LP12 125V 5A 6Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal

254.0 INR/Piece

Get a Price/Quote

Product Details:

IP Rating IP67
Output 6-pin female output
Usage Waterproof power connection
Power Source External Power
Operating Temperature -40C to +85C
Components Female Socket, Plastic Shell, Solder Terminals
Interface 6 Pin Female Panel Socket
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP12 125V 5A 6Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 254.0 INR/Piece

Sealing Method Silicone rubber gasket
Contact Material Gold-plated copper contacts
Shell Material High-strength engineering plastic
Withstand Voltage 1500V AC/minute
Contact Resistance 5m
Mating Cycle Durability >500 cycles
Mounting Type Panel Mount
Connection Type Solder Terminal
Insulation Resistance >1000M at 500V DC
Flame Retardant Grade UL94-V0
Gender Female Socket
Cable Diameter Range 4mm - 6.5mm

LP12 125V 5A 6Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal Product Specifications

Capacity 5A max current
Components Female Socket, Plastic Shell, Solder Terminals
Supply Voltage 125V AC/DC
Operating Temperature -40C to +85C
Power Source External Power
Weight Approx. 15g
Color Black
Current Rating 5A
Dimension (L*W*H) Approx. 48mm x 20mm x 20mm
Function Electrical power and signal connection
IP Rating IP67
Power Supply Wire to Wire / Panel Mount
Size LP12 Series standard size
Usage Waterproof power connection
Output 6-pin female output
Product Type Waterproof Power Connector
Input Wire connection via solder terminal
Rated Voltage 125V AC/DC
Application LED lighting, automation equipment, outdoor electronic devices
Interface 6 Pin Female Panel Socket
Features IP67 dust and waterproof, corrosion resistant, quick installation, secure locking, plastic housing

Sealing Method Silicone rubber gasket
Contact Material Gold-plated copper contacts
Shell Material High-strength engineering plastic
Withstand Voltage 1500V AC/minute
Contact Resistance 5m
Mating Cycle Durability >500 cycles
Mounting Type Panel Mount
Connection Type Solder Terminal
Insulation Resistance >1000M at 500V DC
Flame Retardant Grade UL94-V0
Gender Female Socket
Cable Diameter Range 4mm - 6.5mm

LP12 125V 5A 6Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting mode:Easy locking type
Insertion and extraction force:0.6N Max
Wire specification:UL246424AWG*2C
Rated Current:5A
Contact dimension:Phi 1.0x2
Temperature and humidity:-4080C, 40C, 85%RH
Mating cycle:1700 times

Reliable Waterproof Power Connections

The LP12 6Pin Female Socket offers IP67-rated dust and water protection, making it ideal for outdoor or industrial applications. Engineered with a high-strength plastic shell and silicone rubber sealing, it ensures dependable performance in challenging environments. This connector provides a secure interface, resisting corrosion and rough handling while maintaining lasting electrical integrity.

Efficient and Secure Panel Mount Design

Designed for panel mounting, the LP12 connector features solder terminals for a stable and secure wire connection. This facilitates quick and precise installation, reducing assembly time and minimizing wiring errors. Its secure locking mechanism provides added safety, supporting more than 500 mating cycles for long-term operational reliability.

FAQ's of LP12 125V 5A 6Pin Female Socket IP67 Waterproof Power Connector Plastic Shell Solder Terminal:

Q: How do I install the LP12 125V 5A 6Pin Female Socket in my device?

A: The LP12 is designed for panel mounting, requiring a matching cutout in your panel. Secure the socket using the provided locking mechanism, then solder the wires to the terminals according to your wiring requirements. Ensure the gasket is properly seated to maintain its waterproof rating.

Q: What are the benefits of the IP67 waterproof rating on this connector?

A: With an IP67 rating, the connector is dust-tight and protected against temporary immersion in water. This ensures reliable connections in demanding environments, such as outdoor installations or industrial equipment exposed to moisture and dust.

Q: Where can this socket be used most effectively?

A: The LP12 socket is suitable for outdoor LED lighting, automation systems, and electronic devices that require a secure, waterproof, and corrosion-resistant power connection. Its durable design makes it ideal for environments with exposure to weather or mechanical stress.

Q: What process is involved in connecting wires to this socket?

A: The connection process involves stripping the insulation on your wires, then soldering them to the specified terminals. After soldering, check for secure attachment, and assemble the socket into your panel, ensuring all seals are intact to maintain waterproof performance.

Q: How does the gold-plated copper contact benefit the connector's performance?

A: Gold-plated copper contacts enhance conductivity and reduce contact resistance, ensuring lower power loss and more stable electrical performance. They also resist corrosion, supporting reliable long-term operation even in harsh environments.

Q: When is it necessary to use a flame retardant connector like this one?

A: A flame retardant connector, such as the LP12 with UL94-V0 rating, is essential in applications where fire safety is a concern, such as automation equipment or electronic devices operating in environments with flammable materials.
