LP12 5A 6Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal

329.0 INR/Piece

Get a Price/Quote

Product Details:

Components Metal shell, insulator, 6 solder pins, panel mounting nut
Features Waterproof, corrosion resistant, vibration proof, compact metal shell
Usage Industrial, outdoor electrical enclosures, equipment interfaces
Power Source Externally powered, through connector
Power Supply Panel-mounted, wired via solder terminals
Interface 6 pin solder terminal, panel mount interface
Output Solder terminal connection, 6 pin
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

LP12 5A 6Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal Price And Quantity

Minimum Order Quantity 100 Piece
Price 329.0 INR/Piece

Cable Entry Size Suitable for up to 4mm cable diameter
Flammability Rating UL94-V0 (insulator)
Ingress Protection Waterproof and dustproof
Number of Positions 6
RoHS Compliance Yes
Shell Material Zinc alloy (nickel-plated)
Life Cycle >2000 mating cycles
Sealing Method Silicone rubber gasket
Contact Resistance 5m
Dielectric Withstand Voltage 1500V AC/minute
Connection Method Solder terminal
Mating Connector LP12 6-pin male plug
Insulation Resistance >1000 M
Connector Gender Female (socket)
Mounting Type Panel mount with threaded fastener
Panel Thickness Range 1mm to 4mm
Environmental Rating Outdoor use, UV resistant
Contact Material Brass with silver plating

LP12 5A 6Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal Product Specifications

IP Rating IP67
Supply Voltage Up to 250V AC/DC
Dimension (L*W*H) Approx. 40mm (length) x 16mm (diameter)
Size Panel cutout: 12mm diameter
Input Solder terminal connection, 6 pin
Operating Temperature -20C to +85C
Frequency 50/60Hz
Function Electrical power and signal connection, waterproof panel mount socket
Output Solder terminal connection, 6 pin
Interface 6 pin solder terminal, panel mount interface
Product Type Waterproof connector / female socket
Application Power and signal transmission in harsh environments
Power Source Externally powered, through connector
Rated Voltage 250V AC
Power Supply Panel-mounted, wired via solder terminals
Usage Industrial, outdoor electrical enclosures, equipment interfaces
Features Waterproof, corrosion resistant, vibration proof, compact metal shell
Capacity 6 contacts for signal/power
Components Metal shell, insulator, 6 solder pins, panel mounting nut
Color Silver (metal shell), black (insulator)
Weight Approx. 20g
Current Rating 5A (each pin)
Thickness Approx. 1.5mm (shell)

Cable Entry Size Suitable for up to 4mm cable diameter
Flammability Rating UL94-V0 (insulator)
Ingress Protection Waterproof and dustproof
Number of Positions 6
RoHS Compliance Yes
Shell Material Zinc alloy (nickel-plated)
Life Cycle >2000 mating cycles
Sealing Method Silicone rubber gasket
Contact Resistance 5m
Dielectric Withstand Voltage 1500V AC/minute
Connection Method Solder terminal
Mating Connector LP12 6-pin male plug
Insulation Resistance >1000 M
Connector Gender Female (socket)
Mounting Type Panel mount with threaded fastener
Panel Thickness Range 1mm to 4mm
Environmental Rating Outdoor use, UV resistant
Contact Material Brass with silver plating

LP12 5A 6Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Operating Voltage:250V
Contact dimension:Phi 1.0x2
Insertion and extraction force:0.6N Max.
Mating cycle:1700 times
Temperature and humidity:-4080C, 40C, 85%RH.
Wire specification:UL2464 24AWG*2C
Connecting mode:Easy locking type

Superior Environmental Protection

Engineered for outdoor and industrial applications, the LP12 socket offers IP67-rated waterproof and dustproof performance. The inclusion of a silicone rubber gasket and a robust, nickel-plated zinc shell ensures complete protection against heavy rain, dust intrusion, and UV exposure, making it ideal for harsh environments and long-term installations.

Secure and Reliable Connections

Designed with precision, this 6-pin female socket utilizes brass contacts with silver plating to enhance signal and power transmission quality. Its solder terminal connection method guarantees low contact resistance and high insulation resistance, ensuring consistent performance, while withstanding more than 2000 mating cycles for lasting durability.

Flexible Mounting and Versatile Use Cases

The threaded panel mount design accommodates panel thicknesses from 1mm to 4mm, with a compact cutout diameter of just 12mm. Its application versatility includes industrial automation panels, outdoor electrical enclosures, and critical equipment interfaces, making it a practical choice for electrical distributors, manufacturers, and installers across sectors.

FAQ's of LP12 5A 6Pin Female Socket IP67 Waterproof Power Connector Panel Mount Metal Shell Solder Terminal:

Q: How is the LP12 6 pin female socket installed on a panel?

A: The LP12 socket is panel mounted by inserting it into a 12mm diameter cutout and securing it with the included threaded nut. It supports panel thicknesses from 1mm to 4mm, providing a secure and vibration-resistant fit.

Q: What makes this connector suitable for outdoor and harsh environments?

A: Featuring an IP67 rating, UV resistance, and a nickel-plated metal shell with a silicone gasket, the LP12 socket is waterproof, dustproof, and corrosion resistant. Its robust construction ensures reliable operation even under severe weather and industrial conditions.

Q: When should I use the LP12 6 pin connector for my application?

A: This connector is ideal for situations where dependable power and signal transmission is needed in outdoor or industrial settings, such as electrical enclosures, equipment interfaces, and automation systems exposed to moisture or dust.

Q: Where can this connector be used effectively?

A: The LP12 female socket is commonly used in outdoor electrical panels, industrial machinery, equipment control boxes, and similar environments where water, dust, or vibration could compromise lesser connectors.

Q: What are the key benefits of the solder terminal connection method?

A: Solder terminals provide robust, low-resistance contacts and allow for secure, permanent wire attachment, ensuring stable performance in environments with frequent vibration or temperature changes.

Q: How does the waterproof sealing process work in this connector?

A: A silicone rubber gasket forms a tight seal between the socket and the panel, blocking water and dust ingress. Along with the metal shell and precise construction, this process achieves the IP67 ingress protection rating.
