LP12 125V 5A 5Pin Male Plug IP67 Waterproof Power Connector

278.0 INR/Piece

Get a Price/Quote

Product Details:

Power Supply AC/DC
Components 5 pin male plug, seal ring, housing
Output Cable connection
IP Rating IP67
Operating Temperature -40C to +85C
Features Dustproof, waterproof, corrosion-resistant, reliable locking mechanism
Usage Outdoor/Indoor Electrical Connections
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP12 125V 5A 5Pin Male Plug IP67 Waterproof Power Connector Price And Quantity

Minimum Order Quantity 100 Piece
Price 278.0 INR/Piece

Insulation Resistance >2000 M at 500V DC
Flame Retardant Grade UL94 V-0
Contact Resistance <10 m
Mechanical Life >500 mating cycles
Contact Material Copper alloy with gold plating
Connection Type Panel mount or inline
Sealing Method O-ring with threaded coupling
Cable Diameter Range 4-6.5mm
Shell Material Nylon PA66
Standards Compliance RoHS

LP12 125V 5A 5Pin Male Plug IP67 Waterproof Power Connector Product Specifications

Rated Voltage 125V
Output Cable connection
Components 5 pin male plug, seal ring, housing
Current Rating 5A
IP Rating IP67
Color Black
Power Supply AC/DC
Application Power distribution, industrial automation, LED lighting
Dimension (L*W*H) See datasheet
Function Power Connector
Product Type Waterproof Power Connector
Weight Approx. 32g
Size 12mm shell diameter
Operating Temperature -40C to +85C
Features Dustproof, waterproof, corrosion-resistant, reliable locking mechanism
Capacity 5A
Supply Voltage Up to 125V
Usage Outdoor/Indoor Electrical Connections
Thickness Standard
Frequency 50/60 Hz
Interface Screw terminal or solder
Input 5 Pin Male
Power Source Connected Equipment

Insulation Resistance >2000 M at 500V DC
Flame Retardant Grade UL94 V-0
Contact Resistance <10 m
Mechanical Life >500 mating cycles
Contact Material Copper alloy with gold plating
Connection Type Panel mount or inline
Sealing Method O-ring with threaded coupling
Cable Diameter Range 4-6.5mm
Shell Material Nylon PA66
Standards Compliance RoHS

LP12 125V 5A 5Pin Male Plug IP67 Waterproof Power Connector Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting mode:Easy locking type
Insertion and extraction force:1.5N Max
Wire specification:UL246424AWG*2C
Rated Current:5A
Contact dimension:Phi 1.0x5
Temperature and humidity:-40+80C; 40C,85%RH
Mating cycle:1700 times

Superior Waterproof Performance

Designed to withstand even the harshest environments, the LP12 connector's IP67 waterproof rating and O-ring sealing mechanism ensure protection from dust, water ingress, and environmental corrosion. This makes it highly suitable for outdoor installations and rugged industrial settings, providing reliable operation in all weather conditions.

Long-lasting Durability and Safety

Constructed with high-grade nylon (PA66) and gold-plated copper alloy contacts, this power connector offers outstanding insulation resistance (>2000 M at 500V DC) and minimal contact resistance (<10 m). The flame-retardant housing certified to UL94 V-0 and a secure threaded coupling maximize safety and longevity over more than 500 mating cycles.

Flexible, Versatile Applications

The LP12 5Pin power connector is designed for easy panel mount or in-line installation, fitting cable diameters from 4-6.5 mm, and ensuring seamless integration into power distribution panels, industrial automation systems, and LED lighting networks. Its screw terminal or solder interface allows quick, secure, and flexible wiring to suit various project requirements.

FAQ's of LP12 125V 5A 5Pin Male Plug IP67 Waterproof Power Connector :

Q: How is the LP12 5Pin waterproof power connector installed?

A: The connector supports both panel mounting and inline cable connections. Installation involves threading the housing with an O-ring seal for a watertight fit, then securing wire connections using either screw terminals or soldering, as preferred by the installer.

Q: What benefits does the gold-plated copper contact system offer?

A: Gold plating on copper alloy contacts enhances conductivity and minimizes contact resistance (<10 m), reducing power loss. This also offers better resistance against corrosion and prolongs the lifespan of the connector in various environmental conditions.

Q: When should I choose this connector for my application?

A: Consider the LP12 5Pin connector when you require a reliable, waterproof and dustproof power connection for outdoor/indoor equipment handling up to 5A and 125V (AC/DC), such as in LED lighting, industrial automation, and power distribution projects.

Q: Where can the LP12 5Pin connector be used?

A: This connector is suitable for use in both indoor and outdoor environments, including harsh or wet locations requiring IP67-rated protection. Typical applications include industrial equipment, outdoor lighting systems, and automated electrical systems.

Q: What process ensures the connector remains waterproof?

A: The built-in O-ring and threaded coupling secure the connection and prevent ingress of dust or water. This, combined with the PA66 nylon shell, achieves IP67 protection for long-term reliability in wet or corrosive environments.

Q: How does the LP12 connector comply with safety standards?

A: The connector is RoHS compliant and features a flame-retardant shell rated UL94 V-0. These certifications ensure it meets stringent safety, health, and environmental regulations for electrical components used worldwide.

Q: What is the expected lifespan or usage cycle of this connector?

A: The LP12 connector is designed for over 500 mating cycles, ensuring dependable mechanical performance and reliable electrical contact throughout repeated use in demanding industrial and commercial applications.
