YF24 500V 20A 3Pin PowerCON IP67 Waterproof Connector

374.0 INR/pieces

Get a Price/Quote

Product Details:

Output 3 Pin (Male/Female)
IP Rating IP67
Usage Outdoor & Industrial Power Supply
Power Source Mains AC powered
Power Supply AC
Features Waterproof, Dustproof, Secure Locking Mechanism, Corrosion Resistant
Operating Temperature -40C to +85C
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

YF24 500V 20A 3Pin PowerCON IP67 Waterproof Connector Price And Quantity

Price 374.0 INR/pieces
Minimum Order Quantity 100 pieces

Material High-strength industrial grade PA66 Nylon + Brass contacts
Contact Resistance 5m
Insulation Resistance >2000M (at 500V DC)
Mounting Method Panel mount, cable mount
Sealing Method O-ring sealing gasket
Connector Type 3 Pin PowerCON (Male/Female available)
Mechanical Life >500 mating cycles
Flame Retardant Rating UL94 V-0
Cable OD Range 6-12mm
Rated Impulse Voltage 4000V

YF24 500V 20A 3Pin PowerCON IP67 Waterproof Connector Product Specifications

Operating Temperature -40C to +85C
Application LED display, Outdoor Lighting, Machinery, Power Distribution Boxes
Input 3 Pin (Male/Female)
Usage Outdoor & Industrial Power Supply
Interface Screw terminal connection
Frequency 50/60Hz
Current Rating 20A
Function Waterproof electrical power connection
Supply Voltage 500V AC
IP Rating IP67
Output 3 Pin (Male/Female)
Features Waterproof, Dustproof, Secure Locking Mechanism, Corrosion Resistant
Product Type PowerCON Waterproof Connector
Size YF24 Series 3 Pin
Color Black & Blue
Rated Voltage 500V
Components Socket, Plug, Sealing Gasket, Locking Nut
Weight Approx. 120g per connector
Power Source Mains AC powered
Capacity 20A current
Power Supply AC
Dimension (L*W*H) Approx. 90 x 34 x 34 mm
Thickness Standard housing thickness

Material High-strength industrial grade PA66 Nylon + Brass contacts
Contact Resistance 5m
Insulation Resistance >2000M (at 500V DC)
Mounting Method Panel mount, cable mount
Sealing Method O-ring sealing gasket
Connector Type 3 Pin PowerCON (Male/Female available)
Mechanical Life >500 mating cycles
Flame Retardant Rating UL94 V-0
Cable OD Range 6-12mm
Rated Impulse Voltage 4000V

YF24 500V 20A 3Pin PowerCON IP67 Waterproof Connector Trade Information

Delivery Time 7 Days

Product Description

Brand:CNLINKO
Connecting Mode:Fast Locking
Cable Specification:2.5mm2 4mm2 /1412AWG
Diameter Range:8mm 12mm
Operating Voltage:500V
Withstand Voltage(AC.V)1min:2500V
Durability:> 500 mating & unmating cycles

Industrial Power, Waterproofed

The YF24 3Pin PowerCON connector delivers secure, weatherproof electrical connections for demanding outdoor and industrial use. Resistant to water and dust (IP67-rated), it's constructed from robust PA66 nylon and supports up to 500V and 20A for reliability in critical applications such as LED displays, outdoor lighting, and machinery automation.

Versatile Features for Easy Installation

Designed with convenience in mind, this connector supports both panel mount and cable mount installations. An O-ring sealing gasket and secure screw terminal interface ensure fast and safe assembly. With color-coded options and a standardized size, it fits seamlessly into new and existing systems, simplifying integration with various equipment.

FAQ's of YF24 500V 20A 3Pin PowerCON IP67 Waterproof Connector:

Q: How do I install the YF24 500V 20A 3Pin PowerCON connector?

A: Installation is straightforward: select either the panel mount or cable mount version based on your application. Strip your cable (6-12mm OD), connect the wires to the screw terminals, secure the connector with the included locking nut, and ensure the O-ring gasket is seated for proper sealing.

Q: What makes this connector suitable for outdoor and industrial use?

A: The YF24 connector is IP67-rated, offering complete protection against dust and temporary water immersion. It features a robust PA66 nylon shell, corrosion-resistant brass contacts, and a flame retardant rating of UL94 V-0, ensuring reliability in harsh environments.

Q: Where can I use the YF24 3Pin PowerCON connector?

A: This connector is ideal for powering LED displays, outdoor lighting, industrial machinery, power distribution boxes, and any application requiring a waterproof, dustproof, and secure AC connection up to 500V/20A.

Q: What is the advantage of the O-ring sealing gasket?

A: The integrated O-ring sealing gasket provides enhanced waterproof protection, ensuring no moisture penetrates the connection, even during temporary submersion, thus extending connector life and performance in outdoor conditions.

Q: How long will the connector last under regular usage?

A: With a mechanical life rating of over 500 mating cycles and an operating temperature range from -40C to +85C, the YF24 connector is engineered for frequent use and durability in demanding environments.

Q: What are the safety features of this connector?

A: Safety is prioritized with features such as a secure locking mechanism to prevent accidental disconnection, flame retardant housing (UL94 V-0), high insulation resistance (>2000M at 500V DC), and a robust sealing system to protect users and equipment.

Q: Can I use this connector for both male and female input/output connections?

A: Yes, the YF24 PowerCON series is available in both male and female variants, allowing flexible configuration for 3-pin AC power input and output connections in various setups.
