustworthy connectivity even under the most exacting conditions in India.

Versatile Applications Across Industries

The Din Connector Female Panel type excels beyond instrumentation, finding its place in commercial environments, plant operations, and varied industrial applications. Whether ensuring secure signal transmission in audio/video equipment or managing connections in commercial automation systems, its robust, shielded design ensures consistent performance. The connector's adaptability to various panel mount scenarios makes it valuable for industrial controls, control panels, and versatile plant operations, where reliability and efficiency are essential for uninterrupted functionality.

Certified Assurance and Convenient Sample Policy

This Din Connector adheres to DIN 41524 and RoHS compliance for trust and industry-wide acceptance. For drop-off evaluation, samples are available, allowing customers to rate the fit and suitability of the connector before mass procurement. The policy promotes convenient exchanges, ensuring your organization is equipped with the right solution even if initial requirements change. Obtain certified, tested connectors and experience a customer-focused sample and exchange policy tailored for hassle-free decision-making.
